Presentation Transcript
Slide1 l.jpg

Matlab: Cogent & External Devices

Friederike Schüür

18th March 2010

Course Material: http://www.icn.ucl.ac.uk/

Cogent Software: http://www.vislab.ucl.ac.uk/cogent.php

ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


Basic script overview recap l.jpg

Initialising expt. variables

Configuration of devices

start_cogent

  • Run experiment

  • load premade stimulus files

  • create new stimuli

  • trial loop:

  • - present stimuli

  • - get user responses

  • - save data as you go

  • save final data & close files

stop_cogent

Basic script overview: recap

In the previous sessions we covered:

  • General structure of cogent scrips

  • Presentation of stimuli

    • Visual

    • Sound

  • Registration of keyboard & mouse events

  • Logging & saving of data

  • Communication with external devices!

  • ICN Matlab for Cognitive Neuroscience 2009 /10 – Presenting Stimuli with Cogent


    Today s lecture ext devices l.jpg
    Today’s lecture: Ext. devices

    General Usage:

    • Using a button box

    • Synchronization with external devices

    • MRI scanner

    • Check sound or display synchronization

    • Sending triggers to:

    • TMS

    • EEG

    serial port ...

    Configuration of devices

    + some cogent commands

    parallel port ...

    Configuration of devices

    + some cogent commands

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    What s a serial port l.jpg
    What’s a serial port?

    • A serial port is a serial communication interface.

    • Information transfers in or out one bit at a time.

    • Largely obsolete in modern computers (too bad for us ...).

    Diagrammatic oscilloscope trace of voltage levels for an uppercase ASCII “K” character with 1 start bit, 8 data bits, and one stop bit (RS-232).

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Configuration of the serial port l.jpg
    Configuration of the serial port

    Configuration:

    config_serial(port, baudrate, parity, stopbits, bytesize)

    port: - COM port number (1,2,3,4, etc.)

    baudrate: - (110, 300, 600, ..., 128000, 256000)

    parity: - (0 = none, 1 = odd, 2 = even, 3 = mark, 4 = space)

    stopbits: - (0 = 1, 1 = 1.5, 2 = 2)

    bytesize: - (4 bits, 8 bits)

    Default setting: config_serial(1, 9600, 0, 0, 8) which is used if config_serial is used without input arguments.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Jargon of the serial port l.jpg
    “Jargon” of the serial port

    config_serial(port, baudrate, parity, stopbits, bytesize)

    port: Number of the serial port you’re going to use.

    baudrate: Number of symbols transmitted per second (similar to bit rate).

    parity: Simple form of error detection in data transmission. E.g. if you choose even parity, then parity bit set to 1 is nr. of 1s is odd in data transmission making number of transmitted 1s even. If nr. of transmitted 1s then odd: error! (mark parity = bit always 1, space parity = bit always 0).

    stopbits: Allow receiving signal hardware to detect the end of a character.

    bytesize: Number of bits per byte.

    Default setting: config_serial(1, 9600, 0, 0, 8) which is used if config_serial is used without input arguments.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Slide7 l.jpg

    logserialbytes(port)

    -----------------------------------------------------------------------

    logs & time stamps all serial bytes that have been read by last readserialbytes. Saved in a logfile if configuered.

    clearserialbytes(port)

    -----------------------------------------------------------------------

    empties the buffer for serial port number

    Serial port: button box

    readserialbytes(port)

    -----------------------------------------------------------------------

    reads all bytes arriving at serial port 1 & empties the buffer (clearserialbytes(port))

    ICN Matlab for Cognitive Neuroscience 09 /10: Recording, logging & saving with Cogent


    Slide8 l.jpg

    Serial port: button box

    waitserialbyte(port, time, b)

    -----------------------------------------------------------------------

    waits a time (‘time’ in ms) for a serial byte with value b to arrive at serial port number ‘port’. Executes readserialbytes and logserialbytes.

    All serial bytes are logged, and the buffer is emptied. If time ‘time’ elapsed before b has arrived, then the script continues.

    [k t n] = getserialbyte(port)

    -----------------------------------------------------------------------

    returns values and times of serial bytes read by readserialbytes

    ICN Matlab for Cognitive Neuroscience 09 /10: Recording, logging & saving with Cogent


    Example button box l.jpg

    Loop round 10 x 15sec trials, get button presses

    Depends on specific button box, usually:

    0, 1, 2, 4, 6.

    %Correct

    %defining variables

    trial_no = 10; trial_dur = 15000;

    clearserialbytes(1); %empty buffer

    for p = 1:trial_no;

    wait(trial_dur) % allow some time to pass

    readserialbytes(1); [k t n] = getserialbytes(1); % update & extract bytes

    keys(p).k = k; keys(p).t = t;

    end;

    Example: button box

    ICN Matlab for Cognitive Neuroscience 09 /10: Recording, logging & saving with Cogent


    Example synchronization l.jpg

    Ensure that stimulus computer & external device are in synchrony.

    Example: Synchronization

    • Incoming pulses generated by the external device can be used for synchronization.

    • The stimulus computer waits until the signal is registered.

    • Commands used for this operation are:

    • clearserialbytes(1)

    • waitserialbytes(1,inf, byte_to_wait_for).

    • Once the byte_to_wait_for has been received, the script continues.

    ICN Matlab for Cognitive Neuroscience 09 /10: Recording, logging & saving with Cogent


    Example synchronization11 l.jpg

    with the FIL MRI scanner. synchrony.

    Example: Synchronization

    Depends on serial port (getslice reads serial port)

    use code available at:

    http://www.fil.ion.ucl.ac.uk/local/mri/home/ericf/cogent2000.html

    [slices, times] = getslice( port ) % returns most recent slice number with time stamps.

    logslice %transfers scanner slices read by getslice to the log file

    [s, t] = waitslice( port, n ) %waits forever for MRI slice n or greater, returns actual slice number and time stamp.

    ICN Matlab for Cognitive Neuroscience 09 /10: Recording, logging & saving with Cogent


    Example sound or display l.jpg

    Check sound or display synchronization synchrony.

    Example: Sound or Display

    • Serial port can also send signals to other devices, e.g. oscilloscopes.

    • For this, you need a special cable (see Cogent user manuals for instructions or ask Martin! ).

    • You can generate a signal using:

    • cgsignal (port, signal)

    • Signal = signal code (0/1/2/3/4 etc.)

    • or

    • sendserialbytes (port, byte)

    • byte needs to be between 0 – 255.

    ICN Matlab for Cognitive Neuroscience 09 /10: Recording, logging & saving with Cogent


    What s a parallel port l.jpg
    What’s a parallel port? synchrony.

    • Interface for connecting peripherals.

    • Transmits particular amounts of bits (e.g. 8) in parallel at the same time.

    Problems with accessing the parallel port:

    For security reasons, accessing is parallel port is blocked on most “newer computers”. However, you can open up the ports by e.g. using Userport which is included in the cogent download.

    UserPort.sys is a driver that gives access to the I/O Ports. Needs to be installed once on each computer you use.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Essential links l.jpg
    Essential links synchrony.

    For .dll files for parallel port communication:

    http://www.fil.ion.ucl.ac.uk/local/mri/home/ericf/cogent2000.html

    For problems with I/O access:

    http://www.beyondlogic.org/porttalk/porttalk.htm

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Configuration of the parallel port l.jpg
    “Configuration” of the parallel port synchrony.

    Parallel ports usually have decimal addresses: e.g. 888, 632, or 956.

    Configuration: startportb(port) e.g. starportb(888)

    Note: startportb might not be necessary, depending on your parallel port access (the one exception for configuration ... !)

    Controlling parallel port input: k = inportb(port)

    Returns decimal values of bytes arriving at port ‘port.

    Controlling parallel port output: outportb(port, num).

    Send the number ‘num’ to specified port. ‘Num’ between 0 - 255.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Sending triggers to tms eeg l.jpg
    Sending triggers to TMS / EEG synchrony.

    Use outportb(port,num); wait(t_ms); outportb(port,0);

    to send a t_ms long pulse.

    If parallel port of stimulus computer (sending) is connected to an EEG setup (receiving) then num determines the pulse ID in an EEG trace.

    If particular bits sent by the parallel port send pulses to different external devices, e.g. to trigger data recording or a TMS machine, then num will determine which device receives the trigger.

    This allows triggering multiple devices from within a Matlab Cogent Script.

    Check carefully for delays! Problems in the past!

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Slide17 l.jpg

    Sending triggers to TMS / EEG synchrony.

    Use outportb(port,num); wait(t_ms); outportb(port,0);

    num is a number between 0 and 255.

    It’s meaning is clear once it’s transformed into binary code.

    • e.g. 4 corresponds to ‘100’  send bit 2

      with this command, you would send a pulse to the devices connected to bit 2 (note, count from right, the first zero corresponds to bit 0).

      This way you can send pulses to one or multiple devices at the same time.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Slide18 l.jpg

    Example: paired pulse TMS synchrony.

    Use outportb(port,num); wait(t_ms); outportb(port,0);

    • Bit 0 to TMS machine 1

    • Bit 1 TMS machine 2

    • Bit 2 trigger DAQ computer

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Slide19 l.jpg

    Example: paired pulse TMS synchrony.

    % Trigger TMS 1000ms after stimulus presentation. Start data recording after % 100ms before TMS trigger

    TMS.dly = 1000; TMS.intl = 2; TMS.pre_rec = 100; % Define times

    cgdrawsprite(1,0,0,0); % draw stimulus in buffer

    cgflip(0,0,0); % present stimulus

    t_present = time; % get time of stimulus presentation

    waituntil(t_present + TMS.dly - TMS.pre_rec); %wait until start recording

    outportb(888,4);wait(1);outportn(888,0); %start recording (4 = 100b)

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Slide20 l.jpg

    Example: paired pulse TMS synchrony.

    waituntil(t_present + TMS.dly); %wait until first TMS pulse

    outportb(888,2);wait(1);outportn(888,0); %1st TMS pulse (2 = 10b)

    waituntil(t_present + TMS.dly + TMS.intvl); %wait until 2nd TMS pulse

    outportb(888,1);wait(1);outportn(888,0); %2nd TMS pulse ( 1 = 1b)

    Important: Use waituntil (not wait) otherwise timing inaccuracies.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Slide21 l.jpg

    More advanced communication synchrony.

    Not with the commands introduced …

    Use the Matlab Data Acquisition Toolbox.

    Very flexible use of parallel & serial ports and other interfaces.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices


    Slide22 l.jpg

    That’s it for this time ... synchrony.

    Next session:

    Sam Schwartzkopf about alternatives to Cogent for stimulus presentation:

    Psychophysics toolbox.

    ICN Matlab for Cognitive Neuroscience 2009 /10 – Matlab: Cogent & External devices
