Elastic properties of solids

-Elastic Properties of Solids

AP Physics C

Mrs. Coyle



Elastic properties of solids1
Elastic Properties of Solids influence of an external force.

  • Length (Tensile Stress- Strain)

  • Shape (Shear Stress-Strain)

  • Volume (Bulk Stress-Strain)


Elasticity of length characteristics
Elasticity of Length- Characteristics influence of an external force.

  • Tensile Strain=

Tensile Stress=F/A


Elasticity in length
Elasticity in Length influence of an external force.

  • Tensile Stress = Y x Tensile Strain

  • Y is known as Young’s Modulus

  • Units of Y are N/m2


Tensile strength test
Tensile Strength Test influence of an external force.

  • Tensile Strength Sample


Ex 30
Ex: #30 influence of an external force.

  • A steel wire of diameter 1mm can support a tension of 0.2kN. A cable to support a tension of 20kN should have a diameter of what order of magnitude?

  • Ans: 1cm


Elasticity in shape shear stress f a
Elasticity in Shape - influence of an external force.Shear Stress= F / A


Example shear stress
Example: Shear Stress influence of an external force.

http://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm


http://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtmhttp://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm


Shear stress and shear strain
Shear Stress and Shear Strainhttp://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm

S is the Shear Modulus,

Unit : N/m2


Ex 33
Ex: #33http://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm

If the shear stress in steel exceeds 4.00x108 N/m2

the steel ruptures.

a)Determine the shearing force necessary to shear a steel bolt 1.00cm in diameter.

Ans: a) 3.14x104 N


Ex 33 cont d
Ex: #33 cont’dhttp://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm

b)Determine the shearing force necessary punch a 1.00cm diameter hole in a steel plate 0.500cm thick.

Ans: b) 6.28x104 N


Elasticity in volume
Elasticity in Volumehttp://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm

B is the Bulk Modulus

Unit: N/m2


  • Note that http://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtmΔF/A is pressure.


Ex 35
Ex:#35http://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm

When water freezes, it expands by about 9%.

What pressure increase would occur inside your automobile engine block if the water in it froze?

(The bulk modulus of ice is 2.00x109 N/m2 )

Ans: 1.65 x 108 N/m2


Explaining the inertia ball tensions
Explaining the inertia ball tensions.http://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtm


  • How is http://www.fema.gov/plan/prevent/earthquake/fema74/chapter2_2.shtmΔL affected when you have two same springs in series or in parallel pulled by the same force?
