Presentation Transcript
Introduction to hepatitis b and c for healthcare workers l.jpg

Introduction to hepatitis B and C for healthcare workers

ศตวรรษ ทองสวัสดิ์

ภาควิชาอายุรศาสตร์


Slide3 l.jpg

1910.1030(f)

Hepatitis B Vaccination and Post-exposure Evaluation and Follow-up --

..1910.1030(f)(1)

1910.1030(f)(1)

General.

1910.1030(f)(1)(i)

The employer shall make available the hepatitis B vaccine and vaccination series to all employees who have occupational exposure, and post-exposure evaluation and follow-up to all employees who have had an exposure incident.


Slide4 l.jpg

1910.1030(f)(2)

Hepatitis B Vaccination.

1910.1030(f)(2)(i)

Hepatitis B vaccination shall be made available after the employee has received the training required in paragraph (g)(2)(vii)(I) and within 10 working days of initial assignment to all employees who have occupational exposure unless the employee has previously received the complete hepatitis B vaccination series, antibody testing has revealed that the employee is immune, or the vaccine is contraindicated for medical reasons.


Slide5 l.jpg

Acute hepatitis

Resolution

Chronic hepatitis

cirrhosis

Hepatocellular carcinoma

Death



Slide7 l.jpg

Hepatitis B

  • Incomplete circular DNA virus

  • Four overlapping genes: S, C,P and X

  • Family: Hepadna virus

  • Human, woodchuck, squirrel, Peking duck

  • Replicate as the retrovirus


Slide8 l.jpg

Hepatitis B

A. The HBV invades the cell by binding to surface receptors

B. the virus is taken up by the cell

C. enzymes extend the S(+) strand to form a covalently closed circular double-stranded DNA (CCC-DNA)

D. The HBV genome in its core migrates to the nucleus

E.& F. Additional viral structural protein messenger RNAs pass into the cytoplasm and are translated

G. The pregenome and viral DNA polymerase are packaged into new capsids

H.& I. The pregenome is then destroyed. The L(−) strand (H) is then used as a template for formation of the S(+) strand

J. the mature cores (I) are packaged into HBsAg particles, which accumulate in the endoplasmic reticulum and exit the cell


Slide9 l.jpg

Symptoms

anti-HBe

HBeAg

Total anti-HBc

Titer

anti-HBs

IgM anti-HBc

HBsAg

0

4

8

12

16

24

28

32

52

100

20

36

Weeks after Exposure

Hepatitis B acute infection and resolution


Slide10 l.jpg

Typical Serologic Course

Acute

(6 months)

Chronic

(Years)

HBeAg

anti-HBe

HBsAg

Total anti-HBc

Titer

IgM anti-HBc

Years

0

4

8

16

20

24

28

36

12

32

52

Hepatitis B acute infection turn into chronicity

Weeks after Exposure


Slide11 l.jpg

Hepatitis B

  • Incubation period 30-180 days, mean 60-90

  • Perinatal transmission and intimate contact between toddlers are the important transmission routes

  • 350 million HBsAg carriers worldwide


Slide12 l.jpg

HBsAg Prevalence

³8% - High

2-7% - Intermediate

<2% - Low

Prevalence of chronic hepatitis B


Slide13 l.jpg

Chronic HBV

Asymptomatic with normal ALT

HBe +, HBV DNA +

Spontaneous HBe to Anti-HBe: rare

Immune tolerance

15-35 yr.

Adult acquired

Symptoms +

Increase ALT with active histology

HBV DNA + but usually low

HBe to Anti-HBe : 2.7-25% /year

Immune clearance

rapid

silence

prolonged

fluctuating

No symptom with normal ALT

HBeAg -, HBsAg + (cytoplasm),

HBV DNA (host DNA)

Nonreplicative


Slide14 l.jpg

Natural History of Chronic HBV Infection

CompensatedCirrhosis

90-95% Resolution

Stabilisation

15-25%

Liver Cancer

AcuteInfection

ChronicHepatitis

Cirrhosis

Death

DecompensatedCirrhosis

(Death)

5-10% Chronic Carrier

Progression

30–50 Years

Adapted from Feitelson, Lab Invest 1994


Slide15 l.jpg

The new concept of ‘carrier’

  • All with HBsAg-positive should be called chronic hepatitis B (CHB), with consideration of

    • Virologic (HBeAg status, viral load)

    • Biochemical (ALT level)

    • Histological status

  • Then consider as “active” or “inactive carrier state”

  • “Inactive carrier state” is

    • HBeAg-negative

    • Normal ALT, viral load < 105

    • Very mild necroinflammation (HAI score < 3), no fibrosis


Slide16 l.jpg

Carrier vs chronic hepatitis

Depends on ALT

  • Carrier has normal ALT at every 6 months for at least 3 years (6 tests)

  • Chronic hepatitis

    • HBsAg-positive for more than 6 months

    • High ALT (preferably >1.5x) two times six months apart

    • Biopsy reveals moderate necroinflammation


Slide17 l.jpg

Whom should we treat?

Chronic hepatitis

  • Documented HBsAg+ >6 month

  • Either HBeAg +, (antiHBe -) or HBeAg - (precore mutant)

  • HBV-DNA +, but not very high

  • Moderately increased ALT, >2x but <10x

  • Documented necroinflammation and fibrosis by biopsy


Why biopsy needed l.jpg
Why biopsy needed?

  • Confirm the need to be treated

  • No ideal treatment exists

  • Treatments are with certain risks, including resistance and flares both during and after treatment failure

  • Uncontrolled treatment means uncontrolled infection


Slide19 l.jpg

Should we treat the CARRIERS?

  • Carriers also carry the certain risk of developing cirrhosis and hepatocellularcarcinoma

    • No study on the incidence risk, but very low

    • Surveillance is not recommended, but may be considered if affordable

  • Treatment for carrier (eradication of the virus) is not available now

    • Current treatment relies on activated immune status

    • No treatment that can eradicate the virus

  • Carriers should have regular follow up, avoid alcohol and other liver injury


Slide20 l.jpg

Current treatment

  • Interferonalpha

    • 5-10 million units qd or tiw for 16-24 weeks

  • Pegylated interferon

    • Only pegylated interferon alpha-2a

    • 180 mcg qw for 48 weeks

  • Antivirals

    • Lamivudine

    • Adefovir dipivoxil


Slide21 l.jpg

Seroconversion = HBeAg-ve and anti-HBe+ve

100

ALT > 1 x ULN (n=41)

77%

ALT > 2 x ULN (n=26)

80

69%

65%

63%

56%

54%

60

Patients (%)

42%

38%

37%

40

27%

20

0

1

2

3

4

5

Duration of Therapy (years)

Response to lamivudine treatment

Guan R . J. Gast. Hep. 2001; 16 Suppl.: Abs 160


Slide22 l.jpg

Emerging of YMDD resistance

% Incidence of YMDD mutant HBV

69 - 75%

47 - 56%

16 - 32%

2 year

3 year

1 year

At year of Lamivudine therapy

Atkins M. et al. Hepatology. 1998.


Slide23 l.jpg

55 CH-B patients treated uninterruptedly for a minimum of 2 years

(Lam 100 mg: 38 pts, Lam 25 mg: 7 pts, Lam 25 100 mg: 10 pts)

13/32

(40.6%)

Occurred 4-94 weeks (median 24 wks) after emergence of the YMDD mutant

Acute exacerbation*

1/23

3/32

(9.4%)

(4.3%)

3/13

decompensation

(23%)

With YMDD

Without YMDD

Mean Fu =

104 wks

62 wks

* abrupt increase of ALT by 2 folds and to a level greater than 5 x ULN or to a level > 300 IU/L

Hepatitis flare from YMDD resistance

Liaw YF. et al. Hepatology. 1999.


Slide24 l.jpg

Treatment of years chronic disease

  • Long term treatment

  • Increasing cost in progressing disease

  • Even sky high cost for end stage

    • Supportive treatment

    • Organ replacement therapy

    • Transplantation

    • Cancer prevention and treatment


Slide25 l.jpg

What do we expect from chronic hepatitis B? years

  • Cirrhosis

    • Compensated

    • Decompensated

  • Complication of cirrhosis

    • Ascites

    • Variceal bleeding

    • Hepatic encephalopathy

  • Hepatocellular carcinoma


Slide26 l.jpg

Is treatment of chronic hepatitis B cost-effective? years

  • Relatively low effectiveness as compared to hepatitis C (20-40% vs. 80-90%)

  • Treatment is considerably expensive

  • Undesirable side effects with high dose interferon

  • Treatment with antiviral may result in flare or resistance

  • No firm data on prevention of cirrhosis and HCC


Slide27 l.jpg

Viral entry years

Uncoating

Assembly & budding

ER

Positive strand synthesis

LAM, ADV, and TDF

pol Inhibitors

HBsAg

Nuclear import

HBV Polymerase ?

Removal of pregenome

cccDNA

Repair

Transcription

Negative strand synthesis

5’

3’

2.4/2.1 kb RNA

5’

3’

Translation

3.5 kb RNA

Encapsidation

Role of oral antivirals


Hepatitis b vaccination l.jpg
Hepatitis B vaccination years

  • First anti-cancer Vaccine

    • Hepatitis B vaccine prevents hepatitis B disease and its serious consequences like hepatocellular carcinoma. Therefore, this is the first anti-cancer vaccine.

  • Safe and effective

    • Medical, scientific and public health communities strongly endorse using hepatitis B vaccine as a safe and effective way to prevent disease and death.

    • Scientific data show that hepatitis B vaccines are very safe for infants, children, and adults.

    • There is no confirmed evidence indicating that hepatitis B vaccine can cause chronic illnesses.


Slide30 l.jpg

* years The schedule for hepatitis B vaccination is flexible and varies. Consult the ACIP statement on hepatitis B (11/91), AAP's 2003 Red Book, or the package insert for details.Note: For adult dialysis patients, the Engerix-B dose required is 40µg/2.0ml (use the adult 20µg/ml formulation) on a schedule of 0, 1, 2, and 6 months. For Recombivax HB, a special formulation for dialysis patients is available. The dose is 40µg/1.0ml and it is given on a schedule of 0, 1, and 6 months.


Slide31 l.jpg

Vaccine interruption years

  • If the vaccination series is interrupted after the first dose, the second dose should be administered as soon as possible. The second and third doses should be separated by an interval of at least 2 months. If only the third dose is delayed, it should be administered when convenient.

    Booster doses

  • Current data show that vaccine-induced hepatitis B surface antibody (anti-HBs) levels may decline overtime; however, immune memory (anamnestic anti-HBs response) remains intact indefinitely following immunization. Persons with declining antibody levels are still protected against clinical illness and chronic disease.

  • For health care workers with normal immune status who have demonstrated an anti-HBs response following vaccination, booster doses of vaccine are not recommended nor is periodic anti-HBs testing.


Slide32 l.jpg

  • Post-vaccination Testing years

    • After routine vaccination of infants, children, adolescents, or adults post-vaccination testing for adequate antibody response is not necessary.

    • Post-vaccination testing IS recommended for persons whose medical management will depend on knowledge of their immune status.

  • This includes persons who:

    • are immunocompromised (e.g., hemodialysis patients)

    • received the vaccine in the buttock

    • are infants born to HBsAg (hepatitis B surface antigen)-positive mothers

    • are healthcare workers who have contact with blood

    • are sex partners of persons with chronic hepatitis B virus infection

    • Post-vaccination testing should be completed 1-2 months after the third vaccine dose for results to be meaningful. A protective antibody response is 10 or more milliinternational units (>=10mIU/mL).


Slide33 l.jpg

Hepatitis C years

  • Linear single -stranded RNA virus

  • Family: Flaviviridae

  • Anti-HCV is not neutralizing antibody

  • Neutralizing antibody can be demonstrated but short-lived


Slide34 l.jpg

Hepatitis C years

  • HCV is a positive sense, single-stranded RNA virus, with an estimated diameter of 36 to 72 nm.

  • HCV is believed to represent a distinct genus in the Flaviviridae family

  • A viral envelope comprising a lipid layer and envelope proteins, surrounds a core (capsid) structure enclosing the viral nucleic acid

  • HCV RNA is 9.4 kb in length and consists of a 5′nontranslated region, followed by core (C), envelope (E), and nonstructural (NS) protein encoding regions


Slide35 l.jpg

Hepatitis C years

  • Incubation period 15-160 days,mean 50

  • Transmitted mostly by blood and blood products

  • The second generation test in 1992 reduced the infection to near zero

  • Perinatal and sexual transmission is also possible but with rather low incidence


Slide36 l.jpg

HCV infection years

2-20 wks

All abnormal ALT

1/3 jaundice

15% Resolved

85% chronic

1/3

2/3

All abnormal

pathology

normal ALT

Abnormal ALT

cirrhosis

20-30% in 10-20 yr.

HCC

3%/yr.


Slide37 l.jpg

Different in Disease Progression of HCV years

100

Medium rate 0.133 /y

Very rapid fibrosis 0.36/y

30 years to cirrhosis

% cirrhosis

11 years to cirrhosis

50

Very slow fibrosis 0.04/y

100 years to cirrhosis


Slide38 l.jpg

2 years

5

1

4

3

6

HCV genotypes and subtypes

P. Simmonds, Philos Trans R Soc Lond B Biol Sci 2001;356:1013-26


Slide39 l.jpg

Geographic distribution of hepatitis C genotypes years

1b2a, 2b, 2c, 3a

1b

1a, 1b2a, 2b, 3a

2a

4

1b, 3a

1b, 3, 6

4

3b

1b, 3a

5a

Adapted from Fang J Clin Liver Dis 1997;1:503.


Slide40 l.jpg

Current treatment years

Pegylated-interferon alfa + ribavirin

  • Pegylated interferon qw, 24-48 weeks

  • Ribavirin according to body weight and genotypes

    • <70 kg, or genotypes non-1, 800 mg/day

    • >=70 kg, 1,000-1,200 mg/day

  • All cases that have undetectable HCV-RNA at the end of treatment need to have it checked again 6 months later

  • Undetectable HCV-RNA at 6 months after completion of treatment means complete eradication


Slide41 l.jpg

Benefit from treatment years

  • Eradication, 60-90%Termination of disease course and even with regression of fibrosis

  • Non sustained remission, 20+%Retardation of disease progression

  • Less than 10% will not benefit from treatment


Slide42 l.jpg

Fibrosis regression or retardation in CH-C patients treated with interferon (IFN)

IFN

Fibrosis stage

Fn+1

untreated (+0.10 unit/year)

Fibrosis progression

Fn

non-SR (+0.024 unit/year)

Fn-1

Fibrosis resolution

SR (-0.28 unit/year)

0

5

10

-10

-5

(Years)

After IFN treatment


Slide43 l.jpg

Screening for HCC with interferon (IFN)


ad
