Presentation Transcript
security in wireless sensor networks

Security in Wireless Sensor Networks

Group Meeting

Fall 2004

Presented by Edith Ngai

outline
Outline
  • Wireless Sensor Networks (WSN)
  • Security in WSN
  • Key Management Approaches
    • Straight Forward Approach
    • Basic Probabilistic Approach
    • Deployment-based Approach
  • Conclusion
  • References
wireless sensor networks
Wireless Sensor Networks
  • A sensor network is composed of a large number of sensor nodes
  • Sensor nodes are small, low-cost, low-power devices that have following functionality:
    • communicate on short distances
    • sense environmental data
    • perform limited data processing
  • The network usually also contains “sink” node which connects it to the outside world

Berkeley Motes

applications
Applications
  • WSN can be used to monitor the conditions of various objects / processes
    • Military: battlefield surveillance, biological attack detection, targeting
    • Ecological: fire detection, flood detection, agricultural uses
    • Health related: human physiological data monitoring
    • Miscellaneous: car theft detection, inventory control, home applications
  • Sensors are densely deployed either inside or very close to the monitored object / process
security in wsn
Security in WSN
  • Main security threats in WSN are:
    • Radio links are insecure – eavesdropping / injecting faulty information is possible
    • Sensor nodes are not temper resistant – if it is compromised the attacker obtains all security information
  • Protecting confidentiality, integrity, and availability of the communications and computations
slide6

Why Security is Different?

  • Sensor Node Constraints
    • Battery
    • CPU power
    • Memory
  • Networking Constraints and Features
    • Wireless
    • Ad hoc
    • Unattended
key management goals
Key Management: Goals
  • The protocol must establish a key between all sensor nodes that must exchange data securely
  • Node addition / deletion should be supported
  • It should work in undefined deployment environment
  • Unauthorized nodes should not be allowed to establish communication with network nodes
key management problem

Sensors

Deploy

Key Management Problem

Secure Channels

approaches
Approaches
  • Trusted-server schemes
    • Finding trusted servers is difficult
  • Public-key schemes
    • Expensive and infeasible for sensors
  • Key pre-distribution schemes
key pre distribution
Key Pre-distribution
  • Loading Keys into sensor nodes prior to deployment
  • Two nodes find a common key between them after deployment
  • Challenges
    • Memory/Energy efficiency
    • Security: nodes can be compromised
    • Scalability: new nodes might be added later
straight forward approach
Straight Forward Approach
  • Single mission key is obviously unacceptable
  • Pairwise private key sharing between every two nodes is impractical because of the following reasons:
    • it requires pre-distribution and storage of n-1 keys in each node which is n(n-1)/2 per WSN
    • most of the keys would be unusable since direct communication is possible only in the nodes neighborhood
    • addition / deletion of the node and re-keying are complex
basic probabilistic approach
Basic Probabilistic Approach
  • Proposed by Eschenauer and Gligor
  • Relies on probabilistic key sharing among nodes of WSN
  • Uses simple shared-key discovery protocol for key distribution, revocation and node re-keying
  • Three phases are involved: key pre-distribution, shared-key discovery, path-key establishment
eschenauer gligor scheme
Eschenauer-Gligor Scheme

Key Pool

S

Each node

randomly

selects m keys

A

B

C

D

E

  • When |S| = 10,000, m=75
    • Pr (two nodes have a common key) =0.50
slide15

Observations and Objectives

A

B

F

Problem: How to pick a large key pool while maintaining high connectivity? (i.e. maintain resilience while ensuring connectivity)

deployment based scheme
Deployment-based Scheme
  • Proposed by Du, et. al (IEEE Infocom 2004)
  • Improves Random Key Predistribution (Eschenauer and Gligor) by exploiting Location Information
  • Studies a Gaussian distribution for deployment of Sensor nodes to improve security and memory usage
deployment based scheme17
Deployment-based Scheme
  • Groups select from key group S (i,j)
  • Probability node is in a certain group is (1 / tn).
step 1 key pre distribution key sharing among key pools
Step 1 : Key Pre-distribution - Key Sharing Among Key Pools -

Horizontal

a

B

C

A

b

b

a

D

F

a

a

Vertical

Diagonal

a

b

b

G

H

I

b

a

step 1 key pre distribution key sharing among key pools19
Step 1 : Key Pre-distribution - Key Sharing Among Key Pools -
  • Determining |Sc|
    • When |S| = 100,000, t = n = 10, a = 0.167, b = 0.083

|Sc| = 1770

step 2 shared key discovery
Step 2: Shared-key Discovery
  • Takes place during initialization phase after WSN deployment. Each node discovers its neighbor in communication range with which it shares at least one key
  • Nodes can exchange IDs of keys that they poses and in this way discover a common key
  • A more secure approach would involve broadcasting a challenge for each key in the key ring such that each challenge is encrypted with some particular key. The decryption of a challenge is possible only if a shared key exists
step 3 path key establishment
Step 3: Path-key Establishment
  • During the path-key establishment phase path-keys are assigned to selected pairs of sensor nodes that are within communication range of each other, but do not share a key
  • Find secure path by using flooding method
    • Limit the lifetime of the flooding message to three hops to reduce flooding overhead
  • Share random key K by using secure path
local connectivity
Local Connectivity
  • With 100 keys, location management improves local connectivity from 0.095 to 0.687
network resilience
Network Resilience
  • What is the damage when x nodes are compromised?
    • These x nodes contain keys that are used by the good nodes
    • What percentage of communications can be affected?
conclusion
Conclusion
  • Robust security mechanisms are vital to the wide acceptance and use of senor networks for many applications
  • Security in WSN is quite different from traditional (wired) network security
  • Various peculiarities of WSN make the development of good key scheme a challenging task
  • We have discussed several approaches to key management in WSN
references
References
  • I. F. Akyildiz, W. Su, Y. Sankarasubramaniam, and E. Cyirci. Wireless Sensor Networks: A Survey. Computer Networks, 38(4):393-422, 2002.
  • L. Eschenauer and V. Gligor. A Key-Management Scheme for Distributed Sensor Networks. In Proc. of ACM CCS’02, November 2002.
  • H. Chan, A. Perrig, and D. Song. Random Key Predistribution Schemes for Sensor Networks. In 2003 IEEE Symposium on Research in Security and Privacy.
  • W. Du, J. Deng, Y. Han, S. Chen, and P. Varshney. A Key Management Scheme for Wireless Sensor Networks Using Deployment Knowledge. IEEE Infocom 2004.
