Ecm585 special topics in computer design lecture 2 combinational logic design 1 l.jpg

ECM585Special Topics in Computer DesignLecture 2. Combinational Logic Design 1

Prof. Taeweon Suh

Computer Science Education

Korea University


Introduction l.jpg

Introduction

A logic circuit is composed of:

  • Inputs

  • Outputs

  • Functional specification

  • Timing specification


Circuits l.jpg

Circuits

  • Nodes

    • Inputs: A, B, C

    • Outputs: Y, Z

    • Internal: n1

  • Circuit elements

    • E1, E2, E3


Types of logic circuits l.jpg

Types of Logic Circuits

  • Combinational Logic

    • Memoryless

    • Outputs determined by current values of inputs

  • Sequential Logic

    • Has memory

    • Outputs determined by previous and current values of inputs


Rules of combinational composition l.jpg

Rules of Combinational Composition

  • Every circuit element is itself combinational

  • Every node of the circuit is either designated as an input to the circuit or connects to exactly one output terminal of a circuit element

  • The circuit contains no cyclic paths: every path through the circuit visits each circuit node at most once

  • Example:


Boolean equations l.jpg

Boolean Equations

  • Functional specification of outputs in terms of inputs

  • Example:

    S = F(A, B, Cin)

    Cout = F(A, B, Cin)


Terminology l.jpg

Terminology

  • The Complementof a variable A is A

  • A variable or its complement is called literal

  • The AND of one or more literals is called a product orimplicant

    • Example: AB, ABC, B

  • OR of one or more literals is called a sum

    • Example: A + B

  • Order of operations

    • NOT has the highest precedence, followed by AND, then OR

      • Example: Y = A + BC


Sum of products sop form l.jpg

Sum-of-Products (SOP) Form

  • All Boolean equations can be written in SOP form

  • A mintermis a product (AND) of literals involving all of the inputs to the function

  • Each row in a truth table has a minterm that is TRUE for that row (and only that row)

  • The function is formed by ORing the minterms for which the output is TRUE

    • Thus, a sum (OR) of products (AND terms)

Y = F(A, B, C) = AB + AB


Product of sums pos form l.jpg

Product-of-Sums (POS) Form

  • All Boolean equations can be written in POS form

  • A maxterm is a sum (OR) of literals

  • Each row in a truth table has a maxterm that is FALSE for that row (and only that row)

  • The function is formed by ANDing the maxterms for which the output is FALSE

    • Thus, a product (AND) of sums (OR terms)

Y = F(A, B, C) = (A + B)(A + B)


Boolean equations example l.jpg

Boolean Equations Example

  • You are going to the cafeteria for lunch

    • You won’t eat lunch (E: eat)

      • If it’s not open (O: open)

      • If they only serve corndogs (C: corndogs)

  • Write a truth table for determining if you will eat lunch (E)


Sop pos form l.jpg

SOP & POS Form

  • SOP – sum-of-products

  • POS – product-of-sums

Y = AB

Y = (A + B)(A + B)(A + B)


When to use sop and pos l.jpg

When to Use SOP and POS?

  • SOP produces the shortest equations when the output is true on only a few rows of a truth table

  • POS is simpler when the output is false on only a few rows of a truth table


Slide13 l.jpg

HDL

  • Hardware description language (HDL): allows designer to specify logic function only. Then a computer-aided design (CAD) tool produces the optimized gates.

  • Most commercial designs built using HDLs

  • Two leading HDLs:

    • Verilog

      • developed in 1984 by Gateway Design Automation

      • became an IEEE standard (1364) in 1995

    • VHDL

      • Developed in 1981 by the Department of Defense

      • Became an IEEE standard (1076) in 1987


Hdl to gates l.jpg

HDL to Gates

  • Simulation

    • Input values are applied to the circuit

    • Outputs checked for correctness

    • Millions of dollars saved by debugging in simulation instead of hardware

    • We are going to use ModelSim Xilinx Edition-III (MXE-III) for simulation

      • http://www.xilinx.com/ise/optional_prod/mxe.htm

  • Synthesis

    • Transforms HDL code into a netlist describing the hardware (i.e., a list of gates and the wires connecting them)

    • You can see the synthesized result with ISE Webpack

      IMPORTANT:

      When describing circuits using an HDL, it’s critical to think of the hardware the code should produce.


Verilog modules l.jpg

Verilog Modules

  • Two types of Modules:

    • Behavioral: describe what a module does

    • Structural: describe how a module is built from simpler modules


Behavioral verilog example l.jpg

Behavioral Verilog Example

Verilog:

module example(input a, b, c,

output y);

assign y = ~a & ~b & ~c | a & ~b & ~c | a & ~b & c;

endmodule


Behavioral verilog simulation l.jpg

Behavioral Verilog Simulation

Verilog:

module example(input a, b, c,

output y);

assign y = ~a & ~b & ~c | a & ~b & ~c | a & ~b & c;

endmodule


Behavioral verilog synthesis l.jpg

Behavioral Verilog Synthesis

Verilog:

module example(input a, b, c,

output y);

assign y = ~a & ~b & ~c | a & ~b & ~c | a & ~b & c;

endmodule

Synthesis:


Verilog syntax l.jpg

Verilog Syntax

  • Verilog is case sensitive. So, reset and Reset are not the same signal.

  • Verilog does not allow you to start signal or module names with numbers. So, for example, 2mux is an invalid name.

  • Verilog ignores whitespace.

  • Comments come in single-line and multi-line varieties:

    • // single line comment

    • /* multiline

      comment */


Structural modeling hierarchy l.jpg

Structural Modeling - Hierarchy

module and3(input a, b, c,

output y);

assign y = a & b & c;

endmodule

module inv(input a,

output y);

assign y = ~a;

endmodule

module nand3(input a, b, c

output y);

wire out; // internal signal

and3 andgate(a, b, c, out); // instance of and3

inv inverter(out, y); // instance of inverter

endmodule


Bitwise operators l.jpg

Bitwise Operators

module gates(input [3:0] a, b,

output [3:0] y1, y2, y3, y4, y5);

/* Five different two-input logic

gates acting on 4 bit busses */

assign y1 = a & b; // AND

assign y2 = a | b; // OR

assign y3 = a ^ b; // XOR

assign y4 = ~(a & b); // NAND

assign y5 = ~(a | b); // NOR

endmodule

// single line comment

/*…*/ multiline comment


Reduction operators l.jpg

Reduction Operators

module and8(input [7:0] a,

output y);

assign y = &a;

// &a is much easier to write than

// assign y = a[7] & a[6] & a[5] & a[4] &

// a[3] & a[2] & a[1] & a[0];

endmodule


Conditional assignment l.jpg

Conditional Assignment

module mux2(input [3:0] d0, d1,

input s,

output [3:0] y);

assign y = s ? d1 : d0;

endmodule

? : is also called a ternary operator because it

operates on 3 inputs: s, d1, and d0.


Internal variables l.jpg

Internal Variables

module fulladder(input a, b, cin, output s, cout);

wire p, g; // internal nodes

assign p = a ^ b;

assign g = a & b;

assign s = p ^ cin;

assign cout = g | (p & cin);

endmodule


Precedence l.jpg

Precedence

Order of operations

Highest

Lowest


Numbers l.jpg

Numbers

Format: N'Bvalue

N = number of bits, B = base

N'B is optional but recommended (default is decimal)


Bit manipulations example 1 l.jpg

Bit Manipulations: Example 1

assign y = {a[2:1], {3{b[0]}}, a[0], 6’b100_010};

// if y is a 12-bit signal, the above statement produces:

y = a[2] a[1] b[0] b[0] b[0] a[0] 1 0 0 0 1 0

// underscores (_) are used for formatting only to make it easier to read. Verilog ignores them.


Bit manipulations example 2 l.jpg

Bit Manipulations: Example 2

Verilog:

module mux2_8(input [7:0] d0, d1,

input s,

output [7:0] y);

mux2 lsbmux(d0[3:0], d1[3:0], s, y[3:0]); // from slide 12

mux2 msbmux(d0[7:4], d1[7:4], s, y[7:4]); // from slide 12

endmodule

Synthesis:


Z floating output l.jpg

Z: Floating Output

Verilog:

module tristate(input [3:0] a,

input en,

output [3:0] y);

assign y = en ? a : 4'bz;

endmodule

Synthesis:


Delays l.jpg

Delays

module example(input a, b, c,

output y);

wire ab, bb, cb, n1, n2, n3;

assign #1 {ab, bb, cb} = ~{a, b, c};

assign #2 n1 = ab & bb & cb;

assign #2 n2 = a & bb & cb;

assign #2 n3 = a & bb & c;

assign #4 y = n1 | n2 | n3;

endmodule


Delays31 l.jpg

Delays

module example(input a, b, c,

output y);

wire ab, bb, cb, n1, n2, n3;

assign #1 {ab, bb, cb} =

~{a, b, c};

assign #2 n1 = ab & bb & cb;

assign #2 n2 = a & bb & cb;

assign #2 n3 = a & bb & c;

assign #4 y = n1 | n2 | n3;

endmodule


Testbenches l.jpg

Testbenches

  • HDL code written to test another HDL module, the device under test (dut), also called the unit under test (uut)

  • Not synthesizeable

  • Types of testbenches:

    • Simple testbench

    • Self-checking testbench

    • Self-checking testbench with testvectors (will be explained later)


Example l.jpg

Example

Write Verilog code to implement the following

function in hardware:

y = bc + ab

Name the module sillyfunction


Example34 l.jpg

Example

Write Verilog code to implement the following

function in hardware:

y = bc + ab

Name the module sillyfunction

Verilog:

module sillyfunction(input a, b, c, output y);

assign y = ~b & ~c | a & ~b;

endmodule


Simple testbench l.jpg

Simple Testbench

module testbench1();

reg a, b, c;

wire y;

// instantiate device under test

sillyfunctiondut(a, b, c, y);

// apply inputs one at a time

initial begin

a = 0; b = 0; c = 0; #10;

c = 1; #10;

b = 1; c = 0; #10;

c = 1; #10;

a = 1; b = 0; c = 0; #10;

c = 1; #10;

b = 1; c = 0; #10;

c = 1; #10;

end

endmodule


Self checking testbench l.jpg

Self-checking Testbench

module testbench2();

reg a, b, c;

wire y;

// instantiate device under test

sillyfunction dut(a, b, c, y);

// apply inputs one at a time

// checking results

initial begin

a = 0; b = 0; c = 0; #10;

if (y !== 1) $display("000 failed.");

c = 1; #10;

if (y !== 0) $display("001 failed.");

b = 1; c = 0; #10;

if (y !== 0) $display("010 failed.");

c = 1; #10;

if (y !== 0) $display("011 failed.");


Self checking testbench cont l.jpg

Self-checking Testbench (cont.)

a = 1; b = 0; c = 0; #10;

if (y !== 1) $display("100 failed.");

c = 1; #10;

if (y !== 1) $display("101 failed.");

b = 1; c = 0; #10;

if (y !== 0) $display("110 failed.");

c = 1; #10;

if (y !== 0) $display("111 failed.");

end

endmodule
