Presentation Transcript
Take me out to the ballgame strategies to improve rail transit mode share at fenway park l.jpg

Annual Rail Meeting of the American Public Transportation Association

Rail Operations: Planning for the Extremes

Tuesday, June 8, 2010 | 4:00 – 5:30 p.m.

Hyatt Regency, Vancouver, British Columbia

Take Me Out to the BallgameStrategies to Improve Rail Transit Mode Share at Fenway Park

David O. Nelson

Director of Transit Planning

Jacobs Engineering Group

Boston, Massachusetts


About fenway park l.jpg
About Fenway Park Association

  • Built 1912 by the Boston Red Sox Baseball Club

  • America’s Oldest Professional Sports Venue

  • Seats 37,402

  • One of the four smallest stadiums in the major leagues

  • Have sold out every game since May 2003



Fenway s neighbors l.jpg
Fenway’s Neighbors Association

Boston University

Back Bay

Kenmore Square

  • Longwood Medical & Academic Area

  • Kenmore Square

  • Boston University

  • Back Bay

  • Fenway

  • Northeastern University

  • Brookline

Brookline

Fenway

Northeastern University

Longwood Medical

& Academic Area


Fenway transportation l.jpg
Fenway Transportation Association

  • Comm Ave

  • Brookline Ave

  • Storrow Drive

  • Park Drive

  • The Fenway

  • Green Line

    • Kenmore

    • Fenway

  • Worcester Line

    • Yawkey

  • Orange Line

    • Ruggles

  • Providence Line

    • Ruggles

Kenmore

Yawkey

Fenway

Longwood

Ruggles

Ruggles


Fenway transit hubs l.jpg
Fenway Transit Hubs Association

Kenmore Square

  • B, C & D Lines

    Fenway Station

  • D Line

    Yawkey Station

  • Worcester Line

Kenmore

Yawkey

Fenway



Increasing transit to a larger fenway l.jpg
Increasing Transit to a Larger Fenway Association

  • In 1999, the Boston Red Sox proposed to enlarge or replace Fenway with a 33% larger stadium.

  • Fenway’s neighbors and City concerned about traffic impacts

  • Study team systematically reviewed options to improve transit mode share to a larger venue


Four phase approach l.jpg
Four phase approach Association

  • Review of current plans

  • Literature review

  • Review of current services

  • Identify and evaluate expansion strategies


Four phase approach10 l.jpg
Four phase approach Association

  • Review of current plans

  • Literature review

  • Review of current services

  • Identify and evaluate expansion strategies


Fenway expansion transport plans l.jpg
Fenway expansion transport plans Association

  • Red Sox

    • Maintain current mode splits

    • Expand parking

    • Improve Kenmore Square and Green Line Kenmore Station

    • More cars on Green Line trains

    • Improvements to Green Line Fenway Station

    • Expanded commuter rail facilities and services at Yawkey Station

    • Improve connections to Orange Line Ruggles Station.

  • City of Boston

    • Limit parking expansion

    • Improve transit mode share with Green Line and Commuter Rail


Four phase approach12 l.jpg
Four phase approach Association

  • Review of current plans

  • Literature review

  • Review of current services

  • Identify and evaluate expansion strategies


Literature review l.jpg
Literature Review Association

  • New York, Toronto and Boston lead MLB in transit mode share

  • Limited parking increases automobile occupancy rates and transit use

  • Superior transit contributes to transit demand peaking

  • Auto occupancy rates adversely impacted by good transit service

  • Traffic management after games is usually a bigger challenge than managing arriving crowds due to peaking

  • Good accessibility appears to increase attendance at games involving mediocre teams.


Four phase approach14 l.jpg
Four phase approach Association

  • Review of current plans

  • Literature review

  • Review of current services

  • Identify and evaluate expansion strategies


Pre expansion services l.jpg
Pre Expansion Services Association

Green Line

  • Public officials estimate that 24% of all fans use Green Line

  • 13 post game extra cars

  • Extra collectors and supervisors

    Commuter Rail

  • Four special stops at Yawkey Station

    Local Bus

  • Two extra buses to Allston and Watertown

  • Local service routed off Brookline Avenue

    Orange Line

  • Red Sox Ruggles Shuttle Bus

    Police

  • 12 to 14 transit police at Kenmore and Fenway


Fenway park and the green line l.jpg
Fenway Park and AssociationThe Green Line


About the green line l.jpg
About the Green Line Association

  • America’s Oldest Subway

  • ~240,000 boardings per day

  • ~24,000 passengers per peak hour

  • ~215 vehicles

  • Kenmore Square 60 trains per peak hour

  • Fenway (D Line) 12 eastbound trains per hour



Game day at fenway station l.jpg
Game Day at Fenway Station Association

12 Eastbound Riverside Trains per Peak Hour


Game day at yawkey l.jpg
Game Day at Yawkey Association

  • Four pre game trains

  • One Eastbound

  • Three Westbound

Three Westbound Trains

after 8pm


Driving and parking l.jpg
Driving and Parking Association

Neither Easy nor Cheap


Four phase approach22 l.jpg
Four phase approach Association

  • Review of current plans

  • Literature review

  • Review of current services

  • Identify and evaluate expansion strategies


Strategies identified and evaluated l.jpg
Strategies Identified and Evaluated Association

Institutional (7)

Operational (8)

Capital (4)


Institutional strategies l.jpg
Institutional Strategies Association

  • Bundled ticketing

  • Priority street access for MBTA buses

  • Post-game events in Fenway park

  • Local post-game events outside Fenway Park

  • Red Sox pre-game events at Riverside

  • Game day signage near Riverside

  • Subsidized transit for Red Sox employees and concessionaires


Operational strategies l.jpg
Operational Strategies Association

  • Kingston commuter rail service

  • Dedicated Providence/Attleboro commuter rail service

  • Pre game commuter rail on existing trains from South Station to Yawkey

  • Longer Green Line trains dedicated to post game service

  • Improved post-game service to North Station

  • Express trains from Riverside

  • Coordinated commuter rail at Ruggles

  • Express bus service from Fenway connecting with Red Line stations


Capital strategies l.jpg
Capital Strategies Association

  • Commuter rail turn-back station and train storage

  • Increase Green Line capacity at Fenway Station

  • Increase weeknight pre-game Green Line capacity


Ten years after l.jpg
Ten Years After Association

  • New Red Sox Ownership

  • New stadium scrapped

  • Two World Championships

  • Nearly 800 consecutive sold out games

  • 9% capacity expansion at historic stadium

  • Expanded use of stadium for concerts & other events


Ten years of incremental improvements l.jpg
Ten years of incremental improvements Association

  • Renovated Kenmore Station

    • Improved rail and bus facilities

    • Improved facilities for game day crush

    • Improved fare collection system

  • New Green Line cars

    • Larger, more reliable fleet

  • Fenway Station improvements

    • Still planned

  • Expanded commuter rail service

    • More everyday service to Yawkey and Ruggles

  • Yawkey Station improvements

    • In design

  • Yawkey Way and Lansdowne Street Festival Space

  • Ruggles Orange Line Shuttle

    • Discontinued


Renovated kenmore station l.jpg
Renovated Kenmore Station Association

  • Larger Southside Head House

  • Elevators and Escalators

  • Expanded Mezzanine

  • More Queuing Space

  • Improved Fare Collection


Yawkey way festival space l.jpg
Yawkey Way Festival Space Association

More space for fans to:

  • Arrive sooner

  • Stay longer


New yawkey station l.jpg
New Yawkey Station Association

Air Rights Development

New longer two-track station

700 car parking structure

330 homes

~500,000 ft2 office and retail


Take me out to the ballgame strategies to improve rail transit mode share at fenway park32 l.jpg

Annual Rail Meeting of the American Public Transportation Association

Rail Operations: Planning for the Extremes

Tuesday, June 8, 2010 | 4:00 – 5:30 p.m.

Hyatt Regency, Vancouver, British Columbia

Take Me Out to the BallgameStrategies to Improve Rail Transit Mode Share at Fenway Park

David O. Nelson

Director of Transit Planning

Jacobs Engineering Group

Boston, Massachusetts
