  1. Query Interfaces fora 3D Model Search Engine Patrick Min Tom Funkhouser, Misha Kazhdan, Joyce Chen, Alex Halderman, David Dobkin, David Jacobs DLI2 meeting, Edinburgh, 25 June 2002

  2. Online Data • On-line multimedia data is changing the way we get and use information Registered Saddlebred out of Famous Sultan Supreme line. 100% sound. 16 year old, flashy, chestnut w/white, loving, high energy horse, needs experienced rider. Was shown professionally in early years as gaited saddlebred. Most recently shown and always placed in training and first level dressage shows.Currently used as dressage/pleasure horse, jumps, loves trailriding. www.dreamhorse.com Text 2D Image Audio What about 3D Models?

  3. 3D Models are becoming easier to create, use and distribute

  4. Cyberware Scanner 3D Models are becoming easier to create, use and distribute • Laser range scanners: supply

  5. Georgia Tech Cyberware Scanner Protein Data Bank Large Model Archive 3D Models are becoming easier to create, use and distribute • Laser range scanners: supply • Fast graphics cards: demand • World Wide Web: distribution

  6. 3D Models are becoming easier to create, use and distribute • Laser range scanners: supply • Fast graphics cards: demand • World Wide Web: distribution One day 3D models will be as ubiquitous as images are now Georgia Tech Cyberware Scanner Protein Data Bank Large Model Archive

  7. Digital Michelangelo ProjectStanford Graphics Laboratory Research Challenges Current research: • How do we construct 3D models ?

  8. Digital Michelangelo ProjectStanford Graphics Laboratory Research Challenges Future research: • How do we find 3D models ? • How do we understand them ? Current research: • How do we construct 3D models ?

  9. car Finding 3D Models

  10. Project Goal A Search Engine for 3D Models on the Web car

  11. 3D Model Search Engine World Wide Web Crawler Repository of 3D Models Crawler Indexer Crawler Crawler Off-line Text Index 2D Index 3D Index On-line Query QueryInterface Text Matcher 2D Matcher 3D Matcher User Matches

  12. 3D Model Search Engine Acquisition World Wide Web Crawler Repository of 3D Models Crawler Indexer Crawler Crawler Off-line Text Index 2D Index 3D Index On-line Query QueryInterface Text Matcher 2D Matcher 3D Matcher User Matches

  13. 3D Model Search Engine Analysis World Wide Web Crawler Repository of 3D Models Crawler Indexer Crawler Crawler Off-line Text Index 2D Index 3D Index On-line Query QueryInterface Text Matcher 2D Matcher 3D Matcher User Matches

  14. 3D Model Search Engine World Wide Web Crawler Repository of 3D Models Crawler Indexer Crawler Crawler Off-line Text Index 2D Index 3D Index On-line Query QueryInterface Text Matcher 2D Matcher 3D Matcher User Matches Matching

  15. 3D Model Search Engine World Wide Web Crawler Repository of 3D Models Crawler Indexer Crawler Crawler Off-line Text Index 2D Index 3D Index On-line Query QueryInterface Text Matcher 2D Matcher 3D Matcher User Matches Querying

  16. 3D Model Search Engine Analysis World Wide Web Crawler Repository of 3D Models Crawler Indexer Crawler Crawler Off-line Text Index 2D Index 3D Index On-line Query QueryInterface Text Matcher 2D Matcher 3D Matcher User Matches Querying Matching

  17. Main Challenge & today's topic Which Query Interfaces are Useful for a 3D Model Search Engine? Query QueryInterface User Matches

  18. Desired Properties of Query Interfaces • easy to use • also for novice users • possible to quickly specify query • efficient matching method • effective • high number of relevant results

  19. Available Data for Queries Example of a 3D Model available on the Web: http://www.3dspline.com

  20. Available Data for Queries Text Shape Appearance

  21. Available Data for Queries Text Shape Appearance

  22. Text Queries

  23. Text Queries +easy to use + possible to quickly specify query + efficient matching method +/- effective

  24. Effective Text Queries 747 dna caffeine dog fork

  25. Text Query Problems • objects are badly annotated: • ferrar03.3ds, ferrair, rahmen, … • keywords are too common • face, plane

  26. Text Query Problems • objects are badly annotated: • ferrar03.3ds, ferrair, rahmen, … • keywords are too common • face, plane • keywords are unknown to user, or annotator • not possible to anticipate every relevant text query • elf, fairy-tale creature, puppet, person, ...

  27. Text Query Problems We hypothesize shape can help • objects are badly annotated: • ferrar03.3ds, ferrair, rahmen, … • keywords are too common • face, plane • keywords are unknown to user, or annotator • not possible to anticipate every relevant text query • elf, fairy-tale creature, puppet, person, ...

  28. Outline • Introduction • Text Queries • 3D Shape Queries • 2D Shape Queries • Results • Conclusions • Future Work

  29. 3D Shape Queries use 3D shape to find 3D shape

  30. 3D Model Queries • (create &) upload 3D model • select 3D model on results page ("shape iteration")

  31. 3D Matching Method

  32. 3D Matching Method

  33. Shape Iteration User Study

  34. Shape Iteration User Study • Test Design: • 18 students in an introductory CS class • input: on website, initial text keyword search, then “find similar object” • where similar means similar text or similar shape (unknown to user) How does shape combine with text in interactive searches?

  35. Shape Iteration Results • shape iteration finds target object more often • in fewer iterations and in less time Similarity

  36. 3D Model Query Problems • upload 3D model: • such a model may not be available • creating one with standard tools is hard • shape iteration: • have to get such a result first

  37. 3D Sketch Queries • Sketch 3D model using simple modeling program • e.g. Teddy, Sketch Teddy: A Sketching Interface for 3D Freeform Design Igarashi et al., SIGGRAPH 1999

  38. 3D Sketch Queries Teddy: A Sketching Interface for 3D Freeform Design Igarashi et al., SIGGRAPH 1999

  39. Teddy Sample Results

  40. 3D Sketch Query Problems Teddy: • supports only coarse, blobby shapes of genus 0 • still hard to use for novice users

  41. 3D Sketch Query Properties -easy to use - possible to quickly specify query + efficient matching method +/- effective So we need a simpler query interface

  42. 2D Sketch Queries

  43. 2D Sketch Queries • “paintbrush” style interface: • simple outline sketches • easy to use for most users

  44. Multiple 2D Sketches

  45. 2D Sketch Matching Method 5 6 3 4 7 1 2 Query sketch 7 projections per database model

  46. 2D Sketch Matching Method • compute 2D shape descriptor in similar fashion • intersect with circles instead of spheres

  47. 2D Sketch User Study

  48. 2D Sketch Interface User Study Does shape add to text? • Test design: • 43 students in introductory CS class • goal: retrieve target objects • input: text keywords and sketches on paper

  49. Example Input

  50. Distinguishing keywords: • text works well • even better with sketch 2D Sketch User Study Results
