Presentation Transcript
Process safety management of highly hazardous chemicals l.jpg

Process Safety Managementof HighlyHazardous Chemicals

Nancy J Bethea


Process safety management psm l.jpg
Process Safety Management (PSM)

Is the proactive identification, evaluation and mitigation or prevention of chemical releases that could occur as a result of failures in processes, procedures, or equipment.


Purpose l.jpg
Purpose

  • Prevent Catastrophic Releases of Highly Hazardous Chemicals

  • Minimize Consequences of Such Releases to Employees and the Community


Catastrophic events l.jpg
Catastrophic Events

Deaths Injuries

  • 1984 Mexico City 650 --

  • 1984 Bhopal, India 2500 --

  • 1984 Chicago area 17 17

  • 1985 West Virginia -- 135

  • 1988 New Orleans 5 23

  • 1988 Henderson, NV 2 350


Catastrophic events6 l.jpg
Catastrophic Events

Deaths Injuries

  • 1989 Pasadena, TX 23 130

  • 1990 Houston, TX 17 --

  • 1990 Cincinnati, OH 2 72

  • 1991 Lake Charles, LA 5 --

  • 1991 Sterlington, LA 8 120

  • 1991 Charleston, SC 6 33

  • 1991 Seadrift, TX 1 32


Process safety management l.jpg
Process Safety Management

Bhopal (’84): focused OSHA’s attention

Institute, WV(’85): shows disasters can happen here

1988-1991: concern of public & Congress increases with each event

Feb. 24, 1992: standard in Federal Register


29 cfr 1910 119 l.jpg
29 CFR 1910.119

OSHA’s Process Safety

Management Standard


Anticipated benefits l.jpg
Anticipated Benefits

OSHA estimated that the integrated

approach of the PSM standard would reduce

the average annual number of deaths (265)

by 200 and reduce the average annual

number of serious injuries (900) by 700 in

industries involved with highly hazardous

chemicals.


Resources l.jpg
Resources

  • European Economic Community (EEC)

  • World Bank

  • International Labor Office (ILO)

  • U.S. Environmental Protection Agency

  • Superfund Amendments and Reauthorization Act (SARA)

  • States, Industry, & Labor Organizations


Psm standard l.jpg
PSM Standard

Performance

NOT

Specification Standard


Psm standard12 l.jpg
PSM Standard

  • Process Safety Information

  • Process Hazard Analysis

  • Operating Procedures

  • Training

  • Contractors

  • Pre-startup Safety Review


Psm standard13 l.jpg
PSM Standard

  • Mechanical Integrity

  • Hot-work Permits

  • Management of Change

  • Incident Investigations

  • Emergency Planning & Response

  • Compliance Safety Audits


What s covered l.jpg
What’s Covered

  • Listed Chemicals in Appendix A

  • > 10,000 pounds of Flammable Liquids or Gases


Examples of covered chemicals l.jpg
Examples of Covered Chemicals

Acetaldehyde Chlorine

Nitromethane Ethylamine

Perchloric Acid Phosgene

Tetramethyl Lead Ketone

HF NO


What s not covered l.jpg
What’s Not Covered

  • HC fuels used only for workplace consumption and if not a part of a covered hazardous process

  • Flammable liquids stored or transferred below NBP w/o chilling or refrigeration

  • Retail facilities

  • Oil, gas well drilling, servicing

  • Normally unmanned remote facilities


Process safety information chemicals l.jpg
Process Safety Information:Chemicals

  • Toxicity

  • PEL

  • Physical Data

  • Reactivity and Corrosivity

  • Thermal and Chemical Stability

  • Effects of Mixing Chemicals


Process safety information process l.jpg
Process Safety Information:Process

  • Block flow or process flow diagram

  • Process chemistry

  • Maximum intended inventory


Process safety information process19 l.jpg
Process Safety Information:Process

  • Safe upper/lower limits for such items as temperatures, pressures, flows or compositions

  • Consequences of deviations, e.g. runaway reaction potential


Process safety information equipment l.jpg
Process Safety Information:Equipment

  • Materials of construction

  • P&IDs

  • Electrical Classification

  • Relief system design & design basis


Process safety information equipment21 l.jpg
Process Safety Information:Equipment

  • Ventilation system design

  • Design codes and standards

  • Material & energy balances

  • Safety systems


Process hazard analysis l.jpg
Process Hazard Analysis

Organized and systematic effort to identify and analyze the significance of potential hazards associated with the processing or handling of highly hazardous chemicals


Process hazard analysis23 l.jpg
Process Hazard Analysis

  • Causes/consequences of fires & explosions

  • Releases of toxic or flammable chemicals

  • Major spills of hazardous chemicals

  • Methodology depends on the process & its characteristics


Pha focuses on l.jpg
PHA Focuses On

  • Equipment

  • Instrumentation

  • Utilities

  • Human Actions

  • External Factors


Process hazard analysis25 l.jpg
Process Hazard Analysis

  • What If?

  • Checklist

  • What If?/Checklist

  • Hazard & Operability Study (HAZOP)

  • Failure Mode & Effects Analysis (FMEA)

  • Fault Tree Analysis (FTA)


Pha must address l.jpg
PHA Must Address

  • Hazards of the process

  • Engineering & administrative controls

  • Consequences of failure of controls

  • Facility siting


Pha must address27 l.jpg
PHA Must Address

  • Human factors

  • Evaluate potential effects to on-site personnel from failure of controls

  • Identification of previous incidents


Pha team l.jpg
PHA Team

  • Expertise in engineering & process operations

  • One member to have knowledge of & experience with process being evaluated


Pha team29 l.jpg
PHA Team

  • One member knowledgeable in specific PHA methodology used for evaluating the process

  • Other members with specific knowledge: instrumentation, chemistry, etc.


Employer pha actions l.jpg
Employer PHA Actions

  • Establish system for prompt response

  • Ensure timely resolution of findings & recommendations

  • Document actions taken


Employer pha actions31 l.jpg
Employer PHA Actions

  • Develop written schedule for completions

  • Complete actions ASAP

  • Communicate actions to affected employees


Operating procedures l.jpg
Operating Procedures

  • Provide clear instructions for safely conducting activities involved in each covered process consistent with the process safety information

  • Address at least the listed elements


Operating procedures steps for each operating phase l.jpg
Operating Procedures:Steps for Each Operating Phase

  • Initial startup, operation, shutdown

  • Temporary & emergency operations, emergency shutdown

  • Startup following shutdowns


Operating procedures operating limits l.jpg
Operating Procedures: Operating limits

  • consequences of deviations

  • prevention of deviations


Operating procedures safety health considerations l.jpg
Operating Procedures: Safety & Health Considerations

  • Chemical properties and hazards

  • Precautions to prevent exposure

  • Control measures if contact or airborne exposure occurs


Operating procedures safety health considerations36 l.jpg
Operating Procedures: Safety & Health Considerations

  • Quality controls for raw materials

  • Control of hazardous chemical inventories

  • Special or unique hazards

  • Safety systems & their functions


Operating procedures37 l.jpg
Operating Procedures

  • Operating procedures readily accessible

  • Reviewed as necessary to reflect current procedures and changes

  • Certified annually as current & accurate


Operating procedures38 l.jpg
Operating Procedures

  • Develop & implement safe work practices to provide for the control of hazards during operations, e.g. lockout/tagout/ confined space entry, opening equipment & pipes, facility entry

  • Apply to employees & contractor employees


Training l.jpg
Training

  • Process overview

  • Process hazards

  • Operating procedures

  • Emergency procedures

  • Refresher training at least every 3 yrs

  • Documentation


Employer responsibilities l.jpg
Employer Responsibilities

  • Evaluate contractor’s safety performance & programs

  • Inform contractor of potential hazards: fire, explosion, toxic release, applicable plant safety rules

  • Develop/Implement safe work practices

  • Evaluate contractor performance


Contractor responsibilities l.jpg
Contractor Responsibilities

  • Advise employer of any unique work hazards of contracted work

  • Each employee follow all applicable work practices & safety rules of the facility

  • Ensure each employee is trained in necessary work practices


Contractor responsibilities42 l.jpg
Contractor Responsibilities

  • Ensure each employee is instructed in known fire, explosion, or toxic release problems related to his/her job

  • Document that understanding of training has been evaluated, verified


Pre startup safety review l.jpg
Pre-startup Safety Review

Done when:

  • New processes

  • Modified process


Pre startup review verifies l.jpg
Pre-startup Review Verifies

  • Construction: conforms to design

  • Procedures: adequate, in place

  • PHA recommendations resolved or implemented

  • Management of change requirements met

  • All affected workers trained


Psm mechanical integrity l.jpg
PSM Mechanical Integrity

  • Pressure vessels, storage tanks

  • Piping systems, components

  • Relief & vent systems, devices

  • Emergency shutdown systems

  • Controls: monitoring devices, sensors, alarms, interlocks

  • Pumps


Mechanical integrity l.jpg
Mechanical Integrity

  • Written procedures

  • Training: process hazards, job tasks

  • Inspections

  • Testing

  • Corrective action

  • Records


Hot work permits l.jpg
Hot Work Permits

  • Welding, cutting, brazing

  • Control of ignition sources

  • Verify safe conditions

  • Authorization


Management of change l.jpg
Management of Change

  • Establish written procedures

  • Develop management support

  • Evaluate safety of any changes to:

    process chemicals facility

    technology equipment


Moc procedures must address l.jpg
MOC Procedures Must Address

  • Everything except “replacement in kind”

  • Temporary as well as permanent changes

  • Technical basis for change

  • Safety & health effects


Moc procedures must address50 l.jpg
MOC Procedures Must Address

  • Modified operation procedures

  • Time necessary for change

  • Authorization for change

  • Ways to inform & train workers before change


Incident investigation goals l.jpg
Incident Investigation Goals

Identify incident causes and implement steps to prevent reoccurence


Incident investigation l.jpg
Incident Investigation

  • Every incident

  • Prompt investigation

  • Knowledgeable team

  • Documentation & report

  • Recommendations & findings

  • Resolutions & corrective actions


Emergency planning response l.jpg
Emergency Planning & Response

  • Develop Emergency Action Plans

  • Pre-plan for catastrophe

  • Train & equip workers

  • Drills


Compliance safety audits l.jpg
Compliance Safety Audits

  • Certify all elements of standard

  • Knowledgeable audit team

  • Report & recommendations

  • Address all finding & recommendations

  • Conduct every three years


Appendices l.jpg
Appendices

A: List of chemicals

B: Sample block & flow diagrams

C: Compliance guidelines

D: References
