  1. Chapter 7 Genes and Technology

  2. Section 1: What Do Genes Look Like

  3. The Pieces to the Puzzle • The gene must be able to carry out two processes • 1) it must be able to supply complex instructions for cell processes and building cell structures • 2) It must be able to be copied each time a cell divides • This ensures that hereditary information is passed on • Before the 1940’s most scientists believe that proteins contained DNA • When and how did this perspective change?

  4. Nucleotides-The Subunits of DNA • Nucleotides – the subunits of DNA (4 of them) • Consists of a sugar, phosphate, and a base • Nucleotides are identical except for the type of base present • The four bases are: • 1. adenine (A) • 2. thymine (T) • 3. guanine (G) • 4. cytosine (C)

  5. Chargaff’s Rule • In the 1950’s a biochemist named Erwin Chargaff was studying samples of DNA • He discovered that the amount of adenine and thymine were always the same and that cytosine and guanine were always the same • This led to Chargaff’s Rules: • A = T • G = C

  6. A Picture of DNA • More clues came from chemist Rosalind Franklin • She was able to take images of DNA molecules • The process was known as X ray diffraction • The image that Franklin created suggested that DNA had a spiral shape

  7. Eureka! • Along with many other scientists, James Watson and Francis Crick were also studying The mystery of DNA’s structure • They had been try to make a model of DNA, but nothing worked • After seeing Franklin’s images, Watson and Crick put it all together! • DNA is shaped like a twisted ladder (a double helix)

  8. DNA Structure (see drawing on board) • DNA is shaped like a spiral staircase (double helix) • The two sides of the ladder are made of alternating sugar and phosphate molecules • The rungs of the ladder are composed of a pair of nucleotide bases • Please take the time now to draw the DNA molecule on the board • What does DNA stand for? • Deoxyribonucleic Acid • http://www.dnatube.com/video/365/DNA-Replication

  9. Making Copies of DNA • Because A always bonds with T and C with G, the bases on one side of the molecule become a template or pattern, for the other side • One side is then complementary to the other • What would be the complementary side to the following DNA segment be - ACCG? • TGGC • Before DNA can replicate it must split down the middle

  10. More News About Traits • Incomplete Dominance – when one trait is not completely dominant over the other • i.e. red flower and a white flower have pink offspring • One Gene Can Influence Many Traits • i.e. For a white tiger one gene influences both it’s fur and eye color • Many genes can influence a single trait • i.e. In humans skin, hair, and eye color are influenced by several genes

  11. QUIZ TIME! Take out a ½ a piece of paper.

  12. Chapter 7 –Quiz 1 1) List Chargaff’s Rules 2) _________ are the smallest subunits for DNA 3) _________ took an image of DNA, that allowed Watson and Crick to discover DNA’s shape 4)what is the complementary side to this DNA strand AGGTTCCATGCC 5) ____________ is when one gene or trait is not completely dominate over the other Bonus) ____________ is any change in the order of the bases in DNA

  13. Chapter 7 – Quiz 1 Answers 1) A=T and C=G 2) Nucleotide 3) Rosalind Franklin 4) AGGTTCCATGCC = TCCAAGGTACGG 5) Incomplete Dominance Bonus) Mutation

  14. Section 2: How DNA Works http://video.google.com/videoplay?docid=-4167644462303807708&ei=hUxXS5X9AqTwqAOq5dHIAQ&q=DNA+transcription+%26+translation&hl=en&view=3#

  15. Genes and Proteins • The bases in DNA read like a book • The bases A,T,G, and C form the alphabet for the genetic code • Groups of three bases in a row (codon) codes for a specific amino acid • i.e CCA codes for the amino acid proline, while AGC codes for serine • Remember amino acids are the building blocks of protein! • So proteins are just long chains of amino acids

  16. Why Proteins? • Proteins are found throughout the cell and act as chemical messengers • These proteins “express” the directions found in your genes • i.e your height, eye color, etc. • Human cells contain about 100,000 genes • The human body contains 50,000 different proteins • Proteins are the reason for the multitude of different shapes, sizes, colors, and textures found in living things

  17. The Making of a Protein • The first step in making a protein is to copy the section of the DNA containing a gene • Remember that the DNA has to unwind and unzip • A copy of this section is made with the help of copier enzymes (RNA polymerase) • The gene is copied into mRNA • m = messenger • Remember RNA has U (uracil) instead of T (thymine) • This “message” leaves the nucleus, enters the cytoplasm, and is fed through a ribosome • Ribosomes - are the “factory” where proteins are made out of amino acids

  18. The mRNA fed through the ribosome 3 bases at a time • Codons - are sections of 3 bases in a row, that “code” for a specific amino acid • There are 20 different amino acids • As codons are read by the ribosome, a tRNA molecule brings the correct amino acid to the ribosome • t = transfer • The amino acids continue to be “hooked” together until the ribosome reads a stop codon (UGA, UAG, or UAA) • The protein is now finished and will be transported by the Golgi or Rough ER and be sent to the right place to do it’s job

  19. Change in Genes • Mutations - mistakes or changes to the order of bases in DNA • Deletion - when a base is left out • Insertion - when an extra base is added • Substitution - when an incorrect base replaces a correct base • This is the most common type of error (I will ask this on the exam) • Fortunately repair enzymes are continuously on patrol checking for errors • Occasionally repairs are not made and the mistake becomes a permanent part of the genetic message (DNA)

  20. Differences Between RNA & DNA

  21. An Example of Substitution • ACT CCT GAA GAA AAA • UGA GGA CUU CUU UUUThr - Pro - Glu - Glu - Lys • Substitution • ACT CCT GTA GAA AAA • UGA GGA CAU CUU UUU • Thr - Pro - Val - Glu -Lys • An example of a simple change like this can lead to dramatic changes in an organism • Sickle Cell anemia is caused this way

  22. Mistakes Happen and How Does DNA Get Damaged? • There are 3 possible consequences to changes in DNA • 1) an improvement to an organism • 2) no change at all • 3) harmful or deadly change • If a change happens to a sex cell, the change can be passed on to the offspring • Mutagens - physical or chemical agents that cause mutations

  23. Genetic Counseling • Most genetic conditions are recessive disorders (ss) • That means both parents pass the gene on to their offspring • Carrier - A person who carries the recessive gene, but does not have the condition (Ss) • Pedigree - is a tool used by genetic counselors for tracing a trait through generations of a family • On a pedigree circles represent females, squares represent males • Empty circles or squares = not affected/non carrier • Half circles or squares = not affected/carrier • Full circles or squares = affected/carrier

  24. Chapter 7 Quiz 2 • 1)_____________ the “factory” (organelle) where amino acids are assembled into proteins • 2) ____________ are any mistakes in DNA • 3) ____________ a physical or chemical agent that can cause damage (mutation) to DNA • 4) ____________ is copied from DNA and carries the genetic message (of a gene) to the protein factory • 5) ____________ is a tool used by a genetic counselor to help trace a trait through generations • Bonus) ___________ is when you place a gene from another organism into the DNA of a different organism

  25. Section 3 - Applied Genetics • Humans have been aware of the benefits of selective breeding for thousands of years • Selective Breeding - is when humans choose idealistic traits in other organisms, and breed those organisms together • Genetic Engineering when scientists transfer the genes from one organism to another organism • Genetic engineering is already being used to some extent • Examples include; Dolly, disease resistant plants, repairing damaged genes

  26. Living Factories • The bases, in DNA, are the same in every living organism • This “sameness” allows the genes from one organism to be placed in another organism using genetic engineering • Recombinant DNA - the type of DNA that results from placing a gene from one organism into the DNA of another (bacteria) • Recombinant DNA can be used to produce insulin in large amounts • How is this done???????? (see page 166)

  27. Chapter 7 Quiz 3 • This field of science allows scientists to transfer genes from one organism to another organism ____________ • The resulting DNA from placing a gene of one organism into another is called? • __________ is when you compare DNA fragments, from different samples, to each other • ______________ is the project where scientists “decoded” every gene and chromosome in human DNA • Bonus: Take the following DNA strand and turn it into RNA, TAC CCG GGA TAT CAG

  28. DNA Fingerprints • DNA Fingerprinting - when you compare DNA fragments from different individuals, with a known DNA sample • In the laboratory DNA can be separated based on its size
