  1. Odonata Dragonflies Damselflies

  2. Order: Odonata Suborder: Anisoptera Family: Cordulegasteridae Genus: Cordulegastor A. Bosak BMIC A. Bosak BMIC A. Bosak BMIC Spoon Shaped Prementum Jagged Palpal Lobes

  3. Order: Odonata Suborder: Anisoptera Family: Gomphidae A. Bosak BMIC 4 Segmented antennae A. Bosak BMIC A. Bosak BMIC A. Bosak BMIC Flat mentum

  4. Order: Odonata Suborder: Anisoptera Family: Aeshnidae Genus: Anax A. Bosak BMIC Antennae with 6 or 7 segments, end segments slender Flat labium

  5. Order: Odonata Suborder: Anisoptera Family: Libelulidae Genus: Brechmorhoga A. Bosak BMIC A. Bosak BMIC A. Bosak BMIC

  6. Order: Odonata Suborder: Anisoptera Family: Cordulidae Genus: Macromus A. Bosak BMIC A. Bosak BMIC A. Bosak BMIC Head horn

  7. Antennae segments all equal length A. Bosak BMIC A. Bosak BMIC Caudal lamellae same width throughout Labium not stalked Order: Odonata Suborder: Zygoptera Family: Coengrionidae

  8. A. Bosak BMIC A. Bosak BMIC More round caudal lamellae; no distinct point Order: Odonata Suborder: Zygoptera Family: Coengrionidae Genus: Hesperagrion A. Bosak BMIC

  9. A. Bosak BMIC Vein C1 on forewing extends past origin of M1a A. Bosak BMIC Order: Odonata Suborder: Zygoptera Family: Coengrionidae Genus: Hesperagrion A. Bosak BMIC Female 8th segment ventro-apical spine

  10. Order: Odonata Suborder: Zygoptera Family: Lestidae Genus: Lestes Four processes on the distal portion of each palpal lobe, 3rd process truncate A. Bosak BMIC Prementum petiolate and spoon-shaped A. Bosak BMIC
