  1. WEATHERING GEOLOGY NOTES Chapter 5

  2. WEATHERING • Breakdown of rock due to weather • no visible motion

  3. MECHANICAL (PHYSICAL) WEATHERING • Disintegration • Breaks into small pieces • NO visible motion

  4. MECHANICAL WEATHERING • Ice (frost wedging) • water expands when freezes • angular pieces

  5. MECHANICAL WEATHERING • Sheeting(exfoliation) • pressure is removed from above • Fractures “peel” off

  6. Half-dome

  7. MECHANICAL WEATHERING • Other types • burrowing animals • Plant roots • Mud cracks

  8. When water evaporates- mud shrinks Mudcracks

  9. CHEMICAL WEATHERING • Decomposition • chemical change takes place

  10. CHEMICAL WEATHERING • Hydrolysis • reacts with acid/water to form clays • feldspar + carbonic acid + water clay + soluble minerals • common in granite

  11. CHEMICAL WEATHERING • DISSOLUTION ANY CARBONATE + CARBONIC ACID CALCIUM CARBONATE (soluble) • common in limestone • creates caves and sinkholes

  12. Parthenon, Greece

  13. sinkholes

  14. Sinkhole formation

  15. Areas prone to sinkholes

  16. Dissolution • Marble statue

  17. CHEMICAL WEATHERING • OXIDATION • reacts with O2 • Groundwater with Fe is powerful agent • minerals with high Fe content • hematite, limonite, olivine • intense in tropical climates

  18. Oxidation of basalt

  19. Pictured Rocks, MI

  20. PLANES OF WEAKNESS • WHERE ROCKS WILL BREAK • Joints- vertical fractures • bedding planes- horizontal fractures • Granular disintegration- cement in clastic rocks breaks down

  21. joints

  22. BEDDING PLANES

  23. Granular disintegration

  24. ROCK TYPES • Granite - exfoliation, hydrolysis (k-spar to clay) • quartz doesn’t weather • Basalt- chemical (oxidation) • Sandstone- granular disintegration • limestone- dissolution • shale- breaks down into clay

  25. Sandstone tombstone

  26. Granite

  27. Which rocks weather most rapidly? • sedimentary

  28. Which rocks are most resistant to weathering? • Igneous / metamorphic (exception?) • Bowen’s reaction series • Olivine most

  29. Differential weathering • Different rock types weather differently • OR • Different rates of weathering due to exposure

  30. Stairway to heaven, CO

  31. Bryce Canyon, UT

  32. arches

  33. Differential erosion limestone shale

  34. Hoo-doos

  35. CLIMATE AND WEATHERING • Chemical- warm and moist • Physical- freeze/thaw cycle

  36. CLIMATE • TROPICAL • Strong chemical • DESERT • Slight mechanical • POLAR • Slight mechanical • MID LATITUDE (MI) • Strong chemical and mechanical
