Presentation Transcript


Slide1 l.jpg

Caspian Sea water level fluctuation: comparison between ground

Measurement and altimetry

M Bolgov

R Mammedov

J-F Crétaux

M. Bergé-Nguyen

A. Kouraev


Slide2 l.jpg

Destruction of a coastal zone in northern coast of Azerbaijan as a result of rise of a sea level.


Caspian sea level fluctuation problem l.jpg

Caspian Sea level fluctuation problem

Peculiarities of the variability of the Caspian Sea level

The variability of the Caspian Sea level can be classified on cycles:

  • Geological period,

  • Historical period,

  • Yearly change,

  • Seasonal change.


Slide4 l.jpg

Variability of the Caspian Sea level for historical period: 1-Historical period, 2-Average tendency its, 3-Frequency of repetition, 4-Average tendency, 5-Level maximum, 6-Level minimum.


Slide5 l.jpg

Annual levels of the Caspian Sea measured in the Baku post.

1-measured level, 2- tendencies of changing. In the framework seasonal changing level is shown.


Slide6 l.jpg

Reasons for changes in sea level

Geological factors

Anthropogenic factors

Hydroclimatic factors


Slide7 l.jpg

CASPIAN SEA DATA BASE


Slide8 l.jpg

Water mass balance estimation

The balance of water in the Caspian Sea is determined by the following contributory factors:

1) surface river flow into the sea;

2) precipitation over the surface of the sea;

3) underground flow into the sea;

4) evaporation from the surface of the sea;

5) outflow into the gulf of Kara-Bogaz-Gol.

The first three factors constitute additions to and the last two, subtractions from, the water stock of the Caspian

DV/dt = (Runoffrivers - RunoffKBG) + (Gi-Go) +(P-E)


Slide10 l.jpg

Download data


Slide11 l.jpg

Download data


Slide12 l.jpg

Download data


Slide13 l.jpg

Altimetry on the Caspian sea and Kara Bogaz Gol Gulf

  • This concerns three main components:

    • Calculation of decadal Caspian Sea and KBG level variation and comparison with in-situ measurements

    • Estimation of water mass balance of each water bodies, based on coupled altimetry-climatological data

    • Study of ice regime in the north of Caspian sea from combination of active (altimetry) and passive (radiometry) microwave data


Slide14 l.jpg

Study of CSL from altimetry

+ Digital Bathymetry Map


Slide17 l.jpg

Water mass balance of Caspian sea


Slide18 l.jpg

Global agreement with remaining local discrepancies (70 mm

in 1995)

Errors in altimetry ~15 mm/yr

Possible uncertainty in the global lake level deduced from

terrestrial gauges to investigate


Slide20 l.jpg

Kara Bogaz Gol water balance


Slide21 l.jpg

4 December 1972

29 September 1987

Change of the area of gulf Gara-Bogaz-Gol

Mamedov (1996) presents the following relationship (attributed to Sheremetievskoi):

where, QKBG = annual inflow to the KBG (km3), H = average annual sea level at Baku (cm), QC = annual inflow to the Caspian Sea (km3).


Slide22 l.jpg

+


Slide23 l.jpg

+

DV/dt = Runoff (Caspi->KBG) – (E-P)*Surface(t)


Slide24 l.jpg

Geographycal distribution of annual

CSL variation deduced from 10 years

(1993-2002) Of Topex / Poseidon data

and average seasonal variation

Annual Amplitude (m)
