Presentation Transcript
Fluorescence and transmittance spectrophotometer measurements l.jpg

Fluorescence and Transmittance Spectrophotometer Measurements

Donna Kubik

02/04/04


Measurements l.jpg
Measurements Measurements

  • The goal was to measure and compare the emission spectra and transmittance of the three types of scintillators tested for the DHC plus the MINOS scintillator

  • All samples were machined to the same thickness

    • BC 408

      • Cast scintillator

    • EJ 200

      • Cast scintillator

    • FNAL/NICADD

      • Extruded scintillator

    • MINOS

      • Extruded scintillator


Fluorescence l.jpg
Fluorescence Measurements

  • Used an Hitachi F-4500 fluorescence spectrophotometer

    (at Lab 6, FNAL)

    • 1nm resolution

    • 200nm-730nm range

    • Xenon lamp

Hitachi F-4500


Fluorescence spectrophotometer modes of operation l.jpg
Fluorescence spectrophotometer: Measurementsmodes of operation

Frontside illumination

Backside illumination

~300 nm

~300 nm

mirror

scintillator

scintillator


Absorption transmission l.jpg
Absorption/transmission Measurements

  • Used an HP UV-Vis Diode-Array Spectrophotometer

    (at Lab 6, FNAL)

    • 2nm resolution

    • 190nm-820nm range

    • Deuterium lamp

      • Covers UV and Vis

HP 8452A Diode Array Spectrophotometer


Absorption transmission spectrophotometer operation l.jpg
Absorption/transmission Measurementsspectrophotometer: operation

Deuterium

lamp

Dispersion device

Slit

Scintillator

Diode array


Fluors l.jpg
Fluors Measurements

  • Instead of using the same fluors as used in the cast scintillators, different (less costly) fluors were used to fabricate the MINOS and FNAL extruded scintillators

  • The MINOS and FNAL scintillators were designed so that the final emission peak is similar to that of BC408 and EJ200, all of which must be compatible with WSF.


Fluors8 l.jpg
Fluors Measurements

  • The following slides show:

    • The emission peaks for the cast scintillators

      • PT 350nm

      • Bis-MSB 420nm

  • The emission peaks for the extruded scintillators

    • PPO 365nm

    • POPOP 420nm


Slide9 l.jpg

1 Measurementsst harmonic of the

Excitation wavelength

Excitation wavelength


Fluors10 l.jpg
Fluors Measurements

  • The 365nm and 420nm (for PPO and POPOP) are the emission maxima for each compound.  The remaining bands are part of the PPO and POPOP spectrum.

  • For PPO and POPOP there are roughly 3 peaks for each, one at each side of the maximum, but it’s difficult to see, because there is a lot of overlap in the middle.

  • It is easier to see in the PT and bis-MSB samples, because the two spectra do not overlap as in the case of PPO and POPOP.


Superimpose frontside and backside emission l.jpg
Superimpose frontside and backside emission Measurements

  • Note that, for each sample, the peaks from the backside illumination are at the same wavelength as the longest- wavelength peaks from frontside illumination,

    ~420nm.

  • Zoom on next slide


Slide14 l.jpg

~420nm Measurements

~420nm


Emission spectra l.jpg
Emission spectra Measurements

  • The emission for BC408 and EJ200 are the same, ~422nm

  • Although the chemistry of the FNAL and MINOS scintillators is the same, there is a small difference in the wavelength of maximum emission, 417.6nm vs. 419.8nm

  • Zoom on next slide


Transmittance spectra l.jpg
Transmittance spectra Measurements

  • The difference in emission peaks between the FNAL and MINOS scintillator may be explained by the difference in absorption/transmittance

  • To remove the surface effects due to the different finish quality of each sample, the transmittance spectra were corrected to 100% transmittance at 820nm (because we know that there isno absorption at long wavelengths)


Slide18 l.jpg

Peaks may be due to D Measurements2

Halpha= 656.3nm

Absorbed by polystyrene


Emission and transmittance spectra l.jpg
Emission and transmittance spectra Measurements

  • The next 3 slides show the emission spectra superimposed on the transmittance spectra

  • The first shows all of the measured spectra

  • The next 2 slides zoom in on the onset of transmission, revealing that transmission for the FNAL scintillator begins at a slightly shorter wavelength than the other scintillators


Emission spectra24 l.jpg
Emission spectra Measurements

  • The measurements are consistent with the BC408 and EJ200 data sheets
