Arithmetic and Geometric Sequences and their Summation. 14.1 Sequences. arithmetic sequence. geometric sequence. geometric sequence. geometric sequence. Find the next two terms of the following sequences : 2, 5, 8, 11,…… 2, 6, 18, 54, …. 2, 4, 8, 16,……. 5, -25, 125, -625, ….

Download Presentation

Arithmetic and Geometric Sequences and their Summation

An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -

Presentation Transcript


Arithmetic and geometric sequences and their summation l.jpg

Arithmetic and Geometric Sequences and their Summation


14 1 sequences l.jpg

14.1 Sequences

arithmetic sequence

geometric sequence

geometric sequence

geometric sequence

Find the next two terms of the following sequences :

2, 5, 8, 11,……

2, 6, 18, 54, ….

2, 4, 8, 16,…….

5, -25, 125, -625, ….

3, 4, 6, 9, 13, …….

5, 2, -1, -4, …..

0, sin20o, 2sin30o, 3sin40o

arithmetic sequence


Consider the following sequence 1 3 5 7 9 111 l.jpg

14.1 Sequences

Consider the following sequence:1, 3, 5, 7, 9, ….., 111

3 is the second term of the sequence, mathematically,

T(2) = 3 or T2 = 3

1 is the first term of the sequence,mathematically, T(1) = 1 or T1 = 1

5 is the third term of the sequence, mathematically, T(3) = 5 or T3 = 5

111 is the nth term of the sequence, mathematically, T(n) = 111 or Tn = 111


Consider the sequence 2 4 8 16 l.jpg

14.1 Sequences

Consider the sequence 2, 4, 8, 16, ….

So, the sequence can be represented by the general term

T(n) = 2n or Tn = 2n

The sequence is formed from timing 2 to the previous term.


P 159 ex 14a l.jpg

P.159Ex. 14A


An arithmetic sequence a s a p is a sequence having a common difference l.jpg

14.2 Arithmetic Sequence

An arithmetic sequence(A.S. /A.P.) is a sequence having a common difference.


Slide7 l.jpg

14.2 Arithmetic Sequence

Illustrative Examples


Slide8 l.jpg

14.2 Arithmetic Sequence


Slide9 l.jpg

14.2 Arithmetic Sequence


Slide10 l.jpg

14.2 Arithmetic Sequence


P 166 ex 14b l.jpg

P.166Ex. 14B


Arithmetic means l.jpg

14.2 Arithmetic Sequence

Arithmetic Means

When a, b and c are three consecutive terms of arithmetic sequence, the middle term b is called the arithmetic mean of a and c.


Arithmetic means13 l.jpg

14.2 Arithmetic Sequence

Arithmetic Means

Insert two arithmetic means between 11 and 35.


Slide14 l.jpg

14.2 Arithmetic Sequence

Insert two arithmetic means between 11 and 35.


P 170 ex 14c l.jpg

P.170Ex. 14C


A geometric sequence g s g p is a sequence having a common ratio l.jpg

14.3 Geometric Sequence

A geometric sequence(G.S. / G.P.) is a sequence having a common ratio.


Illustrative examples l.jpg

14.3 Geometric Sequence

Illustrative Examples


Slide18 l.jpg

14.3 Geometric Sequence


Slide19 l.jpg

14.3 Geometric Sequence


Slide20 l.jpg

14.3 Geometric Sequence


P 176 ex 14d l.jpg

P.176Ex. 14D


Geometric means l.jpg

14.3 Geometric Sequence

Geometric Means

When x, y and z are three consecutive terms of geometric sequence, the middle term y is called the geometric mean of x and z.


Geometric means23 l.jpg

14.3 Geometric Sequence

Geometric Means

Insert two geometric means between 16 and -54.


Slide24 l.jpg

14.3 Geometric Sequence

Insert two geometric means between 16 and -54.


P 181 ex 14e l.jpg

P.181Ex. 14E


Let s consider a sequence t 1 t 2 t 3 t 4 t n l.jpg

14.4 Series

The expression T(1) + T(2) + T(3) +….+ T(n) is called a series. We usually denote the sum of the first n term of a series by the notation S(n).

Let’s consider a sequence : T(1), T(2), T(3), T(4), …., T(n)


Arithmetic sequence 2 5 8 11 arithmetic series 2 5 8 11 l.jpg

14.5 Arithmetic Series

Arithmetic Sequence : 2, 5, 8, 11, …

Arithmetic Series : 2 + 5 + 8 + 11 + ….


Formula of arithmetic series l.jpg

14.5 Arithmetic Series

Formula of Arithmetic Series

S(n) = a + a + d + a + 2d + a + 3d + …. + a + (n - 1)d

l


Formula of arithmetic series29 l.jpg

14.5 Arithmetic Series

Formula of Arithmetic Series

S(n) = l + l - d + l - 2d + l - 3d + …. + a + d+ a


Slide30 l.jpg

14.5 Arithmetic Series

S(n) = a + a + d + a + 2d + a + 3d + ………... + a + (n - 1)d

S(n) = l + l – d + l - 2d + l - 3d + ….+ a + d+ a

2S(n) =(a + l)+(a + l)+(a + l)+(a + l)+….. +(a + l)

2S(n) = n(a + l)


Slide31 l.jpg

14.5 Arithmetic Series


P 189 ex 14f l.jpg

P.189Ex. 14F


Geometric sequence 3 9 27 81 geometric series 3 9 27 81 l.jpg

14.6 Geometric Series

Geometric Sequence : 3, 9, 27, 81, …

Geometric Series : 3 + 9 + 27 + 81


Formula of geometric series l.jpg

14.6 Geometric Series

Formula of Geometric Series

S(n) = a + aR + aR2 +aR3+ …. + aRn-1


Formula of geometric series35 l.jpg

14.6 Geometric Series

Formula of Geometric Series

R.S(n) = aR + aR2 + aR3 +aR4+ …. + aRn


S n a ar ar 2 ar 3 ar n 1 l.jpg

Subtracting two series

S(n) = a + aR + aR2 +aR3+ …. + aRn-1

S(n) –R.S(n) = a - aRn

R.S(n) = aR + aR2 + aR3 +aR4+ …. + aRn

(1 – R) S(n) = a (1 – Rn)


Slide37 l.jpg

14.6 Geometric Series

Timing –1 on both numerator and denominator


P 196 ex 14g l.jpg

P.196Ex. 14G


Sum to infinity of a geometric series l.jpg

14.6 Geometric Series

Sum to Infinity of a Geometric Series


Consider such a geometric series l.jpg

14.6 Geometric Series

Sum to Infinity of a Geometric Series

Consider such a Geometric Series

What is the value of common ratio R ?


Slide41 l.jpg

14.6 Geometric Series

Sum to Infinity of a Geometric Series

Consider Rn where n tends to the infinity


Slide42 l.jpg

What will occur for if n tends to infinity ?

where –1< R <1


Slide43 l.jpg

Summation of a geometric Series to infinity


P 203 ex 14h l.jpg

P.203Ex. 14H


Slide45 l.jpg

(extension module)

Summation Notation


Slide46 l.jpg

Consider the symbol

where T( r ) = 3r + 5

= 3(1) + 5 + 3(2) + 5+3(3)

+ 5 + 3(4) +5

= 50
