Presentation Transcript
Slide1 l.jpg

Providing Guaranteed Services Without Per Flow Management

By: Ion Stoica, Hui Zhang

Presented by: Sanjeev R. Kulkarni

Advanced Computer Networks


Outline l.jpg
Outline

  • Problems with the current QoS architectures

  • Stateless Core Architecture(SCORE)

    • Dynamic Packet State

    • Core Jitter Virtual Clock Algorithm

    • Admission Control

  • Implementation details

  • Extensions to IPv6

Advanced Computer Networks


Current qos architectures l.jpg
Current QoS architectures

  • Integrated Services

  • Differentiated Services

Advanced Computer Networks


Integrated services l.jpg
Integrated Services

  • All Routers maintain per-flow state

  • State

    • Control Plane

      • Admission Control: per flow signaling

    • Data Plane

      • Classifier: per flow flow-ids

      • scheduler: per flow scheduling algorithm parameters

Advanced Computer Networks


Integrated services5 l.jpg
Integrated Services

  • All Routers maintain per-flow state

  • State

    • Control Plane

      • Admission Control: per flow signaling

    • Data Plane

      • Classifier: per flow flow-ids

      • scheduler: per flow scheduling algorithm parameters

  • Scalability??

Advanced Computer Networks


Jitter virtual clock l.jpg
Jitter Virtual Clock

  • For each packet

    • eligible time

    • deadline

  • Scheduling done in the order of the deadline

    • e1i,j = a1i,j

    • eki,j = max ( aki,j + gki,j-1, dk-1i,j)

    • dki,j = eki,j + lki/ri

Advanced Computer Networks


Core routers and edge routers l.jpg
Core-routers and Edge routers

Advanced Computer Networks


Differentiated services l.jpg
Differentiated Services

  • A small number of traffic classes

  • Only Edge routers maintain per flow state

  • Control Plane

    • Admission Control: per flow signaling

  • Data Plane

    • Classifier: per class classification

    • Scheduler: per class scheduling

  • Advanced Computer Networks


    Differentiated services9 l.jpg
    Differentiated Services

    • A small number of traffic classes

    • Only Edge routers maintain per flow state

    • Control Plane

      • Admission Control: per flow signaling

  • Data Plane

    • Classifier: per class classification

    • Scheduler: per class scheduling

  • Quality of QoS??

  • Advanced Computer Networks


    Stateless core solution l.jpg
    Stateless Core Solution

    • Idea similar to DiffServ

    • Only Edge Routers maintain per flow state

    • Dynamic Packet State (DPS) is inserted into each packet by edge routers

    • Core routers update DPS and schedule packets accordingly

    Advanced Computer Networks


    Slide11 l.jpg
    DPS

    Ingress

    Egress

    Advanced Computer Networks


    How it works l.jpg
    How it works

    a

    b

    c

    d

    Advanced Computer Networks


    How it works13 l.jpg
    How it works

    a

    b

    c

    d

    Advanced Computer Networks


    How it works14 l.jpg
    How it works

    a

    b

    c

    d

    Advanced Computer Networks


    How it works15 l.jpg
    How it works

    a

    b

    c

    d

    Advanced Computer Networks


    How it works16 l.jpg
    How it works

    a

    b

    c

    d

    Advanced Computer Networks


    How it works17 l.jpg
    How it works

    a

    b

    c

    d

    Advanced Computer Networks


    How it differs from diffserv l.jpg
    How it differs from DiffServ

    • DPS versus Per Hop Behavior (PHB)

      • DPS is dynamic

      • Routers change DPS and schedule packets based on the DPS state

      • DPS change mirrors a Core-Jitter Virtual Clock scheduling

    Advanced Computer Networks


    Core jitter virtual clock l.jpg
    Core Jitter Virtual Clock

    • eki,j = max ( aki,j + gki,j-1, dk-1i,j)

  • The main culprit is dk-1i,j

  • Introduce a slack variable such that

    • aki,j + gki,j-1 + > dk-1i,j

  • ik =max (0, ik-1 + (lik-1 - lik)/ri -

    (ei,1k - ei,1k-1 - lik-1/ri)/(h-1) )

    Advanced Computer Networks


    Example l.jpg
    Example

    a

    b

    Advanced Computer Networks


    Example21 l.jpg
    Example

    a

    ea1

    da1

    b

    Advanced Computer Networks


    Example22 l.jpg
    Example

    ga1

    a

    ea1

    da1

    b

    Advanced Computer Networks


    Example23 l.jpg
    Example

    ga1

    a

    ea1

    da1

    eb1

    db1

    b

    ga1

    Advanced Computer Networks


    Example24 l.jpg
    Example

    a

    ea1

    da1

    eb1

    db1

    b

    Advanced Computer Networks


    Example25 l.jpg
    Example

    a

    ea1

    ea2

    da2

    eb1

    db1

    b

    Advanced Computer Networks


    Example26 l.jpg
    Example

    a

    ea2

    da2

    eb1

    db1

    b

    Advanced Computer Networks


    Example27 l.jpg
    Example

    a

    ea2

    da2

    gb1

    eb1

    b

    db1

    ga1

    Advanced Computer Networks


    The algorithm l.jpg
    The algorithm

    • Parameter Initialization by Ingress Routers

    • Core routers examine the parameters and modify g

    • Egress Routers strip the packet of these labels

    Advanced Computer Networks


    Admission control l.jpg
    Admission Control

    r

    s

    d

    a

    c

    b

    Advanced Computer Networks


    Admission control30 l.jpg
    Admission Control

    Resv

    r

    s

    d

    a

    c

    b

    Advanced Computer Networks


    Admission control31 l.jpg
    Admission Control

    r

    s

    d

    1

    a

    c

    b

    Advanced Computer Networks


    Admission control32 l.jpg
    Admission Control

    r

    s

    d

    a

    c

    b

    Advanced Computer Networks


    Admission control33 l.jpg
    Admission Control

    r

    s

    d

    a

    c

    b

    Advanced Computer Networks


    Admission control34 l.jpg
    Admission Control

    r

    s

    d

    a

    c

    b

    Advanced Computer Networks


    Admission control35 l.jpg
    Admission Control

    r

    s

    d

    3

    a

    c

    b

    Advanced Computer Networks


    Admission control36 l.jpg
    Admission Control

    Resv

    r

    s

    d

    a

    c

    b

    Advanced Computer Networks


    Admission control37 l.jpg
    Admission Control

    • Each core router maintains an upper bound R on the Total Bandwidth reserved

    • Local Admission Control

      • Accept if R + ri < C

    • Periodically they run an algorithm that contains the deviation between the actual B/w reserved and R.

    Advanced Computer Networks


    Recalibration algorithm l.jpg
    Recalibration Algorithm

    • Packet state b

    • Add all b values on each packet arrival

    • Periodically they update based on

      R = min ( R, RD/(1-f) + Rnew )

    Advanced Computer Networks


    Implementation l.jpg
    Implementation

    0

    7

    11

    15

    31

    TOS

    IPv4 Header

    Frag Offset

    18

    Advanced Computer Networks


    Implementation40 l.jpg
    Implementation

    0

    7

    11

    15

    31

    18

    Flag

    F1

    F2

    F3

    2

    5

    9

    16

    Advanced Computer Networks


    Extension to ipv6 l.jpg
    Extension to Ipv6

    0

    7

    11

    31

    Flow Label

    Flag

    F1

    F2

    F3

    6

    11

    19

    2

    Advanced Computer Networks


    Summary l.jpg
    Summary

    • SCORE Network

      • Is Scalable

      • Gives a QoS similar to Jitter Virtual Clock

      • Extensible to Ipv6

      • Transparent to the outside network

    Advanced Computer Networks
