Presentation Transcript

Fy 2008 2009 2010 o m program l.jpg
FY 2008/2009/2010 O&M PROGRAM Conference

*Includes $5.7M for Mooring Cells and Lock Closures

*Includes $1.8M for Water Control Manuals

*Includes $550K for Water Control Manuals

*American Recovery and Reinvestment Act (ARRA)

**Received an additional $4 Million Supplemental Funding for Dredging


Tenn tom o m funding for fy02 fy09 president s budget appropriations l.jpg
TENN-TOM O&M FUNDING FOR FY02 – FY09 Conference(President’s Budget + Appropriations)


American recovery and reinvestment act arra o m funding by business program l.jpg
American Recovery and Reinvestment Act (ARRA) Conference O&M Funding by Business Program

$48.6M

$5M

$105.5M

$59.1M

$9.5M


Mobile harbor turning basin l.jpg
Mobile Harbor Turning Basin Conference

  • Type of Work: New

  • Depth: 45 Feet

  • Quantity: 2.6Mcy

  • Type of Material: Sand, Silt and Clay

  • Disposal Area (D/A): Upland/Ocean

  • Distance to D/A: 35 miles (Ocean)

  • Type of Equipment: Bucket/Pipeline

  • Contract Awarded: 8 Jul 09

  • Contractor: Great Lakes D &D Co.

  • Start Work: Around late Aug 09

  • Completion: Projected in March 2010

Project Costs

CG Federal $6M

CG Non-Federal $2M

ARRA Federal $16M

ARRA Non-Federal $5M

Total $29M


Slide6 l.jpg
ARRA Conference

  • Key Focus Areas:

    • Job Preservation and Creation

    • Infrastructure Investment

    • Energy Efficiency

  • Projects

    • Backlog Maintenance/Buy Down Risk

    • Energy Efficiency

  • Focus on quick execution/job creation

  • Cooperation of users during outages


Arra key projects l.jpg
ARRA Conference(Key Projects)



Ttww dredging program l.jpg
TTWW DREDGING PROGRAM Conference

FY2007 Work

  • Inland Dredge KELLY L

  • 10 July – 21 August 2007 (43 days)

  • 4 Most Critical Locations

  • Approximately 10,000 linear feet of bars, 191,000 cubic yards of material removed

  • Several locations werenot dredged due to funding limitations

FY2008 Work

  • No Project Contract due to funding limitations

  • Issued Task Order to Shared 16”/24” Dredge Contract with Coastal Project

  • Dredged 2 Locations

  • Approximately 6,500 linear feet of bars, 130,000 cubic yards of material removed

  • Increased Survey Efforts to Monitor Channel Conditions

  • “Hot Spots” Removed with R.W.DAVIS


Ttww 2009 dredging program l.jpg
TTWW 2009 DREDGING PROGRAM Conference

Supplemental Funding

  • Received $4 million

  • ENCO Dredge “EDWARD G” (subcontract to Mike Hooks, Inc.)

  • Approximately 9 bars – 225,000 cy

ARRA Funding

  • Received $8 million

  • $4.2M Committed for 2009 (balance carry over to FY10)

  • Inland dredge “INGENUITY”

  • Approximately 8 bars – 350,000 cy


Dredge material removal work l.jpg
DREDGE MATERIAL REMOVAL WORK Conference

  • Regain critical disposal capacity

  • Agreements for removal of materials

  • Beneficial use of materials

    • Barge to Louisiana & Gulf Coast

    • Truck to local markets

  • Approximately 200,000 cubic yards removed


Slide12 l.jpg

O&M CONTRACT Conference

  • TTW’s O&M Contract expired September 30, 2008.

  • Maintenance work performed under BWT’s O&M contract from October 1, 2008 through April 8, 2009.

  • New TTW O&M contract awarded April 7, 2009.


Lock closures l.jpg
LOCK CLOSURES Conference

  • Selden Lock: September 9 – October 8, 2009

  • Coffeeville Lock: September 11 – October 1, 2009

  • Bankhead Lock: September 14 – October 4, 2009

NOTE: Next Scheduled Lock Closures on the Tennessee-Tombigbee Waterway (2011) are Wilkins Lock, Bevill Lock and Heflin Lock.



Slide15 l.jpg

Remove a portion of the island and dredge to elevation 116.0 Conference

Remove dogleg and 100 feet of existing spur dike

Dredge the upper approach to elevation 110.0


Slide16 l.jpg

Construct a system of nine submerged bendway weirs Conference

Relocate the Snagboat Montgomery


Aquatic plant management l.jpg
AQUATIC PLANT MANAGEMENT Conference

  • O&M Contract

    • Treated To Date – 778 acres

    • Projected Through End of FY – 775 acres

  • ARRA - Helicopter Contract (Projected Through End of FY)

    • Floating Plant Treatment – 1400 acres

    • Submersed Plant Treatment – 1000 acres


Questions l.jpg
QUESTIONS? Conference


Tennessee tombigbee waterway canal section levee certification l.jpg

Tennessee-Tombigbee Waterway ConferenceCanal Section Levee Certification

20 August 2009


Slide21 l.jpg

Certification Conference

  • PAL > Analyses > Report > FEMA

  • 2 yr. max.

  • Monroe, Itawamba, Tishomingo counties

  • 31 August deadline to sign request or decline to seek accreditation


Slide25 l.jpg

Certification Requirements Conference

  • 44 CFR 65.10 and complementary USACE and FEMA regs

  • Required report Submittals

    • Engineering Analyses

    • Operations and Maintenance Plans

    • As-Builts

    • Stamped by Engineer

    • USACE requirements more comprehensive and exhaustive


Slide26 l.jpg

Issue Conference

Authority – Public Law 79-525, 79th Congress, 2d Session, enacted July 24, 1946.

Two-way barge traffic, no provisions in the authorization for flood control protection . . .


Slide27 l.jpg

Issue Conference

Certification – no analyses exist that refute or demonstrate flood control performance; required analyses are extensive.

Hydraulics, geotechnical, vegetation compliance, O&M . . .


Slide29 l.jpg

Issue Conference

Vegetation – currently heavily wooded, can not certify unless vegetation and roots removed.

Would also require increased annual O&M to sustain levee requirements. . .




Slide33 l.jpg

Issue Conference

Wildlife Mitigation – Wooded areas on levee are part of Tenn-Tom mitigation lands.

Clearing would likely require acquisition of replacement lands. . .
