    Slide 2:National Cancer Institute’s 2015 Goal Need: Enable investigators to leverage their joint expertise in order to meet NCI 2015 Goal. Strategy: Create scalable, actively managed organization connecting members of the NCI-supported cancer enterprise by building a Biomedical Informatics Grid

    Slide 3:Cancer Biomedical Informatics Grid (caBIGTM) The cancer Biomedical Informatics Grid (caBIG™), is a voluntary network or grid connecting individuals and institutions to enable the sharing of data and tools, creating a World Wide Web of cancer research. The goal is to speed the delivery of innovative approaches for the prevention and treatment of cancer. The infrastructure and tools created by caBIG™ also have broad utility outside the cancer community. National Cancer Institute Initiative Over 800 Participants Over 80 Organizations Over 70 Projects

    Slide 4:VO Related Security Issues Identity / User Provisioning Hundreds of organizations, Tens of thousands of users. Varying levels of Identity Management from Institution to Institution. How do we assign Identity to users, how do we provision user accounts? Who should assert the identity for a given user? Trust - How do we decide who to trust? Credential Providers Certificate Authorities Attribute Authorities Group Authorities Other digital signers

    Slide 5:VO Related Security Issues Authorization How do we create, manage, and provision groups of users/services at the grid level, such that we can build access control policy based on group membership? How can we share access control policy across the grid? How can we leverage institution maintained attributes?

    Slide 6:caGrid Grid Infrastructure for caBIG Focuses on providing middleware for enabling the interoperability between caBIG applications. Open Source Reusable Components caGrid Components Grid Service Graphical Development Toolkit (Introduce) Metadata / Semantic Services Advertisement and Discovery Data Service Infrastructure Analytical Service Infrastructure Identifiers Workflow Security

    Slide 7:Grid Authentication and Authorization with Reliably Distributed Services (GAARDS) The GAARDS Security Infrastructure provides services and tools for the administration and enforcement of security policy in an enterprise Grid. Developed on top of the Globus Toolkit Extends the Grid Security Infrastructure (GSI) Provide enterprise services and administrative tools for: Grid User Management Identity Federation Trust management Group/VO management Access Control Policy management and enforcement Integration between existing security domains and the grid security domain. Security Infrastructure for the Cancer Biomedical Informatics Grid (caBIGTM) GAARDS

    Slide 8:GAARDS Services Dorian Grid User Account Management Integration point between external security domains and the grid. Allows accounts managed in external domains to be federated and managed in the grid. Dorian allows users to use their existing credentials (external to the grid) to authenticate to the grid Grid Trust Service (GTS) Creation and Management of a federated trust fabric. Supports applications and services in deciding whether or not signers of digital credentials/user attributes can be trusted. Supports the provisioning of trusted certificate authorities and corresponding CRLS. Grid Grouper Group management service for the grid Provides a group-based authorization solution for the Grid Enforce authorization policy based on membership to groups

    Slide 9:Dorian – Grid User Management Grid User Account Management Administrative interface for account provisioning and management. Built in Certificate Authority Manages Grid Credentials for each user. Enables users to authenticate and create grid proxies, which they may use to access the grid. Identity Management and Federation Integration point between external security domains and the grid. User may use existing credentials to obtain a grid proxy. User’s authenticate to IdP, obtain a SAML assertion (proof) which is then given to Dorian to facilitate the creation of a grid proxy. Automated Account Creation and Provisioning Complete WSRF Compliant Grid Service Can be accessed and administered over the grid. Complete Administrative UI Manage all aspects of Dorian

    Slide 11:Grid Grouper Grid Grouper provides a group based authorization solution for the grid. Groups are defined and managed at the grid level. Grid services/applications enforce authorization policy based on membership to groups.

    Slide 12:caGrid / GAARDS Status Release Schedule Beta Release was Summer 2006 Official Release December 15, 2006 Focus on Quality Automated Continuous and Nightly Builds and Unit, System, and Integration Testing “Quality at a glance” dashboards and archive of all build and test results Giving Back to the Community GAARDS is a Globus Incubator Project More Information caBIG https://cabig.nci.nih.gov/ caGrid http://gforge.nci.nih.gov/projects/cagrid-1-0/ GAARDS Globus Project Information to be posted shortly after release http://dev.globus.org/wiki/Incubator/GAARDS

    Slide 13:GAARDS Team Ohio State University Stephen Langella Shannon Hastings Scott Oster David Ervin Tahsin Kurc Joel Saltz NCICB Avinash Shanbhag

    Slide 14:Special Thanks caBIGTM Internet 2 Grouper Team Tom Barton, University at Chicago Frank Manion, Fox Chase

    Slide 15:Questions?
