Project proposal project 7 drifters

Project ProposalProject 7: Drifters

Lance Ellerbe - BS EE

Jamal Maduro - BS CpE

Peter Rivera - BS ME

Anthony Sabido - BS ME


Drifter design team

Drifter Design Team


Project overview

Project Overview

  • Develop a self-contained network of tracked surface drifters for near coastal application.

    • Housing

    • Electronics

      • Power System

      • GPS receiver

      • Radio transceiver

      • Microcontroller

  • Any of these drifters within range of the base station will then be able to send all the information from all other drifters, thus providing a self-contained drifter network.

  • Many such drifters are deployed globally by the National Oceanic and Atmospheric Administration (NOAA) as part of the world climate observation program.


Legacy drifter

Legacy Drifter

*Picture courtesy of FSU Marine Lab


Operational description

Operational Description

*Picture courtesy of FSU Marine Lab

Client will take drifters out to the Ochlocknee Bay and release drifters into the water a set time intervals


Operational description1

Operational Description

*Picture courtesy of FSU Marine Lab

Then the drifters will be recovered based on pin pointed locations using the GPS and wireless communication from one another.


Electrical components

Electrical Components

  • Microcontroller

  • Radio Transceiver

  • GPS module

  • Battery

  • Data Logger


General layout

General Layout


Microcontroller radio transceiver and gps

Microcontroller ,Radio Transceiver, and GPS

Engineer: Jamal Maduro


Microcontroller

Microcontroller


Microcontroller1

Microcontroller


Microcontroller2

Microcontroller


Radio transceiver

Radio Transceiver


Radio transceiver1

Radio Transceiver


Radio transceiver2

Radio Transceiver


Radio transceiver3

Radio Transceiver


Radio transceiver4

Radio Transceiver


Gps module

GPS Module


Gps module1

GPS Module


Gps criteria

GPS Criteria


Gps criteria1

GPS Criteria


Power systems

Power Systems

Engineer: Lance Ellerbe


Power systems1

Power Systems

Overview

  • Low Power Consumption

  • Each must be able to operate on 3.3V maximum.

  • The drifter network will be designed to use the least amount of power when transmitting data

  • The power supply will be selected in order to supply the adequate amount of amp-hours in order to provide enough current for each electrical component to be operational throughout its 15 day deployment.


Power systems2

Power Systems

Current Component Selection PROGRESS:

  • Xbee

    • Operation Voltage: 3.0 -3.6VDC

    • Current Draw:

      • Transmitting current: 256mA

      • Receiving Current: 50 mA

    • Transmission Frequency:

      • every 2.16 min @ 10000 GPS fixes

  • GPS module

    • Will be selected for low power consumption and operate at a maximum of 3.3V. (Based on chart on previous slide the current drawn from GPS is approximately 29mA)

  • Microcontroller

    • Operation Voltage: 1.8V to 3.6V

    • Active mode: 230uA

    • Standby Mode: 0.5uA


Power systems3

Power Systems

Testing/ Verification

  • The testing of this task will include a number of power consumption tests. First, each electrical component will be attached separately to a multimeter or oscilloscope to validate that the component is operating within its electrical specifications.

  • Second, based on the results in the previous step the results can be then used to tweak network parameters such as transmission time or microprocessor algorithms in an attempt to lower power consumption and increase theoretical operation time.


Power systems4

Power Systems

Time of Operation

  • 15 days of operation = 360 hours of operation

  • Required GPS fixes: 10,000

  • Number of Fixes in 15 days: GPS fix every 2.16 min or 129.9 sec

  • FCC rule: The average time of occupancy at any frequency must not be larger than 0.4 seconds when using the frequency hopping spread spectrum.

  • Maximum current drawn per transmission/reception of all electrical components:

    Approximately 336mA


Power systems5

Power Systems

Worst Case Scenario: 0.4 sec for each transmission/reception

  • 336 mA for 1.11 hours of ACTIVE operation

    • sleep mode considered negligible (uA range).

  • 336 mA × 1.11 hours = 372.96 mAh

    • Battery needed would be something with 3.3 V and greater than 372.96 mAh


Power systems6

Power Systems

Criteria for Making Battery Selection:

  • Run Time

  • Volts (Power)

  • Amp-Hour Rating

  • Rechargeable

  • Life Cycle

  • Temperature of Operation


Power systems7

Power Systems

Power supply considerations:

  • (1)Lithium Ion

  • Lithium Manganese Nickel

  • Lithium Polymer

  • Nickel Cadmium (NiCad)

  • Nickel Metal Hydride (NiMH)

  • Photovoltaics


Power systems8

Power Systems

Lithium Ion Battery:

  • These batteries are able to handle excessive current applications.

  • Lithium batteries are great for long-term use.

  • Lithium batteries also perform well in extreme temperatures.

  • Increased life cycles over Nickel cadmium (NiCad) and Nickel Metal Hydride (NiMH) batteries.

  • Lithium ion batteries are also cheaper to manufacture than lithium polymer batteries, so when cost is a factor, lithium ion is the choice.

  • Much lower self-discharge rate than Nickel Metal Hydride (NiMH) batteries.

  • Wide variety of shapes and sizes efficiently fitting the devices they power.


Power systems9

Power Systems

Ideal Battery Configuration

Parallel configuration would be ideal to increase the amount of Amp-Hours to supply the adequate amount of current to Microcontroller, GPS module and Radio Transceiver for a 15 day period.

EXAMPLE


Power systems10

Power Systems

Voltage regulation

If battery chosen has a nominal voltage of more than 3.3 V, a voltage regulator will need to be implemented to maximize battery life and supply the correct operating voltage to the components.


Power systems11

Power Systems

PCB protection

  • Lithium Ion batteries must connect to a protection circuit module to protect Li-Ion Battery from overcharge, over discharge  and to prevent accidental battery explosion due to its extra high energy density.


Power systems12

Power Systems

Once all component selection has been finalized, the battery will be chosen based the voltage needed and the highest mAh that can be found.


Hull design

Hull Design

Engineers: Anthony Sabido and Peter Rivera


Hull design1

Hull Design

  • Increase water drag while decreasing wind drag

  • Watertight

  • Resist corrosion in saltwater

  • Survive light to medium impacts on potentially sharp objects

  • Easily duplicated


Legacy casing

Legacy Casing

*Picture courtesy of FSU Marine Lab


Hull design2

Hull Design

  • Semi-spherical shape.

  • The electric components will be stored in the center

  • Top will be as flat as possible.


Hull design3

Hull Design

  • Low weight

  • High stability

  • Easy to Seal

  • Easily Fabricated

  • Low Cost


Hull components

Hull Components

  • Base

    • Lack of edges reduces snagging.

    • 3 Piece design reduces materials and simplifies fabrication.

    • Allows for foam filling.

  • Top

    • Flat panel top decrease vertical profile.

    • Simple sealing process.

    • Quick component access.


Project proposal project 7 drifters

Base


Exploded view

Exploded View

  • Six screws fasten the top to the base.

  • Sealing achieved by 1 main rubber seal and 6 rubber coated washers.


Hull assembly

Hull Assembly


Issues encountered

Issues Encountered

  • Fastening

    • Need aluminum ring to secure the top.

Veck Female Bonding Fastener


Issues encountered1

Issues Encountered

  • Fastening

    • Excessive torque

  • Solutions

    • Bonding Fasteners

    • Torque Key

Ritchey Carbon Torque Key

- Cycle Club Sports


Specifications

Specifications

  • Waterproof to 5m (CAP-04 & REQF-06).

  • Low profile to reduce wind drag (CAP-06).

  • Painted to camouflage with the water (CAP-07).

  • Maximum weight of 0.5 kg (REQF-04).

  • Overall height less than 10 cm (REQF-05).


Hull testing

Hull Testing

  • Water tightness

  • Floatation


Hull testing1

Hull Testing

  • Vibration testing will be done on a vibration table, where the drifter will be shaken at a variety of frequencies for endurance.


Project timeline budget

Project Timeline & Budget


Project overview timeline

Project Overview - Timeline


Project overview timeline1

Project Overview - Timeline


Budget

Budget


Questions

Questions


References

References

Technical Report:

“Surface Circulation Study of Waters Near Ochlockonee Bay, Florida”

- Peter Lazarevichand Dr. Kevin Speer

Project Description :

“Tracking the coastal waters: a wireless network of shallow water drifters”

- FAMU-FSU College of Engineering
