Presentation Transcript


Neuron nervous system

Neuron & Nervous System

http://biodeluna.wordpress.com


Image from http protomag com assets fertile ground

image from http://protomag.com/assets/fertile-ground


The stimulus response pathway

The Stimulus-Response Pathway

http://www.vce.bioninja.com.au/aos-2-detecting-and-respond/coordination--regulation/nervous-system.html


Neuron nervous system

"Como hay talentos

por el estudio,

hay tontos entontecidos por desuso."


Neuron nervous system

Give 3 examples of Receptors:


Neuron nervous system

Give 3 examples of Recpetors:


Neuron nervous system

Las ideas no duran mucho. Hay que hacer algo con ellas.


Give 3 examples of effectors

Give 3 examples of Effectors :

(Effectors are parts of the body that produce a response)

http://arturogoicoechea.wordpress.com/2010/05/24/neuronasneurons/


Give 3 examples of effectors1

Give 3 examples of Effectors :

(Effectors are parts of the body that produce a response)

  • a muscle contracting to move an arm

  • a muscle squeezing saliva from the salivary gland

  • a gland releasing a hormone into the blood


Neuron nervous system

Lo peor no es cometer un error, sino tratar de justificarlo, en vez de aprovecharlo como aviso providencial de nuestra ligereza o ignorancia.


Nervous system

Nervous System


Neuron nervous system

  • The central nervous system is comprised of the brain and spinal cord.

  • The peripheral nervous system includes all peripheral nerves.


C n s

C.N.S.

  • Cerebrum

  • Cerebellum

  • Brain stem


Name the two structures which make up the central nervous system

Name the two structures which make up the central nervous system.


Name the two structures which make up the central nervous system1

Name the two structures which make up the central nervous system.

  • The central nervous system consists of the brain and

    spinal cord.


Nerves

Nerves

  • Nerves → Collections of neurons that are joined together by connective tissue.


The neuron

The Neuron

  • The basic functional unit of the nervous system.


Neuron nervous system

(Petilla de Aragón, Navarra, 1 de mayo de 1852 - Madrid, 17 de octubre de 1934)

Santiago Ramón y Cajal (Petilla de Aragón,1 May 1852 – Madrid 18 October 1934)

Spanish pathologist, histologist, neuroscientist, and Nobel laureate in 1906

Education at: Universidad de Zaragoza (1873


Function

Function:

  • Send impulses to and from the Central Nervous System and Peripheral Nervous System and the effectors (muscles/glands)


Neuron nervous system

  • Dendrite→ Fine hair-like extensions on the end of a neuron.

    • Function: receive incoming stimuli.

  • Cell Body or Soma → The control center of the neuron.

    • Function: Directs impulses from the dendrites to the axon.

  • Nucleus → Control center of the Soma.

    • Function: Tells the soma what to do.

  • Axon→ Pathway for the nerve impulse (electrical message) from the soma to the opposite end of the neuron.

  • Myelin Sheath → An insulating layer around an axon, It is made up of Schwann cells.

  • Nodes of Ranvier → Gaps between schwann cells.

    • Function: Saltatory Conduction (Situation where speed of an impulse is greatly increased by the message

      ‘jumping’ the gaps in an axon).


Types of neurons

Types of Neurons


Neuron nervous system

  • (a) The nerve fibres which carry impulses from the sense organs to the central nervous system are called …..….. fibres.

  • (b) The nerve fibres which carry impulses from the central nervous system to the glands and muscles are called …..….. fibres.


Sensory

sensory

  • (a) The nerve fibres which carry impulses from the sense organs to the central nervous system are called …..…..... fibres.

  • (b) The nerve fibres which carry impulses from the central nervous system to the glands and muscles are called ……..….. fibres.


Sensory1

sensory

  • (a) The nerve fibres which carry impulses from the sense organs to the central nervous system are called …..…..... fibres.

  • (b) The nerve fibres which carry impulses from the central nervous system to the glands and muscles are called ……..….. fibres.

motor


Neuron nervous system

Complete the passage below, selecting the appropriate words from the list below.sensory, nerve fibre, cell body, impulses, dendrons, dendrites, motor, contact, axons, synapses, cytoplasm

A neurone (nerve cell) consists of a ….. A ….. containing a nucleus surrounded by ….. B ….. Branching filaments, called ….. C ….., extend from the cell surface and make ….. D ….., with other neurones. In ….. E ….. and ….. F ….. neurones, one of the filaments is very long and is called …… G …..


Neuron nervous system

Complete the passage below, selecting the appropriate words from the list below.sensory, nerve fibre, cell body, impulses, dendrons, dendrites, motor, contact, axons, synapses, cytoplasm

A neurone consists of a cell body(A) containing a nucleus surrounded by cytoplasm (B).

Branching filaments, called dendrites(C), extend from the cell surface and make synapses(D) with other neurones. In sensory(E) and motor(F) neurones, one of the filaments is very long and is called a nerve fibre(G).


Transmission of signals

Transmission of signals


The synapse

The Synapse

  • The junction between two neurons is called a ________________, it forms a physical ______ between the pre-synaptic and post-synaptic neurons

  • An action potential (__________signal) cannot cross the synaptic gap, so it triggers the release of chemicals (______________) to continue the signal


The synapse1

The Synapse

  • The junction between two neurons is called a Synapseit forms a physical Gapbetween the pre-synaptic and post-synaptic neurons

  • An action potential (Electricalsignal) cannot cross the synaptic gap, so it triggers the release of chemicals (Neurotransmitters) to continue the signal


Neurotransmitters

Neurotransmitters

Neurotransmitters are endogenous chemicals that transmit signals from a neuron to another cell across a synapse.


Neuron nervous system

Overview of Synaptic Transfer

http://www.vce.bioninja.com.au/aos-2-detecting-and-respond/coordination--regulation/nervous-system.html


Neuron nervous system

Nada me inspira más veneración y asombro que un anciano que sabe cambiar de opinión.


Reflex arc

Reflex arc


Give 3 examples of reflex actions

Give 3 examples of reflex actions.


Give 3 examples of reflex actions1

Give 3 examples of reflex actions.

  • change in size of the pupil of the eye in response to light intensity,

  • blinking in response to foreign particles on the cornea,

  • coughing or sneezing in response to irritation of the nasal passages and trachea or bronchi,

  • knee jerk in response to a blow on the tendon of the leg extensor muscle,

  • rapid removal of the hand from a hot or sharp object

    (any three)


Neuron nervous system

De todas las reacciones posibles ante una injuria, la más hábil y económica es el silencio.


Neuron nervous system

http://www.bbc.co.uk


Which one is a

Which one is a …?

motor neuron

interneuron

sensory neuron

a)b)C)


Neuron nervous system

Consists of: Brain and Spinal Cord

Cerebrum

brain

Cerebellum

Medulla Oblongata

Spinal Cord


Neuron nervous system
