GROUNDHOG DAY!

Alan Murray


Agenda l.jpg
Agenda

  • RC circuit, AC signal

    • using trigonometry (J?)

    • using phasors (K?)

    • using complex numbers (L?)

  • worked examples complex numbers

Alan Murray – University of Edinburgh


Notation l.jpg

T=1/f

VS0

VS

Phase

Notation

Alan Murray – University of Edinburgh


This is all we need l.jpg
This is all we need ...

Alan Murray – University of Edinburgh


Rc phasor k l.jpg

I

VR

VS

VC

RC Phasor (K?)

  • Choose I =IC =IR horizontal

  • VR = RI (Ohm’s Law)

    VRalso horizontal

    i.e. VR and I are in phase

  • CIVIL → I leads VC by π/2

    • Or VC is -π/2 behind I

  • VC points ↓ … rotated by -π/2

  • VS = VC + VR

Sonny & Cher sing…"I got you babe" ...

Alan Murray – University of Edinburgh


Rc phasor k6 l.jpg

I

VR

VS

VC

RC Phasor (K?)

Alan Murray – University of Edinburgh


Rc phasor k7 l.jpg

I

VR

VS

VC

RC Phasor (K?)

Alan Murray – University of Edinburgh


Rc phasor k8 l.jpg

I

VS

RC Phasor (K?)

I and VR are in phase

VC lags I and VR by π/2

VS is at an angle -Φ in between

Plug in numbers forR,C and ω =2πf to get values for VR, VC, I and Φ

(Leave this as a worked example, once we have the same result from the complex number method and from trigonometry)

VR = RI

Φ

VC = I/ωC

Alan Murray – University of Edinburgh


Rc complex numbers l here s the idea l.jpg

I

VR

Φ

VS

VC

RC Complex numbers (L?)Here’s the idea ...

  • Write all currents/voltages as Cej(ωt+phase)

  • I = I0ejωt

  • VR = VR0ejωt = ZRI0ejωt

  • VC = VC0ejωt = ZCI0ejωt

  • VS = VS0ejωt= VR + VC= (ZR + ZC)I0ejωt

    • ωt spins the complex “phasors”

    • I0 and VR0are real

    • VC0is imaginary because of an e-jπ/2 term

      • -jπ/2 puts the CIV in CIVIL

    • VS0 is complex and will includean e-jΦ term

      • -Φ is the phase of VS

  • To get real voltages and currents - take real parts

  • I = Re(I0ejωt)

  • VR = Re(VR0ejωt)

  • VC = Re(VC0ejωt)

  • VS = Re(VS0ejωt)

  • The ejωt terms will cancel.

    We will leave them in for now

J

Alan Murray – University of Edinburgh


Rc complex numbers l l.jpg
RC Complex numbers (L?)

  • And impedances, ZR, ZC?

    • VR = RI, VR and I are in phase

“j x” = “I leads VC by 90°”

The 90° phase shift is dealt with by the mathsautomatically.We no longer have to think about it explicitly.

J

Alan Murray – University of Edinburgh


Rc complex numbers l11 l.jpg
RC Complex numbers (L?)

  • This chooses I0 to be real, = “horizontal in the phasor diagram”

Sonny & Cher sing…"I got you babe" ...

X

X

Alan Murray – University of Edinburgh


And if we had anticipated the cancellation of e j t l.jpg
And if we had anticipated the cancellation of ejωt …

  • This chooses I0 to be real, = “horizontal in the phasor diagram”

Alan Murray – University of Edinburgh


Rc complex numbers l13 l.jpg
RC Complex numbers (L?)

Insert numbers for |VS0|, R, C, f and thus ω

Then …

Alan Murray – University of Edinburgh


Fill in the blanks l.jpg

IS

VS

C

R

IC

IR

Fill in the blanks

Draw a phasor diagram for

VS, VR, VC, IS, IR and IC

here

Similar expressions forVR and VC

VS= VR= VC

Now use Ohm’s Law to

Write an expression for IR,

complete with its ejωt+phase

Then do the same for IC

And tidy it up a little.

Now write this expression

IC as IC0ejωt+phase, with allthe phase information inthe exponential part.

Alan Murray – University of Edinburgh


Comparison l.jpg

From the phasor diagram

From ejωt analysis

Comparison

Note – in the phasor equations, the sinusoidal nature of the voltages andcurrents and the phase differences between them are not spelt out.

In the complex-number version these are explicitas the ejωt and e-jπ/2 terms respectively


Summary how to use e j t l.jpg

(Notation)

(Impedances)

(Ohm’s Law on the total impedance)

(Ohm, continued … ejωt cancels out)

(More Ohm’s Law on R and C individually,then add VR0 and VC0 to get VS0)

Summary : How to use ejωt

Plug in numbers, take real parts, calculate relative phases

NB – We can choose to leave out the ejωtthroughout the calculation, although it must go back in atthe end to retrieve the sinusoidal voltages and currents explicitly.

Alan Murray – University of Edinburgh


Slide17 l.jpg

Worked examples lecture

Clicker exercise


Rc trigonometry j should be easy shouldn t it l.jpg
RC Trigonometry! (J?)Should be easy, shouldn't it?

Sonny & Cher sing…"I got you babe" ...

  • I = I0cos(ωt)

    • Equivalent to choosing I horizontal

  • VR = RI0cos(ωt)

    • VR is in phase with I

  • VC = I/(ωC) and lags I by π/2 (CIVIL)

  • VC = I0cos(ωt-π/2)/(ωC)

    … which is the same as …

  • VC = I0sin(ωt)/(ωC)

  • VS = VR + VC

  • VS = I0Rcos(ωt) + I0sin(ωt)/(ωC)

  • VS = I0[Rcos(ωt) + sin(ωt)/(ωC)]

  • VS = I0R[cos(ωt) + sin(ωt)/(RωC)]

Alan Murray – University of Edinburgh


Rc trigonometry j should be easy shouldn t it19 l.jpg
RC Trigonometry! (J?)Should be easy, shouldn't it?

  • VS = I0R[cos(ωt) + sin(ωt)(RωC)-1]

  • Now for a very non-intuitive step …

  • Set Ф = arctan[(RωC)-1],

    • tan(Ф) = (RωC)-1 = sin(Ф) cos(Ф)

  • VS = I0R[cos(ωt) + sin(ωt)tan(Ф)]

  • VS = I0R[cos(ωt)cos(Ф) + sin(ωt)sin(Ф)] cos(Ф)

  • VS = I0R cos(ωt+Ф) cos(Ф)

  • fatigue setting in?

Alan Murray – University of Edinburgh


Rc trigonometry j should be easy shouldn t it20 l.jpg
RC Trigonometry! (J?)Should be easy, shouldn't it?

X

X

  • VS = I0R cos(ωt+Ф) = VS0 cos(ωt+Ф) cos(Ф)

  • ... and after several lines of VERY tedious trigonometry(!) ...

  • cos(Ф) = [1+(ωRC)-2]-½

  • VS is at an angle of Ф = tan-1(ωRC-1)

Alan Murray – University of Edinburgh


Message l.jpg
Message?

  • Trigonometry is familiar from school, but really messy - even for only two components (R and C)

    • it gets MUCH worse VERY rapidly for more

  • Phasors are excellent for seeing what is happening, but make for messy algebra.

    • again - MUCH worse for 3, 4 or more components

    • because phasors take you straight back to trigonometry

  • Complex numbers are initially threatening, but make the actual maths MUCH easier, ONCE YOU HAVEACCEPTED THE IDEA.

  • Groundhog Day finally ends ...

  • Goodnight

Alan Murray – University of Edinburgh
