1. Envirolyte … Recycled Water Technology We make disinfectant from Salt Water! July 2010 Environmental sterilising, disinfection and water treatment technology

2. Information in this slideshow ... What is Envirolyte Technology? Brief on Envirolyte Water recycling • Application examples • Industry Trial Results • Comparisons with other methods • Contacts Environmental sterilising, disinfection and water treatment technology

3. How does Salt convert to disinfectant? • Add salt to water (Make a Brine) • Meter Brine into water then pass through cell • Apply power to the patented cell • The Cell splits solution into Anolyte&Catholytevia electrochemical activation • Collect Anolyte&Catholyte On site, On demand, non toxic! ABSOLUTELY SAFE! Harsh Chemicals Environmental sterilising, disinfection and water treatment technology

4. How does Salt convert to disinfectant? • Disinfectant (Anolyte) • 500 ppm FAC • pH 5.5 – 8 • ORP ~ 800 mV Single phase • Detergent (Catholyte) • pH 12 • ORP ~ 1100 mV Brine Water Catholyte Returned to Control pH of Anolyte Environmental sterilising, disinfection and water treatment technology

5. Why Recover Water ? Site discharge is often very costly >$ 5.00/cubic mtr Industries target waste ratio of 2 kg Out: 1 kg In Most don't’ achieve it ! Average > 3 : 1 • REDUCE or RECYCLE water with Anolyte and reduce WASTE, Save $$ ! Approved Solutions - On Site, On demand, non toxic! ABSOLUTELY SAFE! Environmental sterilising, disinfection and water treatment technology

6. Water Successfully Recycled: Condensate Streams Storm Water Tertiary waste streams RO Permeate River or Bore water Environmental sterilising, disinfection and water treatment technology

7. Cost to Treat – How Much? Incl. Salt and Power 1,000 Litres Anolyte made on Site = $ 3.50 1,000,000 Litres Condensatetreated @ 3 ppm FAC ~ $ 21.00 1,000,000 Litres Storm water treated @ 1 ppm FAC ~ $ 7.00 1,000,000 Litres Waste watertreated @ 1.5 ppm FAC ~ $ 10.50 1,000,000 Litres Permeatetreated @ 0.5 ppm FAC ~ $ 3.50 1,000,000 Litres Bore Watertreated @ 1 ppm FAC ~ $ 7.00 Environmental sterilising, disinfection and water treatment technology

8. NZFSA & AsureQuality Approvals... NZFSA Approved:Dairy Maintenance Compound, for use in farm dairies. NZFSA Approved:C23, C43, C51, C61, C104, (all animal product except dairy) NZFSA Approved:Dairy Maintenance Compound, for use in farm dairies. NZFSA Approved:C23, C38, C63, (all animal product except dairy) Australian Certified Organic 31/07/08: Envirolyte NZ Ltd Envirolyte ANK Neutral Anolyte (& components - Envirolyte K-Catholyte & Envirolyte ANK Anolyte) from Envirolyte EL900 to EL/ELA6000 & EL/ELA 10000 machines. Sanitiser neutral Chlorine (generated)For use for: factory food area potable process water, and food rinse water. Environmental sterilising, disinfection and water treatment technology

9. ANK-Anolyte NZFSA Approved:(All animal product except dairy) C23 - Sanitiser for use in premises processing all animal product except dairy. May be used in edible areas after rinse. C43 -For use in premises processing all animal product except dairy. May be used as a no-rinse sanitiser on clean hard surfaces in licensed fish processing premises. C51 - Sanitiser for use in premises processing all animal product except dairy. May be used as a hand washing and sanitising compound in all areas.C61 - Sanitiser for use in premises processing all animal product except dairy. Permitted in potable water. C104 - Sanitiser for use in premises processing all animal product except dairy. May be used to sanitise whole shell eggs. NZFSA Approved:Dairy Maintenance Compound, for use in farm dairies.Envirolyte ANK Neutral Anolyte Antiseptic/Sanitiser for the purpose of cleaning, sanitising and/or maintaining the milking plant. Environmental sterilising, disinfection and water treatment technology

10. K-Catholyte NZFSA Approved: (All animal product except dairy) C23 - Cleaner for use in premises processing all animal product except dairy. May be used in edible areas after rinse. C38 - Cleaner for use in premises processing all animal product except dairy. May be used as a general cleaner. C63 - Cleaner for use in premises processing all animal product except dairy. May be used for treating boilers and steam lines where the steam produced may contact edible product. NZFSA Approved:Dairy Maintenance Compound, for use in farm dairies.Envirolyte K-Catholyte Cleaner for the purpose of cleaning the milking plant. Environmental sterilising, disinfection and water treatment technology

11. Auckland Zoo – Effluent Treatment • Treats 1.7 million litres/day continuously. • Cost to treat ~ $ 17.85 / Day Contaminants Before & After Anolyte Treatment: Environmental sterilising, disinfection and water treatment technology

12. Results from Anolyte trial in Reduction of Faecal coli & e-coli in Whey Condensate Trial Start - target 1 ppm residual Environmental sterilising, disinfection and water treatment technology

13. Envirolyte Technology Strengths: • Custom built installation for each customer’s needs • Strong focus on Product & Water Quality issues • Most cost effective sanitation Technology available • Safer,superior outcomes than competing technologies • Treats incoming and outgoing water with two solutions produced on site! • Innovative solutions to old problems • Prevention verses cure! • We assist in finding root cause and then providing the remedy! • CIP/Hygiene Consultancy and Support • More than 20 years Meat, FMCG, Dairy, Seafood & Beverage industry experience • We assess your site and advise the most economic application (win:win) • Site Specific Training and operations manual. • Web page monitoring available. • NZFSA and AsureQuality Approved Environmental sterilising, disinfection and water treatment technology

14. Thank you for taking the time to learn about Envirolyte Technology!Want to know more?Please contact... Keith Mason • 61 7 3807 8566 / 0413122822 • Or visit www.envirolyteasiapacific.com Environmental sterilising, disinfection and water treatment technology
