Presentation Transcript


Snmp simple network management protocol haris ribic

SNMPSimple Network Management ProtocolHaris Ribic


Objectives

Objectives

  • History

  • What is SNMP?

    • Management Station

    • Management Agent

    • Management Information Base

    • Network Management Protocol

  • How does SNMP work?

  • Architecture

  • Bibliography


History

History

  • Networks became vital and more complicated

    • Cannot be managed by human effort alone

  • Simple Gateway Monitoring Protocol (SGMP)

    • Did not work with equipment from different vendors

  • Internet Activities Board (IAB) - Network Management System

    • Need for an automated management tool for TCP/IP network and Internet

    • Standards required to allow multi-vendor networks

    • View the entire network as a unified architecture

    • Single operator interface

    • Powerful, user friendly command set

  • SNMP - RFC 1067 - August 1988

    • J. Case

    • M. Fedor

    • M. Schoffstall

    • J. Davin


What is snmp

What is SNMP?

  • Network management software for networks operating TCP/IP model

    • Application Layer TCP/IP - OSI

    • Variety of Operating Systems

  • SNMP network management - 4 key elements

    • Management Station

    • Management Agent

    • Management Information Base

    • Network Management Protocol

  • Simple Network Management Protocol version 1 (SNMPv1)

    - Protocol that enables a management station to configure, monitor network devices

  • Simple Network Management Protocol version 2 (SNMPv2)

    - Update provides additional administrative structure, authentication, and privacy

    - SNMPv1 and SNMPv2 are incompatible

  • Simple Network Management Protocol version 3 (SNMPv3)

    - Update provides additional security and administrative capabilities


Management station

Management Station

  • Standalone device or part of a shared system

  • Interface for human network manager

  • Has management applications

  • Interface to monitor and control network

  • Platforms, such as hosts, bridges, routers, and hubs

  • Equipped with agent software so they can be managed

  • Responds to requests for information

  • Responds to requests for action

  • Asynchronously supply important but unsolicited information

  • Management Agent


Snmp simple network management protocol haris ribic

  • Management Information Base (MIB)

  • Representation of network resources as objects

  • Each object is a data variable that represents one aspect of managed agent

    • Standardized across system

  • Collection of objects is referred to as a MIB

    • Collection of access points for the management station

  • Management station

    • Retrieves values of MIB objects to provide monitoring

    • Sets MIB object values to change configuration

  • Link between management station and agent

    • TCP/IP uses SNMP

    • SNMPv2 for OSI & TCP/IP

  • Key capabilities

    • get - management station retrieves value

    • set - management station sets value

    • notify - agent sends event notification

  • Network Management Protocol


How does snmp work

How does SNMP work?

  • Network management software

    • Controls devices connected to a network

    • Manages performance, solves problems, optimizes network

    • Firewall

  • Community

    • Devices store information about the community

    • Command input limited to certain machines

    • MIB contains communication information

      • Protocols

      • Device identifications


Snmp architecture

SNMP Architecture

  • Application-level protocol of the TCP/IP model

  • Operates on top of UDP

  • Typical configuration:

    • Standalone management station

      • Manager process controls access to a central MIB

      • Provides an interface to the network manager

    • SNMP, UDP, IP and network dependent protocol (Ethernet, ATM)

      • Each agent must be implemented same way


Snmp architecture1

SNMP Architecture

  • Closer look:

    • Management station issues 3 messages

    • All 3 are acknowledged by the agent

    • May issue a trap message - something undesirable happens

  • Relies on UDP - connectionless protocol

    • No ongoing connections are maintained

    • Each exchange is a separate transaction


Bibliography

Bibliography

Pictures:

Stallings, William. Data and Computer Communications. 8th ed. New Jersey: Pearson Prentice Hall, 2007. 760-771.

Information:

Stallings, William. Data and Computer Communications. 8th ed. New Jersey: Pearson Prentice Hall, 2007. 760-771.

"Cisco Documentation." cisco.com. 12 Oct. 2006. Feb. 2008 <http://www.cisco.com/univercd/cc/td/doc/cisintwk/ito_doc/snmp.htm>.

"Simple Network Management Protocol." Wikipedia. 10 Jan. 2008. Feb. 2008 <http://en.wikipedia.org/wiki/Simple_Network_Management_Protocol#SNMP_basic_components>.


Snmp simple network management protocol haris ribic

Q?A!
