Presentation Transcript

Slide1 l.jpg

Assisted Reproduction


Endangered Species

Rick Mauldin & Collette Thepenier

BS640, Fall 2006

Slide2 l.jpg

What is an Endangered Species?

Defined by the Convention on International

Trade in Endangered Species (CITES)

Appendix I includes species threatened with extinction. Trade in specimens of these species is permitted only in exceptional circumstances.

Appendix II includes species not necessarily threatened with extinction, but in which trade must be controlled in order to avoid utilization incompatible with their survival.

Slide3 l.jpg

What is an Endangered Species?

“A species that is in danger of extinction and whose survival is unlikely if the causal factors continue; included are species whose numbers have been reduced to a critical level or whose habitats have been so drastically reduced that the species are deemed to be in danger of extinction.”

Slide4 l.jpg

Causes of Extinction

  • Habitat loss or degradation

    • agriculture

    • development

  • Overexploitation (hunting)

  • Competition/predation by invasive

  • species

  • Combinations of the above,

  • frequently with a triggering event,

  • i.e. natural disaster

  • Slide5 l.jpg

    World Conservation Union 2006 Red List



    Reptiles 341





    Slide6 l.jpg

    What is Assisted Reproduction?

    In humans:

    “The use of medical techniques, such as drug therapy, artificial insemination, or in vitro fertilization, to enhance fertility.”

    Expanded to include:

    Any directed action taken by humans to enhance reproduction in animals.

    Slide7 l.jpg

    Assisted Reproduction Techniques

    Divide the topic into two parts:

    1) Assisted reproduction with a technical

    component (mostly mammals)

    2) Assisted reproduction using various

    forms of population management

    The two are not mutually exclusive

    Slide8 l.jpg

    Assisted Reproduction Techniques

    • Artificial Insemination

    • Embryo transfer

    • In vitro fertilization

    • Semen/embryo sexing

    • Gamete/embryo micromanipulation

    • Somatic cell nuclear transfer (SCNT)

    • Genome resource banking

    Slide9 l.jpg

    Five Steps Necessary for Adoption of an

    AR Technique

    (from Swanson, 2006)

    • Technique development in a domestic

    • animal counterpart, if available

    • 2) Characterization of species-specific reproductive

    • biology in a targeted non-domestic animal

    • 3) Assessment of technique feasibility for producing

    • offspring

    • 4) Demonstration of adequate efficiency for applied usage

    • 5) Application of new tool for population management

    Slide10 l.jpg

    ‘Charismatic Megafauna’

    Animals that have popular appeal and so can form the basis of conservation campaigns and fundraising drives.

    Slide12 l.jpg

    World Wildlife Fund Logo

    Slide13 l.jpg

    Before we even begin:

    • For endangered species, lack of basic knowledge

      of reproductive cycles is a major impediment

    • How can information concerning estrous cycles/

      pregnancy be obtained when individuals are rare,

      restrictions exist on what may be done with


    • Fecal/urinary assays for steroid/hormone metabolites

      to indicate endocrine status

      • gorillas (Czekal, 1997)

      • pandas (Kersey et al. 2003)

      • killer whales (Pukazhenthi and Wildt (2004)

      • Ultrasonography also useful in following ovarian

      • cycles

    Slide14 l.jpg

    Artificial Insemination (AI)

    • Wild female trapped and fertilized with

    • sperm from zoo male, released, or vice

    • versa.

    • Major application is to avoid genetic

    • depression in fragmented populations

    • Assumes sperm can be collected

    Slide15 l.jpg

    “First, we are working with species that are

    often dangerous, if not homicidal” (Wildt, 2006)

    Slide16 l.jpg

    Artificial Insemination

    • Standard collection methods, i.e.

      • artificial vagina

      • vaginal condoms

      • electroejaculation (under anesthesia)

      • post-mortem epididymal

  • These can be difficult for:

    • non-domestic equids,

    • some great apes,

    • canids

    • marsupials (Pukazhenthi &Wildt, 2004)

  • Large interspecific differences in freshvs.


  • Slide17 l.jpg

    Artificial Insemination

    • Problems:

    • Ovulation must be induced or synchronized by

      exogenous gonadotropins which frequently do

      not work

    • Gross female anatomical differences, i.e two

      uteri in marsupials, complex cervix in oryx,

      rhinoceros, others.

    • Actual site of semen deposition frequently not

      known, usually transabdominally by

      laparoscope (invasive surgery)

    Slide18 l.jpg

    Artificial Insemination Successes

    • Conceptions:

    • gerenuk

      • (Litocranius walleri)

      • pacific white-sided dolphin

      • (Lagenorhynchus obliquidens)

      • Bottle-nosed dolphin

      • (Tursiops truncatus)

    Slide19 l.jpg

    Artificial Insemination Successes

    Live births:

    Persian leopard

    (Panthera pardus saxicolor)

    Spanish Ibex

    (Capra pyrenaica hispanica)

    Giant panda

    (Ailuropoda melanoleuca)


    (Acinonyx jubatus)

    Slide20 l.jpg

    Embryo Transfer (ET)

    Most important aspect is to pave the way for

    interspecies transfer

    Gaur born to a holstein

    (Stover, et al. 1981)

    Indian desert cat to a

    domestic cat (Loskutoff, 2003)

    Urial to a domestic sheep

    (Ullah et al. 2006)

    Little is know about embryo development or

    feto-maternal recognition in most species

    Slide21 l.jpg

    In vitro Fertilization

    Many attempts, few successes

    Requires oocyte collection, knowledge of ovarian

    cycles. Can use ovaries from dying animals.

    Pumas, tigers, cheetahs, Indian desert cats, gaur, elephants, gorillas, zebras, marmosets,

    minke whales, ocelots, springboks, many others

    Live births in only tigers, Indian desert cats, gorillas,

    and European mouflon

    Slide22 l.jpg

    Gamete/Embryo Micromanipulation

    • Intra-cytoplasmic sperm injection (ICSI)

    • Sub-zonal insemination (SUZI)

      • sperm placed between zp and vitelline membrane,

        • can lead to polyspermy

    • In clouded leopards and cheetah, up to 70% of

    • sperm may be deformed or abnormal.

    • ICSI allows selection of healthy sperm, but has

    • not been applied to endangered species yet.

    Slide23 l.jpg

    Semen Sexing

    • Great potential in single-sex dominated social

    • structures (O’Brien et al. 2002)

    • Excessive males can play havoc with small

    • population management

    • Used successfully in gorillas in conjunction

    • with IVF and ICSI (O’Brien et al. 2002)

    Slide24 l.jpg

    Somatic Cell Nuclear Transfer (SCNT)

    • Has been attempted in:

    • giant panda (Chen, et al. 2002)

    • Argali sheep (White et al. 1999)

    • gaur (Lanza et al. 2000)

    • but these attempts did not result in viable offspring

    • Apparently healthy offspring resulted in trans-

    • species cloning in mouflon sheep (Loi, et al. 2001)

    • (mouflon granulosa nuclei to enucleated sheep oocyte)

    Slide26 l.jpg

    Small Cat Species

    Survival Plan

    Black-footed cat

    Fishing cat

    (Prionailurus viverrinus)

    Arabian sand cat

    (Felis margarita)

    Pallas’ cat

    (Otocolobus manul)

    Brazilian ocelot

    (Leopardus pardalis mitis)

    (Felis nigripes)

    Slide27 l.jpg

    ART Success Story

    The Wild European Mouflon sheep

    (Ovis musimon)

    • Oocytes collected, then matured and fertilized in vitro

    • After cryopreservation, 10 pairs of blastocysts were

    • transplanted into 10 recipient domestic ewes.

    • Results: 4 live offspring

    Slide28 l.jpg

    The Story So Far……..

    • ART shows great promise for enhancing

    • reproduction in endangered species

    • To date, reality has not kept up with “hype”,

    • results are inconsistent, usually failure. These

    • techniques require much more R&D

    • Many species do not have the time to wait, and

    • ART is expensive and represents an investment

    • that can be used elsewhere

    • Disparity between promise and deliverable

    • results has caused conflict between ART

    • researchers and wildlife biologists

    Cryopreservation l.jpg


    • Inhibits all biological activity, esp. that which leads to cell death or deterioration

    • Use Vitrification Agent to prevent crystalline formation via the conversion of cellular material to an amorphous glass-like solid

    • CONS:

      • Species differences in cryosensitivity

        - Nieman and Rath, 2001

      • No standard Vitrification method

        - Andrabi & Maxwell, 2006

    Genome resource banking l.jpg

    Genome Resource Banking

    • Goal: To create depositories of germplasm as an interface between ex situ and in situ conservation programs- Holt and Pickard, 1999

    • GRB can be tool for managing the exchange of genetic diversity among endangered species by facilitating the creation of a global gene pool- Hanks, 2001

    • One of the most effective ways to conserve genetic resources is by establishing cryocollections and cryobanks of endangered and industrially important species- Katov, 2006

    Slide31 l.jpg

    - Holt and Pickard, 1999

    Genome resource banking32 l.jpg


    Semen Banks


    Embryo or Oocyte Banks

    Primordial Follicles

    Fertilized Oocytes

    Tissue Graft Banks

    Ovarian Tissue

    Testicular Tissue

    Genome Resource Banking

    Pros cons l.jpg

    Pros & Cons

    • Semen Banks

      • (+): Heterozygosity; DEC in captive ♂ and in mvmt of animals

      • (-): Low efficiency in sperm production – Paris, et al., 2004

    • Embryo or Oocyte Banks

      • (+): Storage of full or half complement of DNA to preserve heterozygosity

      • (-): Cryobiology of Embryo & Oocyte viability relatively unknown – Andrabi & Maxwell, 2006

    • Tissue Graft Banks

      • (+): Age, Cycle doesn’t matter; Can collect from carcasses of unknown etiology; Future with SCNT – Cleary et al., 2006; Snow et al., 2001

      • (-): More research needed to identify sources of suitable cells

        – Andrabi & Maxwell, 2006

    Slide34 l.jpg

    - Holt and Pickard, 1999

    Assisted artificial l.jpg

    Assisted ≠ Artificial

    Ex situ conservation l.jpg

    Ex situ Conservation

    Entrance to the Bronx Zoo in New York

    • “Off-site” Conservation

    • Protection via the removal of a species from unsafe or threatened habitat and placing the entire population (or some portion of) under human care

    Ex situ conservation37 l.jpg

    Ex situ Conservation


    • Zoos & Breeding Centers

      • Maintain whole, protected specimens for breeding and reintroduction into the wild when necessary and possible

      • Education of Public

    • “Frozen Zoo”

      • Gene Banks, consisting of cryogenic facilities used to store living sperm, eggs, or embryos

    Ex situ conservation38 l.jpg

    Ex situ Conservation


    • Helpful, but insufficient to save species from extinction

      • Cannot recreate natural habitat or the adaptation/evolutionary selection that would occur therein

    • Assisted Reproductive Technologies are very $ COSTLY $

    Slide39 l.jpg

    “[T]he long-term survival of most endangered species depends not only on our ability to prevent further losses but also on our ability to increase their populations by restoring degraded habitats, often on private lands.”

    - Wilcove & Lee, 2004

    In situ conservation l.jpg

    In situ Conservation

    • “On-site” Conservation

    • Protection of a species in it’s natural habitat either by protecting or cleaning up the habitat itself, or by defending the species from predators

    In situ conservation41 l.jpg

    In situ Conservation


    • Allow species population to recover in its natural environment, in which adaptations have evolved naturally

      Essentially Involves Habitat Protection from:

    • Human Intrusion & Destruction

    In situ conservation42 l.jpg

    In situ Conservation


    • Endangered Species Act

      • Prevent Gov’t Agencies or Private Individuals from inflicting further harm on a species once it has been declared Endangered

      • BUT it does NOT require private citizens to undo past deeds for the sake of recovery – so…

    • Incentive-based Programs

      • Safe Harbor (>>> success)

      • Environmental Defense’s Landowner Conservation Assistance Program (>>> success)

      • Conservation Banking (> success)

        - Wilcove & Lee, 2004

    Zoo biologists vs wildlife managers l.jpg

    Zoo Biologists vs. Wildlife Managers

    So who is right?

    …they BOTH are

    Strategies l.jpg


    • Captive Breeding Programs

      • Small # of Founder Individuals

      • Entire Population

        • Black Footed Ferrets

    Mustela nigripes

    Strategies cont d l.jpg


    Lynx canadensis

    • Reintroduction

      • Translocation of Wild Members

        • Canadian Lynx

          • Continuous release of wild caught members into wild to compensate for high initial mortality

      • Captive Bred

        • Whooping Crane

          • Show the birds their migration path

    Grus americana

    Strategies cont d46 l.jpg


    • Reduction in Disease/Pollution

      • California Winter Run Chinook Salmon

        • Clean up heavy metal leaching into water

      • Peregrine Falcon

        • Ban DDT pesticide

    • Predator Removal

      • California Least Tern

        • Common Crow

    Oncorhynchus tshawytscha

    Sterna antillarum browni

    Falco peregrinus

    Strategies cont d47 l.jpg


    Enhydra lutris

    • Laws Against Poaching & Illegal Collecting

      • Southern Sea Otter

      • Galapagos Tortoise

    • Development Legislation & Restrictions

      • Grizzly Bears

        • Banning development in areas that would fragment habitat and thus increase human interaction

    Geochelone nigra

    Ursus arctos

    Strategies cont d48 l.jpg


    • Habitat Acquisition & Restoration

      • Rainforest

        • Blue Poison Arrow Frog

      • Wetlands

        • Bog Turtle

    Dendrobates azureus

    Clemmys muhlenbergii

    Strategies cont d49 l.jpg


    • Reducing Inbreeding

      • Florida Panther

        • Introduce Texas Mountain Lion to wild population

    • Public Cooperation

      • Karner Blue Butterfly

        • Don’t mow lawns later in summer to avoid interference with butterfly eggs

    • Ranching Program

      • American Alligator

        • Eggs are purchased from landowners

    Puma concolor coryi

    Alligator mississippiensis

    Trage dies l.jpg


    • Unavoidable…

      • Accidents/Disaster

        • Puerto Rican Parrot

          • 1989 Hurricane Hugo

        • Leatherback Sea Turtle

          • 2004 Tsunami

      • War

        • Mountain Gorillas

          • Civil War in Rwanda

    Amazona vittata

    Dermochelys coriacea

    Gorilla berengei berengei

    Slide51 l.jpg

    - Holt and Pickard, 1999

    Financial considerations l.jpg

    Financial Considerations

    • There is no such thing as a Million-Dollar Ocelot

    • But there is such a thing as a Million-Dollar Bull

    Slide53 l.jpg

    - Holt and Pickard, 1999

    Take home message l.jpg

    Take Home Message:

    Synergistic Approach!

    • Use both ART and ARM:

      • Neither are sufficient by themselves (at present)

    • ART has potential for success in the FUTURE

    • ARM can keep problems from getting worse TODAY

      ART + ARM=Success

    Questions l.jpg


    Thanks l.jpg


    If you would like copies of the slides

    or a list of citations, please email:

    Collette Thepenier

    Rick Mauldin

  • Login
