Presentation Transcript
Dec 7 2007 l.jpg

Dec 7, 2007

SOAP vs REST

Can you read this? If not, please sit closer. Thank you.


Slide2 l.jpg

XML RPC (1998)

  • Request

  • <?xml version="1.0"?>

  • <methodCall>

    • <methodName>doSomeWork</methodName>

    • <params>

      • <param>

        • <value><int>40</int></value>

      • </param>

      • <param>

        • <value><double>-12.53</double></value>

      • </param>

    • </params>

  • </methodCall>

  • Response

  • <?xml version="1.0"?>

  • <methodResponse>

    • <params>

      • <param>

        • <value>

          • <array>

            • <data>

              • <value><dateTime.iso8601>19980717T14:08:55</dateTime.iso8601></value>

              • <value><string>Something here</string></value>

            • </data>

          • </array>

        • </value>

      • </param>

    • </params>

  • </methodResponse>


Slide3 l.jpg

Early SOAP (2000) “section 5 encoding”

  • <?xml version="1.0"?>

  • <soap-env:envelope

  • soap-env:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"

  • xmlns:soap-env="http://schemas.xmlsoap.org/soap/envelope/"

  • xmlns:soap-enc="http://schemas.xmlsoap.org/soap/encoding/"

  • xmlns:xsd="http://www.w3.org/1999/XMLSchema"

  • xmlns:xsi="http://www.w3.org/1999/XMLSchema-instance">

    • <soap-env:header>

      • ...

    • </soap-env:header>

    • <soap-env:body>

      • <m:doSomeWork xmlns:m="http://www.lab49.com/">

        • <foo xsi:type="xsd:int">40</foo>

        • <bar>-12.53</bar>

      • </m:doSomeWork>

    • </soap-env:body>

  • </soap-env:envelope>

  • <?xml version="1.0"?>

  • <soap-env:Envelope

  • soap-env:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"

  • xmlns:soap-env="http://schemas.xmlsoap.org/soap/envelope/"

  • xmlns:soap-enc="http://schemas.xmlsoap.org/soap/encoding/"

  • xmlns:xsd="http://www.w3.org/1999/XMLSchema"

  • xmlns:xsi="http://www.w3.org/1999/XMLSchema-instance">

    • <soap-env:body>

      • <m:doSomeWorkResponse xmlns:m="http://www.lab49.com/">

        • <soap-enc:array soap-enc:arrayType="xsd:ur-type[2]">

          • <baz xsi:type="xsd:int">12345</baz>

          • <quux xsi:type="xsd:string">Something here</quux>

        • </soap-enc:array>

      • </m:doSomeWorkResponse>

    • </soap-env:Body>

  • </soap-env:Envelope>


Slide4 l.jpg

SOAP fancy encoding rules

References:

<e:Book> <title>My Life and Work</title> <author href="#Person-1"/></e:Book>

<e:Person id="Person-1"> <name>Henry Ford</name> <address href="#Address-2"/></e:Person>

<e:Address id="Address-2">  <email>mailto:[email protected]</email> <web>http://www.henryford.com</web></e:Address>

Sparse arrays:

<SOAP-ENC:Array SOAP-ENC:arrayType="xsd:string[,][4]"> <SOAP-ENC:Array href="#array-1" SOAP-ENC:position="[2]"/></SOAP-ENC:Array>

<SOAP-ENC:Array id="array-1" SOAP-ENC:arrayType="xsd:string[10,10]"> <item SOAP-ENC:position="[2,2]">Third row, third col</item> <item SOAP-ENC:position="[7,2]">Eighth row, third col</item></SOAP-ENC:Array>


Slide5 l.jpg

Document/literal (2003): Forget all the fancy encoding rules

  • <?xml version="1.0"?>

  • <soap-env:envelope

  • soap-env:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"

  • xmlns:soap-env="http://schemas.xmlsoap.org/soap/envelope/"

  • xmlns:xsd="http://www.w3.org/1999/XMLSchema"

  • xmlns:xsi="http://www.w3.org/1999/XMLSchema-instance">

    • <soap-env:header>

      • ...

    • </soap-env:header>

    • <soap-env:body>

      • … your XML Schema compliant document goes here …

    • </soap-env:body>

  • </soap-env:envelope>


Slide6 l.jpg

I want my, I want my RPC (rpc/literal)

  • <?xml version="1.0"?>

  • <soap-env:envelope

  • soap-env:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"

  • xmlns:soap-env="http://schemas.xmlsoap.org/soap/envelope/"

  • xmlns:soap-enc="http://schemas.xmlsoap.org/soap/encoding/"

  • xmlns:xsd="http://www.w3.org/1999/XMLSchema"

  • xmlns:xsi="http://www.w3.org/1999/XMLSchema-instance">

    • <soap-env:header>

      • ...

    • </soap-env:header>

    • <soap-env:body>

      • <m:doSomething xmlns:m=“http://lab49.com/”>

        • <foo>

          • … XML Schema compliant value…

          • … XML Schema compliant value…

        • </foo>

        • <bar>

          • … XML Schema compliant value…

        • </bar>

      • </m:doSomething>

    • </soap-env:body>

  • </soap-env:envelope>

Namespace does not

have to be the same

as the parameter values

Argument elements don’t

even have a namespace

Lets you model procedure calls, but can’t validate SOAP body with an XML Schema


Slide7 l.jpg

SOAP encoding convention line-up circa 2003

  • RPC/encoded (the original)

  • Document/literal (based on XML Schema, but doesn’t model RPC)

  • RPC/literal (adds RPC modeling, breaks XML Schema validation)

  • Can’t we model RPC without breaking Schema validation?


  • Slide8 l.jpg

    Wrapped document literal style (2005)

    • <?xml version="1.0"?>

    • <soap-env:envelope

    • soap-env:encodingStyle="http://schemas.xmlsoap.org/soap/encoding/"

    • xmlns:soap-env="http://schemas.xmlsoap.org/soap/envelope/"

    • xmlns:soap-enc="http://schemas.xmlsoap.org/soap/encoding/"

    • xmlns:xsd="http://www.w3.org/1999/XMLSchema"

    • xmlns:xsi="http://www.w3.org/1999/XMLSchema-instance">

      • <soap-env:header>

        • ...

      • </soap-env:header>

      • <soap-env:body>

        • <m:doSomething xmlns:m=“http://lab49.com/”>

          • <m:foo>

          • </m:foo>

          • <m:bar>

          • </m:bar>

        • </m:doSomething>

      • </soap-env:body>

    • </soap-env:envelope>

    Entire body complies with an XML Schema

    containing element doSomething containing

    a sequence of elements foo and bar



    Slide10 l.jpg

    Web Service Definition Language (WSDL 1.1)

    • <definitions>

      • <types>

        • <schema>

          • <element name="doSomething">

            • <complexType>

            • <sequence>

              • <element name="foo" nillable="true" type="string" />

              • <element name="bar" nillable="true" type="double" />

            • </sequence>

            • </complexType>

          • </element>

          • <element name="doSomethingResponse">

            • ...

          • </element>

        • </schema>

      • </types>

      • <message name="doSomethingRequest"> <part name="parameters" element="doSomething"></part> </message>

      • <message name="doSomethingResponse"> <part name="parameters" element="doSomethingResponse"></part> </message>

      • <portType name="myServices">

        • <operation name="doSomething">

          • <input name="doSomethingRequest" message="doSomethingRequest"></input>

          • <output name="doSomethingResponse" message="doSomethingResponse"></output>

        • </operation>

      • </portType>

      • <binding name="myServicesHttpBinding" type="myServices">

        • <binding style="document" transport="http://schemas.xmlsoap.org/soap/http" />

        • <operation name="doSomething">

          • <operation soapAction="" />

          • <input name="doSomethingRequest"> <body use="literal" /> </input>

          • <output name="doSomethingResponse"> <body use="literal" /> </output>

        • </operation>

      • </binding>

      • <service name="myServices">

        • <port name="myServicesHttpPort" binding="myServicesHttpBinding"> <address location="http://..." /> </port>

      • </service>

    • </definitions>

    Wrapped style. Notice the operation

    has one message part called “parameters”

    which is an XML sequence of the args



    Slide12 l.jpg

    Code first / WSDL first decision algorithm

    Write code first and use doc/literal style. i.e. Every method has one arg. Use

    annotations to name everything and review

    WSDL afterward.

    Will other projects be using these services? i.e. is this part of an SOA?

    Are you in a great hurry?

    No

    No

    Yes

    Yes

    Write code first in

    wrapped/literal style, i.e. Use

    annotations to name everything and review WSDL afterward.

    Write WSDL first.

    Think through interfaces carefully, plan

    for backward compatibility, write lots of

    comments, and maintain in source control.


    Slide13 l.jpg

    Goodies

    • WS-Security (message integrity, confidentiality, and authentication)

    • WS-ReliableMessaging

    • WS-Routing (messaging patterns and routes)

    • WS-Eventing (pub/sub)

    • Many other incomprehensible extensions, collectively referred to as WS-*





    Slide17 l.jpg

    Complexity

    Low

    High

    SOAP

    ?

    REST


    Slide18 l.jpg

    Comparison points

    • WSDL is a good idea for both SOAP and REST

      • (not a long-term differentiator)

    • SOAP and REST both allow you to name resources with URIs

      • (also not a long-term differentiator)

    • REST adds value to the entire web

      • (we don’t care)

    • REST is easier to program

      • (not for long)

    • SOAP provides better support for async messaging

    • SOAP is better if developers and network administrators don’t

    • have a good relationship


    Slide19 l.jpg

    In conclusion

    • For enterprise apps, default to SOAP.

    • But if (like Amazon.com) you

    • are catering to people who are not making a large

    • investment in connecting to your service

    • have control over your network

    • are trying to reach a broad audience

    • … then go with REST.

    • Expires: Mon, 31 Mar 2008 20:00:00 GMT
