Presentation Transcript

Slide2 l.jpg

  • When substituents are attached to a molecule, such as a carboxylic acid, they can influence the acidity (or basicity) of that substance.

  • Some substituents strengthen acids and weaken bases; other substituents have the opposite effect, the weaken acids and strengthen bases.

  • Substituents exert their effects on acidity or basicity through a combination of resonance and inductive effects.

  • REVIEW: Lecture Textbook, Chapter 7, especially sections 7.6 through 7.8.

WWU- Chemistry


Slide3 l.jpg

  • The essential idea is this: if a substituent removes electrons from the negative oxygen of a carboxylate ion, it will stabilize the ion. This effect shifts the equilibrium to the right and increases acidity.

  • If a substituent pours electrons toward the negative oxygen of a carboxylate ion, it will destabilize the ion. This effect will shift the equilibrium to the left and decrease acidity.

WWU- Chemistry


Slide4 l.jpg

  • Electron-withdrawing Effects electrons from the negative oxygen of a carboxylate ion, it will stabilize the ion. This effect shifts the equilibrium to the right and :

    • strengthen acids

    • weaken bases

  • Electron-releasing Effects:

    • weaken acids

    • strengthen bases

WWU- Chemistry


Slide5 l.jpg

Resonance Effects on the Acidities of Carboxylic Acids electrons from the negative oxygen of a carboxylate ion, it will stabilize the ion. This effect shifts the equilibrium to the right and

WWU- Chemistry


Resonance effects of substituents l.jpg
Resonance Effects of Substituents electrons from the negative oxygen of a carboxylate ion, it will stabilize the ion. This effect shifts the equilibrium to the right and

Consider a substituent that contains multiple bonds.

Let

represent such a substituent, where B is more electronegative than A.

WWU- Chemistry


Slide7 l.jpg

In other words, let’s compare the acidities of: electrons from the negative oxygen of a carboxylate ion, it will stabilize the ion. This effect shifts the equilibrium to the right and

Which acid is stronger, and why?

WWU- Chemistry


Slide8 l.jpg

The substituent will be a hybrid of two or more resonance forms of the type:

The presence of the substituent on a molecule will influence the electron distribution throughout the entire structure. This type of effect, called a resonance effect, can be seen most clearly when the substituent is attached to a benzene ring.

WWU- Chemistry


Slide9 l.jpg

To illustrate, consider a forms of the type:para-substituted benzoic acid. We can draw resonance forms:

WWU- Chemistry



Slide11 l.jpg

The resonance forms that are the most important in our discussion are those forms where the positive charge is located on the carbon atom that also bears the functional group. The ionization of the substituted benzoic acid can thus be analyzed by examining the following equilibrium:

WWU- Chemistry


Slide12 l.jpg

  • The positive charge in the ring attracts the electrons on the carboxylate group. The resonance effect of the substituent thus acts to stabilize the anion and shift the equilibrium to the right.

  • Remember that we are comparing the substituted benzoic acid with unsubstituted benzoic acid. In the unsubstituted benzoic acid, we are assuming that the substituent (H) makes no difference in the electron distribution in the ring.

  • Thus, we would expect the -A=B substituted benzoic acid to be a stronger acid than benzoic acid itself.

WWU- Chemistry


Slide13 l.jpg

A specific example of the -A=B type of substituent is the the carboxylate group. The resonance effect of the substituent thus acts to stabilize the anion and shift the equilibrium to the right.nitrogroup (-NO2). A nitro group in the para position of a benzoic acid strengthens the acidity by a factor of six (0.8 log units).

WWU- Chemistry


Slide14 l.jpg

The nitro group stabilizes the carboxylate anion and shifts the equilibrium to the right.

NOTE: The nitro group also has an electron-withdrawing inductive effect; this has been ignored in this discussion. Inductive effects will be examined later.

WWU- Chemistry


Slide15 l.jpg

  • The resonance effect of a substituent of the -A=B type the equilibrium to the right.reduces the electron density in the benzene ring. The resonance forms shown here represent this reduction of electron density by showing positive charge in the ring.

  • As a result, these substituents exert an electron-withdrawing resonance effect.

  • This is sometimes represented as a -R effect.

  • The following table shows several substituent groups that exert an electron-withdrawing resonance (-R) effect.

WWU- Chemistry


Substituents with electron withdrawing resonance effects l.jpg
Substituents with Electron-Withdrawing Resonance Effects the equilibrium to the right.

WWU- Chemistry


Slide17 l.jpg

  • The resonance forms show that positive charge is located at the ortho and para positions with respect to the substituent.

  • A functional group that is located ortho or para to the substituent will be influenced by the resonance effect. A substituent located meta to the substituent will be affected to a much smaller degree.

  • Therefore, we would expect that whenever a -R substituent is located ortho or para to a carboxyl group, the acidity of the benzoic acid should be increased.

WWU- Chemistry


R substituents strengthen acids and weaken bases l.jpg
-R the substituents strengthen acids and weaken bases

WWU- Chemistry


Resonance effects of substituents part two l.jpg
Resonance Effects of Substituents (Part Two) the

Consider a substituent that contains an atom that bears one or more unshared pairs of electrons.

Let

represent such a substituent.

WWU- Chemistry


Slide20 l.jpg

In other words, let’s compare the acidities of: the

Which acid is stronger, and why?

WWU- Chemistry


Slide21 l.jpg

When this substituent is attached to the benzene ring, the unshared electron pairs will be shifted into the ring through resonance.

Once again, the presence of the substituent on a molecule will influence the electron distribution throughout the entire structure. This is another example of a resonance effect.

WWU- Chemistry


Slide22 l.jpg

To illustrate, consider a unshared electron pairs will be shifted into the ring through resonance.para-substituted benzoic acid. We can draw resonance forms:

WWU- Chemistry



Slide24 l.jpg

The resonance forms that are the most important in our discussion are those forms where the negative charge is located on the carbon atom that also bears the functional group. The ionization of the substituted benzoic acid can thus be analyzed by examining the following equilibrium:

WWU- Chemistry


Slide25 l.jpg

  • The negative charge in the ring repels the electrons on the carboxylate group. The resonance effect of the substituent thus acts to destabilize the anion and shift the equilibrium to the left.

  • Remember that we are comparing the substituted benzoic acid with unsubstituted benzoic acid. In the unsubstituted benzoic acid, we are assuming that the substituent (H) makes no difference in the electron distribution in the ring.

  • Thus, we would expect the -Y substituted benzoic acid to be a weaker acid than benzoic acid itself.

WWU- Chemistry


Slide26 l.jpg

A specific example of the -Y type of substituent is the carboxylate group. The resonance effect of the substituent thus acts to methoxy group (-OCH3). A methoxy group in the para position of a benzoic acid weakens the acidity by a factor of 1.9 (0.27 log units).

WWU- Chemistry


Slide27 l.jpg

The methoxy group destabilizes the carboxylate anion and shifts the equilibrium to the left.

NOTE: The methoxy group also has an electron-withdrawing inductive effect; this has been ignored in this discussion. Inductive effects will be examined later.

WWU- Chemistry


Slide28 l.jpg

  • The resonance forms show that electron density is increased at the ortho and para positions with respect to the substituent.

  • A functional group that is located ortho or para to the substituent will be influenced by the resonance effect. A substituent located meta to the substituent will be affected to a much smaller degree.

  • Therefore, we would expect that whenever a +R substituent is located ortho or para to a carboxyl group, the acidity of the benzoic acid should be decreased.

WWU- Chemistry



Slide30 l.jpg

  • The resonance effect of a substituent of the -Y type at the increases the electron density in the benzene ring. The resonance forms shown here represent this increase of electron density by showing negative charge in the ring.

  • As a result, these substituents exert an electron-releasing resonance effect. This is sometimes called anelectron-donating resonance effect.

  • This is sometimes represented as a +R effect.

  • The following table shows several substituent groups that exert an electron-releasing resonance (+R) effect.

WWU- Chemistry


R substituents weaken acids and strengthen bases l.jpg
+R at the substituents weaken acids and strengthen bases

WWU- Chemistry


Slide32 l.jpg

In the case of the alkyl substituents (which have no unshared pairs of electrons), their electron-releasing resonance effect arises from hyperconjugation.

p-Methylbenzoic acid is less acidic than benzoic acid by a factor of 1.5 (0.17 log units)

WWU- Chemistry


Slide33 l.jpg

Inductive Effects on the Acidities of Carboxylic Acids unshared pairs of electrons), their electron-releasing resonance effect arises from hyperconjugation.

WWU- Chemistry


Slide34 l.jpg

Let’s now compare the acidities of two unshared pairs of electrons), their electron-releasing resonance effect arises from hyperconjugation.aliphaticcarboxylic acids:

where X is an electronegative element.

WWU- Chemistry


Slide35 l.jpg

  • Electronegative substituents attract electrons. unshared pairs of electrons), their electron-releasing resonance effect arises from hyperconjugation.

  • When electronegative elements are present in a molecule that can act as an acid, they enhance the acidity of the bond because they lower the electron density in that bond and because they stabilize the conjugate base.

  • Substituents of this type are said to have an electron-withdrawing inductive effect. This type of effect is often known as a -I effect.

  • The following table lists a number of substituents that have -I inductive effects:

WWU- Chemistry


Substituents with electron withdrawing inductive effects l.jpg
Substituents with Electron-Withdrawing Inductive Effects unshared pairs of electrons), their electron-releasing resonance effect arises from hyperconjugation.

WWU- Chemistry


Slide37 l.jpg

As before, whenever we consider the resonance or inductive effect of a substituent, we are comparing it with a reference substituent, hydrogen.

When hydrogen is the substituent, it is treated as if it had no resonance or inductive effect.

WWU- Chemistry


I substituents strengthen acids and weaken bases l.jpg
-I effect of a substituent, we are comparing it with a reference substituent, substituents strengthen acids and weaken bases

WWU- Chemistry


Slide39 l.jpg

And one last case, again comparing two effect of a substituent, we are comparing it with a reference substituent, aliphatic carboxylic acids:

The alkyl substituent (R) is weakly electropositive with respect to a hydrogen.

WWU- Chemistry


Slide40 l.jpg

  • When an electropositive substituent is placed in a molecule, we should see the opposite type of effect than we saw when electronegative substituents were present.

  • An electropositive substituent should show an electron-releasing (or electron-donating) inductive effect.

  • An electron-releasing inductive effect is sometimes known as a +I effect.

  • The following table lists several +I substituents.

WWU- Chemistry


Substituents with electron releasing inductive effects l.jpg
Substituents with Electron-Releasing Inductive Effects we should see the opposite type of effect than we saw when electronegative substituents were present.

WWU- Chemistry


I substituents weaken acids and strengthen bases l.jpg
+I we should see the opposite type of effect than we saw when electronegative substituents were present. substituents weaken acids and strengthen bases

WWU- Chemistry


Slide43 l.jpg

To illustrate the resonance and inductive effects described in this unit, consider the following examples:

WWU- Chemistry


Slide44 l.jpg

WWU- Chemistry


Slide45 l.jpg

WWU- Chemistry resonance effects.


Slide46 l.jpg

WWU- Chemistry


Slide47 l.jpg

WWU- Chemistry multiple substitution. Both electron-withdrawing and electron-releasing examples are included.


Slide48 l.jpg

  • In the next table, the effect of a chlorine substituent on the strength of a benzoic acid is shown.

  • The reference compound is benzoic acid.

  • -Cl has two competing effects: +R and -I

  • In the case of the chloro group, the -I effect is larger than the +R effect, so we see the -I effect. As the chloro group moves farther away from the carboxyl group, the acid becomes weaker.

WWU- Chemistry


Slide49 l.jpg

WWU- Chemistry


Slide50 l.jpg

Benzoic Acid: pK resonance effects are electron-withdrawing (acid strengthening).a = 4.19

WWU- Chemistry


Slide51 l.jpg

  • In the next example, we see the larger +R effects of the methoxy and hydroxy groups predominating over the smaller -I effects.

  • We can see that the substituted benzoic acids are significantly weaker when the -OH or -OCH3 groups are in the para positions than when they are in the meta positions (where the +R effect is not significant).

  • But we see that when we compare the two ortho-substituted benzoic acids, there is an anomaly.

  • ortho-Hydroxybenzoic acid (salicylic acid) is much stronger than we would predict.

WWU- Chemistry


Slide52 l.jpg

2.97 methoxy and hydroxy groups predominating over the smaller -I effects.

Benzoic Acid: pKa = 4.19

WWU- Chemistry


Slide53 l.jpg

When there is a hydroxy group methoxy and hydroxy groups predominating over the smaller -I effects.ortho to the carboxylic acid functional group, the carboxylate ion is stabilized through intramolecular hydrogen bonding.

WWU- Chemistry


Slide54 l.jpg

  • Finally, we see the acid-weakening effect (both +R and +I) of a methyl substituent.

  • When the methyl group is in the para position, it is more effective in weakening the benzoic acid. This is because the +R effect is operating from the para position (when the methyl group is in the meta position, we only see the +I effect).

WWU- Chemistry


Slide55 l.jpg

Benzoic Acid: pK of a methyl substituent.a = 4.19

WWU- Chemistry
