Presentation Transcript
Slide1 l.jpg
AMS-02 Thermal Vacuum and Thermal Balance Tests in the Large Space Simulator at ESTECJ. BurgerAMS-02 TIMCERN, July 23, 2004


Slide2 l.jpg
Two Meetings at ESA/ESTEC Space Simulator at ESTECNoordwijk, Netherlandsto request overall AMS-02 TVTin Large Space Simulator (LSS)

  • June 11 2003 - Presentation of AMS request to ESA

    S.C.C. Ting Martin Zell Head of Human Spaceflight ESA

    Martin Pohl Wolfgang Supper Head of Thermal ESTEC

    Joseph Burger Jean Jamar Head of Testing ESTEC

    Robert Becker

  • July 3, 2003 – Follow-up Meeting

    Joseph Burger Jean Jamar Head of Testing ESTEC

    Marco Molina Wolfgang Supper Head of Thermal ESTEC

    Alexander Grechko Gaetan Piret Test Manager ESTEC

    Peter Berges R. Effenberger Managing Director ETS

    Y. Hoyet ESTEC

    Matin Zell Head of Human Spaceflight ESA


Lmso visit to lss l.jpg
LMSO Visit to LSS Space Simulator at ESTEC

  • Trent Martin, Phil Mott, Ross Harold, and Craig Clark were at ESTEC last year for planning acoustic test.

  • Also visited the Large Space Simulator


Large space simulator dimensions useable volume diameter 9 5m height 10m l.jpg
Large Space Simulator Dimensions Space Simulator at ESTECUseable Volume: diameter 9.5m, height 10m


Our original request from esa estec l.jpg
Our Original Request from ESA/ESTEC Space Simulator at ESTEC

  • Test equipment

    300 temperature sensors with DAS and cables (provided in advance)

    Test heaters or IR lamps (TBC)

    Cabling: Power (120VDC) and data, including fiber optics (provided by ESTEC: cables inside the chamber, feedthrough, cables outside chamber to control room)

    Corrugated stainless steel tubes from AMS02 venting ports to external vacuum pumps for He and TRD gas venting

  • Space

    Clean room area 150 m2, with 8m crane height

    40 m2 control room for ~13 people with pc/control terminals

    ~30 m2 storage room for shipping equipment

  • Personnel - people to operate facility, plus 2 people full time during integration/deintegration (plus crane drivers, …)

  • Office space for 10-15 people including phones, fax, xerox, network plugs

  • Other – list of elecrical and vent feedthroughs needed

  • Time – original request 42 days in chamber plus 3 weeks installation and checkout, 2 weeks deinstallation and shipping

  • Mechanical and electrical interface data

  • Thermal model of LSS in SINDA/TRASYS and support in using it


Slide8 l.jpg
90 ton seismic block can support 60 tons Space Simulator at ESTECexternal dimensions 3.2m x 3.2 mmechanically decoupled from LSS and building



Vacuum system typical pumping times l.jpg
Vacuum system typical pumping times Space Simulator at ESTEC


Vent lines needed for he and trd gas l.jpg
Vent lines needed for He and TRD gas Space Simulator at ESTEC

  • The turbomolecular pumps cannot handle the nominal He venting rate of 2 mg/s, nor a TRD gas venting, and a cryopump won’t work on He

  • Vent lines are needed for normal He and TRD gas venting and venting from the cryosystem burst disk outputs


Shrouds and nitrogen supply l.jpg
Shrouds and Nitrogen Supply Space Simulator at ESTEC

  • C1 covering the main chamber

    LN2 mode (<100K)(max. heat load 170kW)

    or GN2 mode (150-350K) (max. heat load 10kW)

  • C2 covering the auxiliary chamber – LN2 mode only


Solar simulator l.jpg
Solar Simulator Space Simulator at ESTEC

  • Horizontal beam 6m diameter, 5m deep

  • Maximum intensity at nominal lamp power 2000W/square meter

  • Intensity distribution in reference plane within +/-4%


Thermal data handling l.jpg
Thermal Data Handling Space Simulator at ESTEC

  • Thermocouple recording

    - 864 t/c internal

    - 216 t/c direct

  • Platinum sensors

    - 98 Pt100

    - 8 Pt500

  • Power supplies (P-U-I)

    40 PSU 24 W - 40V – 0.6A

    94 PSU 240 W – 80V – 6A

    Possibility to record other signals using external scanners

    Possibility to send some information using RS232 link to EGSE

    A total of 2000 channels with a minimum scan time of 30 seconds

    User interface using Dynaworks real time display


Wp1 standard facility preparation seismic block configuration l.jpg
WP1 – Standard Facility preparation (seismic block configuration)

  • Chamber configuration

  • Meetings

  • Procedure reviews

  • Data handling configuration


Wp2 ams specific preparation prior to pre test l.jpg
WP2: AMS specific preparation prior to pre-test configuration)

  • Provision of t/c harness (300 t/c) (no special calibration)

  • Provision of internal harness including loan of vacuum connectors

  • Provision of Helium venting line

  • Provision of test heater/IR lamp setup (to be clarified)

  • Support during installation of the compact superfluid cooling system around the chamber

  • Support during installation of the specimen support stand

  • Installation of test heater/IR lamp


Wp3 4 days of pre test l.jpg
WP3: 4 days of pre-test configuration)

  • 4 days of pre-test in VTC modes

  • Standard post test activity for facility and data handling

  • Pre-test facility data report

    Note: Pre-test is to check the facility configuration including new flanges for line feedthrough,

    submit to vacuum all the test aids (test support stands, piping, test harness,…)


Wp4 satellite preparation support l.jpg
WP4: Satellite preparation support configuration)

  • Support to customer during installation of the specimen (2 persons/3weeks)

  • Verification of specimen instrumentation

  • Chamber close-out

  • Normally, we have to do our own handling (crane operations) of the AMS-02 payload


Wp5 42 days of tb tv test l.jpg
WP5: 42 days of TB/TV test configuration)

  • 42 days of TB/TV test including 28 days of TV test and 14 days of sun illumination


Wp6 post test activities l.jpg
WP6: Post-Test Activities configuration)

  • Support for satellite removal (2 persons/1 week)

  • Standard data handling post test activities (including 1 set of all data in electronic format)

  • Standard facility post test activities

  • Preparation of facility data report

  • Support during specimen support stand


Wp7 general support l.jpg
WP7: General Support configuration)

  • Preparation of office, check-out area and clean room

  • 150 sq.m. clean room class 100,000 during 12 weeks

    (assembly area)

  • 30 sq.m. clean room class 100,000 during 12 weeks

    (shipping equipment storage)

  • 40 sq.m. clean room class 100,000 during 12 weeks

    (this is requested control room)

  • Provision of offices for 15 persons incl. Phones, FAX, access to copying machines during 12 weeks

  • Cleaning of equipment entering the clean room


Estec meeting outcome l.jpg
ESTEC meeting outcome configuration)

  • A new stand for the TV/TB tests will be designed and manufactured by AMS Collaboration

    (Shandong University will send a mechanical engineer to stay at CERN, who will work on designing the stand with Robert Becker)


Estec feedback action items l.jpg
ESTEC feedback configuration)Action Items

1. AMS Collaboration should try reducing time spent inside LSS to 30 days.

2. ESTEC will investigate the sensitivity of the facility vacuum gauges to the magnetic field

3. Thermal model of LSS delivery in the requested format (SINDA/TRASYS) will be confirmed end of August, 2003

4. AMS Collaboration to check how long AMS can be disconnected from the vacuum pump


Status of action items from july 3 2003 meeting 1 l.jpg
Status of Action Items from configuration)July 3, 2003 Meeting (1)

  • We confirm 30 day thermal vacuum/balance test schedule, while recommending reserving ~12 days contingency, because of the complexity of the cryogenic system


Slide25 l.jpg


Preliminary tv test schedule 30 days l.jpg
Preliminary TV-Test schedule: needed for the 30 days


Response for action item 1 l.jpg
Response for Action Item 1 needed for the

Geneva, September 18, 2003

Dear Dr. Zell,

After discussion of the studies of the times needed to obtain stable conditions during thermal vacuum

cycling and thermal balance, we can confirm that we request thirty days in the Large Space Simulator

for the thermal vacuum test of the AMS-02 experiment. This time includes allowance for pump down of

the chamber, cycling to the highest and lowest permissible non-operating temperatures, four thermal

cycles to the hottest and coldest operating temperatures, hot and cold thermal balance tests, followed

By return to ambient conditions, as shown in the accompanying preliminary schedule.

Following the suggestion of Dr. Eric Ettlinger we wish to report to you that you may want to set a

contingency of the order of twelve days in the test time to allow for the possibility of unexpected

difficulties during the test, especially because of the complexity of the superconducting magnet

cryogenic system with 2500 liters of superfluid helium.

With best regards,

Joseph Burger

cc: Jean Jamar

Gaetan Piret

S. C. C. Ting


Status of action items from july 3 2003 meeting 2 l.jpg
Status of Action Items from needed for the July 3, 2003 Meeting (2)

  • G. Piret says he has not yet gotten a response from manufacturer on ability of LSS vacuum gauges to withstand 5 gauss field at walls.

  • We offer to make a test in a weak field if ESTEC supplies a probe and its electronics.


Action item 3 l.jpg
Action Item 3 needed for the

  • LSS Geometrical Mathemetical Model and Thermal Mathematical Model available only in ESATAN/ESARAD (developed by ESA)

  • We asked model be translated into SINDA/TRASYS (used by NASA and most others)

  • We were told this would probably be possible, but no answer came

  • Now told they will help support the translation. Two thermal engineers from SDU are now at CERN and will work on this with ESTEC and CGS


Status of action items from july 3 2003 meeting 4 l.jpg
Status of Action Items from needed for the July 3, 2003 Meeting (4)

  • S. Harrison confirms cryosystem can remain disconnected from vacuum pump at least one day, so there is no danger of losing superfluidity in case of a crane failure while installing AMS-02 in the LSS


Conclusion l.jpg
Conclusion needed for the

  • Martin Zell and Wolfgang Supper have stated they do not expect any problem for ESA/ESTEC supporting the AMS-02 thermal vacuum test

  • M. Zell has funds to start support for test studies and preparation this year
