Contents. Reef / Seagrass / Mangrove RelationshipsWhat is Seagrass?Where does seagrass grow?Seagrass Diversity
E N D
1.
2. Contents Reef / Seagrass / Mangrove Relationships
What is Seagrass?
Where does seagrass grow?
Seagrass Diversity & Anatomy
Seagrass Community
Physical Parameters
Inhabitants of Seagrass
Seagrass Ecology / Services
Nurseries
Threats to Seagrass
CCMI Seagrass Research
3. Reefs, Sea Grasses & Mangroves Relationships Coral reefs, seagrass beds and coastal mangrove systems are closely connected.
4. Seagrass – Mangroves – Reefs Sea grasses trap sediment and slow water movement
Corals thrive in clear, sediment-free water
Seagrass benefits coral by reducing sediment loads.
Barrier reefs form lagoons protected from waves, which allows mangrove and seagrass communities to develop.
Mangroves trap sediment, reduce the load on seagrass and corals.
Seagrass sediments form substrate that can be colonized by mangroves.
5. What is seagrass? The only true flowering plants that can live completely underwater!
Possess true roots, stems and leaves
Require certain physical conditions to grow
Provide food and habitat for many creatures
Main diet of juvenile sea turtles, manatees, crabs, shrimp, and a variety of juvenile fishes
6. Where is seagrass in the world? Seagrass beds cover less than 10% of the world's shallow coastal waters, but are important nursing grounds for commercial fish species
Greatest diversity: Indo-Pacific region
Located along the coast of all continents except Antarctica
7. Where does seagrass grow? Must be fully submerged
Require saltwater to grow
Thrive in warm temperatures: 20-30°C
Require light for photosynthesis
Grow in shallow, coastal waters
Root system needs a stable soft-bottom habitat
8. Diversity of Seagrass
9. Biodiversity of Seagrass
10. Turtle grass anatomy
11. Types of Sea grasses Left: wigdeon grass, Johnson’s grass;
Right top to bottom: star grass, manatee grass, shoal grass;
Below: Turtle grass, Paddle grass
12. Location Turtle- Florida, Caribbean, Bermuda, area between Gulf of Mexico and Venezuela
Manatee- Florida, Bermuda, Bahamas, Gulf of Mexico, Caribbean
Shoal- North Carolina, along the Atlantic, coast of Gulf of Mexico, Caribbean
Johnson’s- Indian River Lagoon
Paddle- near Indian River Lagoon, Gulf of Mexico, Caribbean, Indo-West Pacific
Star- Florida, Bahamas, Texas, West Indies
Widgeon- Atlantic coast (New Foundland-Texas)
13. Seagrass Community Food Chain
14. Physical Parameters of Seagrass Communities Temperature
Typical Caribbean shoreline temperature: 26-30°C
Thalassia thrives in 20-30°C
Large scale senescence (leaf loss) occurs in extreme temperatures
Salinity
Greatest photosynthetic activity between 34-36 psu
Leaf loss and drop in photosynthetic activity below 24 psu
Significant damage caused by lots of fresh water runoff during storms or water management (i.e. the Everglades)
Current and Sediment Depth
Slower current = greater sediment depth
Greater sediment depth = increases in seagrass bed elevation, leaf density and leaf length
15. Inhabitants of Seagrass Beds Infauna
Protozoan and metazoan invertebrates that burrow in the sediment and rhizomes
Feed on sediments, filter feed or feed in water column nocturnally
Epiphytes
Organisms living on stems and leaves
Epiphytic algae, bryozoans, polychaetes, small amphipods
Epifauna
Organisms living on the sediment
Conspicuous invertebrates – starfish, sea urchins, queen conch
Nekton
Organisms swimming in canopy – fishes and sea turtles
16. Conch in Sea Grass Sea grasses grow in just a few inches of water.
Sea grasses need a lot of light to photosynthesize, so they only grow to depths to 3 - 4’.
17. Sting Ray This sting ray is a predator eating small squid, shrimp and other animals that it finds in the grass.
They look scary, but they are really friendly and don’t bite.
They eat by sucking up their prey as they have no teeth.
18. Green Sea Turtles This turtle swims above the sea grass in the lagoon.
Sea grass is a favorite food of green sea turtles.
19. Manatees& Dungeons Manatees are herbivores that also live off of the sea grass.
They are found mostly in Florida waters and in the Great Barrier Reef, Australia.
They are slow swimmers and prefer grazing in quiet, shallow areas.
20. Ecosystem services: Seagrass beds protect against shoreline erosion, home for a huge diversity of marine life, food for turtles, and help to create clear waters.
21. The Ecological Roles of Seagrass Ecological Importance:
Nursery habitat
Foraging habitat
Stabilize sediments
Absorb excess nutrients
Also provide coastal protection from erosion and water purification, absorb CO2, and stabilize sediments
22. Seagrass Beds as Nurseries Seagrass ecosystems host a rich diversity of species, including threatened and commercially important species:
Dugongs
Seahorses
Conch
Grouper
Sea turtles
Snapper
Shrimp
Blue crabs
Scallops
What other species do we see in seagrass beds?
23. Threats to Seagrass Ecosystems fishing by benthic trawling
clearance for beaches and tourist facilities
fishing by benthic trawling
clearance for beaches and tourist facilities
24. Threats to Seagrass Ecosystems
25. Natural Threats Wasting disease (caused by marine slime mold?)
Storms
Wind-driven waves
Marine animals disturbing sea grass
Imbalance in marine grazers / predators
26. Protection Boating
Do not disturb eelgrass beds (avoid if possible)
Stay within marked channels
Slower in shallower areas
Make propeller wash effect lower in shallower areas
Use pumpout stations to dispose of waste
Shell fishing
Do not use clam rakes or tongs in areas of eelgrass
When dredging for bay scallops- dredge should be rigged and working properly
27. Protection (cont’d) Daily Activities
Do not put trash or pollutants in the estuary
Do not use harmful fertilizers and pesticides
Wash Cars in commercial car wash or on lawn (prevents excess soap from draining into local waterways)
Educate others about the benefits of sea grass
28. Seagrass in the Protection of the Reef This aerial was taken from the airplane above Little Cayman Island.
A patch reef and areas of sea grass can be seen in the lagoon between the land and the fringing reef.
29. Patch Reef Ecological Importance:
Nursery habitat
Foraging habitat
Stabilize sediments
Absorb excess nutrients
30. Patch Reefs
31. Green Sea Turtles Sea turtles spend their juvenile years eating and growing in near-shore habitats such as patch reefs.
Once they reach adulthood they migrate to different feeding grounds.
32. Seagrass Ecology Angiosperms = True flowering plants
True roots, stems, flowers and leaves
Five Characteristics of Ecological Success:
Ability/need for saline medium
Function physiologically while fully submerged
Well-developed anchoring system
Ability to reproduce while submerged
Ability to compete for space and resources
33. Seagrass Study Methods CCMI measures standing crop biomass (above ground) and total biomass (standing crop + below ground)
Four randomly placed cores per site
Light attenuation using Secchi disk
4 random quadrats along 5 transects to evaluate % cover per species
34. Seagrass Study Methods Use corer to get 40-50 cm deep, rotating through the sediment
After collection:
Sort by species
Sort Thalassia by material:
Green leaves
Non-green leaves and bundle sheath
Rhizomes
Live roots
Dead belowground material
Sort other species as green or non green
Clean samples from carbonates and sediments
Toothbrush
HCl acid soak – 5 min; Rinse
Dry to constant weight to calculate dry weight per m2
35. Seagrass Productivity Studies Six 10x20 cm quadrats randomly marked at each site
all the seagrass within each quadrat will be marked
poke a needle hole a short distance above the green-white interface of the leaves, making sure to do all leaves on a shoot at once
return to collect them after 10 days
1) Daily Production = (Weight of new leaves + Weight of old growth) x 50 # of days marked
2) Turnover Rate (%/day) = (Daily Production x 100)/(Standing Crop)
36.
37. Citations http://www.flmnh.ufl.edu/Fish/southflorida/seagrass/profiles.html
http://www.flmnh.ufl.edu/fish/southflorida/seagrass/importance.html#product
http://www.unep-wcmc.org/marine/seagrassatlas/introduction.htm
http://www.sms.si.edu/IRLspec/Seagrass_Habitat.htm
http://www.dnr.state.md.us/boating/pumpout/pumpout.html
www.wikipedia.org
