Presentation Transcript

Slide2 l.jpg

Pongsak Chaisuparasmikul, Raymond J Clark, Robert J Krawczyk

College of ArchitectureIllinois Institute of Technology

ISES 2003 Solar World CongressGvteborg, Sweden June 14-19, 2003.


Slide3 l.jpg

KEY ISSUES IN SOLAR ENERGY PREDICTION MODEL

  • Building consumes 35% of total energy consumption.

  • Need the simplified method and tool for solar heating, cooling, and

    daylighting during the schematic design process.

  • Modelling becomes the major issue of providing knowledge based information for

    designing solar energy efficient buildings.

  • Measurable digital studying of the approximate method for the solar energy.

  • Ability to identify the potential and problems related the functions and parameters.

  • Addressing the issues of development the model into the software.


Slide4 l.jpg

ABOUT THIS RESEARCH

  • Looking at the building solar cooling model (which is more important for the office

    buildings in the U.S.A.)

  • Finding could be iterative and alternative solutions, during the conceptual design

    process.

  • Dealt with the interactive process, many unknown variables, energy approximation

    and probability model.


Slide5 l.jpg

OBJECTIVES

  • Create the solar cooling prediction models or equations.

  • Find the approximate methods for the measurement of the solar heating, cooling and daylighting.

  • Study the solar energy model without having to use the complicated building energy design software.

  • Providing a mean of simplifying the calculation of solar cooling.


Slide6 l.jpg

METHODOLOGY

  • Wrote the source code program to create the DOE-2 input simulation from the nested loop to generate the meaningful data for the multiple parameters.

  • Assessment the influencial data from each of the parameters resulted from the DOE-2 simulation.

  • Sensitivity analysis and correlation methods were used to select the most significant design variables.

  • Regression procedure was using SPSS statistical software tp conduct and identify the principal form of relationships.

  • Data from these selected parameters were generated for developing the multiple non-linear regression models (least square models) that can fit into the linear regression models.

  • Multiple linear regressions were performed to derive the prediction model to obtain the best-fit equations.


Slide7 l.jpg

MODULE

  • The module was developed as a simulation input model for the DOE-2 processor.

  • Intelligent module worked as an environmental interaction building (space, size,

    envelope materials, temperature, condition), and can be programmed as any the

    building types).

  • Module concept was derived from the finite element theory (Raymond J. Clark)

  • Any building forms or geometries can be approximately studied if they were divided into the smallest workable parts.

  • Work well in studying the relative probability of influential parameters that are affected from the solar energy.


Slide8 l.jpg

MODULE

  • Module size: 15 ft x 15 ft (4.50 m x 4.50 m) 14ft (4.20 m) floor to floor high,

  • 10 ft (3.00 m) floor to ceiling high.

  • Climate Location: Chicago, Illinois, USA.

  • Weather file: TRY (Test Reference Year)

  • Sample

  • Module schedule used the typical office-building schedule.

  • Module wall, floor, partition, ceiling, and roof used the typical office building: size, material, transmission U-value, insulation.

  • Control strategies: temperature, light (1.2W/m²), daylight, ventilation rate, number of people and equipment.

  • Day-lighting schedule:

    From 8.00am-6pm each day into the middle of the window façade, 5 ft (1.52 m) deep to the inside, 3 ft (0.91 m) above the floor.

  • Infiltration rate 0.06 cfm per window perimeter.



Slide10 l.jpg

MODULE

Pongsak Chaisuparasmikul, Raymond J Clark, Robert J Krawczyk

College of ArchitectureIllinois Institute of Technology

ISES 2003 Solar World CongressGvteborg, Sweden June 14-19, 2003.


Slide11 l.jpg

MODULE

Pongsak Chaisuparasmikul, Raymond J Clark, Robert J Krawczyk

College of ArchitectureIllinois Institute of Technology

ISES 2003 Solar World CongressGvteborg, Sweden June 14-19, 2003.


Slide12 l.jpg

DESIGN PARAMETERS

  • Deterministic

  • Variability


Slide13 l.jpg

DESIGN PARAMETERS

  • Orientation: 8 orientation;

    north, north-east, east, south-east, south, south-west, west, north-west.

  • Fenestration: 4 window to wall ratio

    40%, 50%, 60%, 80%.

  • Glass types: 8 glass types;

    Monolithic clear & tinted; Insulated clear & tinted; Low-E clear, tinted, green, reflective

  • Overhang shading: 4 overhangs shading ratio;

    none, 25%, 50%, 0.75%

  • Fin shading: 4 fins shading ratio;

    none, 25%, 50%, 75%


Slide15 l.jpg

SIMULATION MODEL

  • Customized input model

  • Interactive and interfacing model with program Front end software

  • Library entry data

  • Programming the model

  • Parametric analysis was assessed to obtain the most influential of each design

    variables to the annual solar heating.


Slide16 l.jpg

Solar radiation: variation of solar radiation assessment is considered as a probability

Module with

The design parameters

Module as a finite element black box

Customized Input Model

SIM File

SUM File

DOE-2 Simulation

49,135 runs

Regression procedure to identify the principal form of relationships

Sensitivity analysis and correlation method to select the most significant design variables.

Parametric analysis to obtain the most influential variables

Testing the model

Multiple non-linear regression

models fit on linear regression

model

Prediction Model

Form of equations


Slide17 l.jpg

Solar radiation: variation of solar radiation assessment is considered as a probability

Module with

The design parameters

Module as a finite element black box

Customized Input Model

SIM File

SUM File

DOE-2 Simulation

49,135 runs

Regression procedure to identify the principal form of relationships

Sensitivity analysis and correlation method to select the most significant design variables.

Parametric analysis to obtain the most influential variables

Testing the model

Multiple non-linear regression

models fit on linear regression

model

Prediction Model

Form of equations


Slide18 l.jpg

Solar radiation: variation of solar radiation assessment is considered as a probability

Module with

The design parameters

Module as a finite element black box

Customized Input Model

SIM File

SUM File

DOE-2 Simulation

49,135 runs

Regression procedure to identify the principal form of relationships

Sensitivity analysis and correlation method to select the most significant design variables.

Parametric analysis to obtain the most influential variables

Testing the model

Multiple non-linear regression

models fit on linear regression

model

Prediction Model

Form of equations


Slide19 l.jpg

Solar radiation: variation of solar radiation assessment is considered as a probability

Module with

The design parameters

Module as a finite element black box

Customized Input Model

SIM File

SUM File

DOE-2 Simulation

49,135 runs

Regression procedure to identify the principal form of relationships

Sensitivity analysis and correlation method to select the most significant design variables.

Parametric analysis to obtain the most influential variables

Testing the model

Multiple non-linear regression

models fit on linear regression

model

Prediction Model

Form of equations


Slide20 l.jpg

Solar radiation: variation of solar radiation assessment is considered as a probability

Module with

The design parameters

Module as a finite element black box

Customized Input Model

SIM File

SUM File

DOE-2 Simulation

49,135 runs

Regression procedure to identify the principal form of relationships

Sensitivity analysis and correlation method to select the most significant design variables.

Parametric analysis to obtain the most influential variables

Testing the model

Multiple non-linear regression

models fit on linear regression

model

Prediction Model

Form of equations


Slide21 l.jpg

Solar radiation: variation of solar radiation assessment is considered as a probability

Module with

The design parameters

Module as a finite element black box

Customized Input Model

SIM File

SUM File

DOE-2 Simulation

49,135 runs

Regression procedure to identify the principal form of relationships

Sensitivity analysis and correlation method to select the most significant design variables.

Parametric analysis to obtain the most influential variables

Testing the model

Multiple non-linear regression

models fit on linear regression

model

Prediction Model

Form of equations


Slide22 l.jpg

PARAMETRIC ANALYSIS: TREND OF DISTRIBUTION considered as a probability

Solar heating and cooling curve


Slide23 l.jpg

PARAMETRIC ANALYSIS: TREND OF DISTRIBUTION considered as a probability

Solar daylighting curve


Slide24 l.jpg

PARAMETRIC ANALYSIS: TREND OF DISTRIBUTION considered as a probability

Solar cooling peaks in June, July, or August

Solar heating peaks in December, or January


Slide25 l.jpg

SENSITIVITY ANALYSIS AND CORRELATION: SPREE PLOT considered as a probability

** Correlation is significant at the 0.01 level (2-tailed).


Slide26 l.jpg

SENSITIVITY ANALYSIS AND CORRELATION: SPREE PLOT considered as a probability

Significant 5 variables


Slide27 l.jpg

RESULTS considered as a probability

Mean was closer

than median

Histogram

Scattered outliers

Scattered Curve Fit


Slide28 l.jpg

RESULTS considered as a probability

Data Residual Identification

Solar cooling

“S” distribution

Solar heating

“S” distribution with a significant on line plotted for both of the prediction model


Slide29 l.jpg

RESULTS considered as a probability

Regression Line

R² = 0.21

R² = 0.46 use Variable addition & multiplication

R² = 0.79 use Z transform; Z transform = X - Mean

Estimator of scattered data from regression line

Std = 1 , Mean = 0

Comparison the predicted value and standard residual with DOE-2 simulation

“S” distribution with a significant on line plotted for both of the prediction model


Slide30 l.jpg

RESULTS considered as a probability

Regression Model after Z transform

a Predictors: (Constant), Standardized Residual

b Predictors: (Constant), Standardized Residual, Standardized Predicted Value

c Dependent Variable: COOLING


Slide31 l.jpg

FORM OF THE MODEL considered as a probability

  • Form of equation was polynomial probability distribution.

  • The variables were transformed (multiplication) one by one, and add new variables into the

    equations.

  • Y=(0.254OR+0.065FN)-(0.025OR²+0.004GL²+0.008OH²)+(0.044OR*WR-0.005OR*GL-

    0.034OR*OH-0.010OR*FN)-(0.002OR*WR*GL+0.003OR*WR*OH+0.003OR*WR*FN-

    0.003OR*GL*OH-0.006OR*OH*FN+0.002GL*OH*FN) ____Least Square Line-1

  • Y=(0.108WR-0.087GL-0.343OH)+(0.023OH*GL)+(0.048OH²-0.003OH²*WR-0.003OH²*GL)

    ____Least Square Line-2

  • Y=(0.216WR-0.147OH-0.125FN)-(0.141OH*GL) ____Simplified Model

Where Y= Maximum solar heat gain;

OR=Orientation;

WR=Window to wall ratio;

GL=Glass types;

OH= Overhang shading;

FN =Fin shading.


Slide32 l.jpg

VALIDATION: TESTING THE MODEL considered as a probability

  • The valid testing of this model was conducted to see how this model was deviated from the

  • standard errors and compared with DOE-2 simulation results

  • The test had “S” distribution with a significant line plotted

  • Y(Model) – Y(DOE-2) : Model deviated from standard error

    N-2


Slide33 l.jpg

CONCLUSIONS considered as a probability

  • The results were to find the best-predicted value of Y (solar cooling energy) that

    respond well to the changing of the combination of design parameters X variables

  • The model was in the form of quadratic and cubic equations

  • Testing of this model was proposed to see how these models were deviated from

    the standard error and compared with DOE 2 results.

  • These methods were able to include all of the envelope design parameters.

  • The equation models can be developed to provide the effective simplified tools for

    solar cooling.

  • Future research include using these models in the measurement and verifiction of

    Midwest Chicago Green Technology Project.


Slide34 l.jpg

THANK YOU FOR BEING HERE considered as a probability

FOR MORE DETAILED INFORMATION PLEASE SEE MY PAPER NO. 06 22

OR YOU CAN CONTACT ME AT

EMAIL: [email protected]

WEBSITE: www.iit.edu/~chaipon/


ad
