Presentation Transcript

Incident investigation logic tree methods l.jpg

Incident Investigation Logic Tree Methods

Dennis C. HendershotRohm and Haas Company, retired

SACHE Workshop

September 2005

Bristol, PA

Purpose of incident investigations l.jpg

Purpose of Incident Investigations

  • System improvements

  • Not choosing scapegoats

  • You must set the tone!

Logic tree l.jpg

Logic Tree

  • Start with the incident as the top event

  • It may be useful to start with a generic top tree

    • Damaging agent in a location

    • Employee or equipment in location

    • Employee or equipment in contact with damaging agent long enough to cause

      • Injury

      • Damage

Generic top level logic tree for incident investigations l.jpg

Generic Top Level Logic Treefor Incident Investigations

Injury or Equipment Damage

Injured (or damaged equipment) in

contact with

Causative agent


Causative agent

Present (fire,



Contact with

causative agent

long enough

to cause injury







Logic tree5 l.jpg

Logic Tree

  • Choose one second level event

    • Determine causes

    • Draw causing events on logic tree

    • Keep asking "Why?" and

    • Draw causes on treeFollow one branch to basic (root) system cause

    • Includes

      • Training

      • Management systems

      • Culture

  • Repeat for the other events

And gate l.jpg


"AND" Gate

All events entering this box must be true in order for this event to be true

Event A

Event B

Test the logic at each step l.jpg

Event B

Event A

Test the Logic at Each Step

All events entering this box must be true in order for this event to be true


  • For each event, ask, “If this event does not happen, would the event above occur?”

    • If no, the event stays as a cause.

    • If yes, the event is not a cause.

Or gate l.jpg


"OR" Gate

If any event entering this box is true, then this event is true

Event B

Event A

When to stop l.jpg

When to Stop

  • At System Level

    • Broader areas affected than this incident

    • Systems, rather than peopleTypical: management systems, design systems, training systems

  • When needed expertise is lacking

    • May need instrument expert (or vendor expert) to explain why a control device failed a certain way.

    • May need manufacturer when we can't figure out why cooling tower fan blades are failing.

Writing events l.jpg

Writing Events

  • Stick to the Facts

  • Avoid drawing conclusions

  • Clearly label conclusions

  • Indicate direct quotations of witnesses

Stick to facts l.jpg

Stick to Facts

  • Box Says

    • “Goggle area" sign too high to see easily

  • Facts Are

    • Sign is high

  • Conclusions Drawn

    • Signs cannot be easily seen

Determining causes l.jpg

Determining Causes

  • Generic logic tree

  • Top level event

  • Second level events

  • Keep asking"WHY?"

  • "AND" gates

  • "OR" gates

  • Common mode failures

  • System level causes

  • Test the logic

Test the logic l.jpg

Test the Logic

  • Test the logic against the sequence of events and the facts.

  • Does the tree support the facts?

    • does the tree explain all the facts?

  • Is the tree supported by the facts;

  • are additional facts or assumptions needed to support the tree?

  • The events below each gate must be necessary and sufficient to cause each event

  • If there are gaps, modify the tree or get more facts.

Recommendations l.jpg


  • Look at each bottom level event.

    • Attempt to make a recommendation to prevent that event from occurring, or

    • To mitigate it, if it does occur.

  • Look at structure of tree.

    • Attempt to add "AND" gates to the tree.

  • Selection basis for recommendations:

    • Protection provided

    • Frequency of challenge,

    • Cost of recommendation.

  • Management will address each recommendation and document what was done.

Peroxide drum explosion 1998 loss prevention symposium paper 6c l.jpg

Peroxide Drum Explosion1998 Loss Prevention Symposium Paper 6c

Mcsoii logic tree 1 l.jpg

MCSOII Logic Tree (1)

Mcsoii logic tree 2 l.jpg

MCSOII Logic Tree (2)

Mcsoii logic tree 3 l.jpg

MCSOII Logic Tree (3)

Mcsoii logic tree 4 l.jpg

MCSOII Logic Tree (4)

Logic tree advantages l.jpg

Logic Tree Advantages

  • More structure

  • Good display of facts

  • Encourages “Out of the Box” thinking

  • Displays cause and effect

  • Shows simultaneous events

  • Captures common mode failures

  • Shows "AND" - "OR" relationships

  • If keep asking "Why?", can lead to deep system problems

Logic tree disadvantages l.jpg

Logic Tree Disadvantages

  • Can get bogged down in discussions about the logic structure

    • Requires good facilitator to manage discussions

    • If something appears to be important, get it written down somewhere, worry about detailed logic later

  • Logic can become complex, if too rigorous

  • Can miss deep cultural issues

  • Some background items might not fit easily in the tree (impact many branches)

Some incident investigation resources and articles l.jpg

Some Incident InvestigationResources and Articles

  • Book:

    • Center for Chemical Process Safety (CCPS) (2003). Guidelines for Investigating Chemical Process Incidents. 2nd Edition. American Institute of Chemical Engineers, New York.

  • Papers and Articles

    • Anderson, S. E., and R. W. Skloss (1992). “More Bang for the Buck: Getting the Most From Accident Investigations.” Plant/ Operations Progress 11, 3 (July), 151-156.

    • Anderson, S. E., A. M. Dowell, and J. B. Mynaugh (1992). “Flashback From Waste Gas Incinerator into Air Supply Piping.” Plant/Operations Progress11, 2 (April), 85-88.

    • Antrim, R. F., M. T. Bender, M. B. Clark, L. Evers, D. C. Hendershot, J. W. Magee, J. M. McGregor, P. C. Morton, J. G. Nelson, and C. Q. Zeszotarski (1998). “Peroxide Drum Explosion and Fire.” Process Safety Progress17, 3 (Fall)), 225-231.

Incident investigation exercises l.jpg

Incident Investigation Exercises

  • Incident 1 – Emergency relief system catch tank rupture

    • Groups 1, 3, 5

  • Incident 2 – Sodium hydroxide dilution tank eruption

    • Groups 2, 4
