Presentation Transcript


New approximate strategies for playing sum games based on subgame types l.jpg

New Approximate Strategies for Playing SumGames Based on Subgame Types

Authored by:

Manal M. Zaky

Cherif R. S. Andraos

Salma A. Ghoneim

Presented by:

Manal M. Zaky


Outline l.jpg

Outline

  • Sum Games

  • Combinatorial Game Theory

  • Previous Strategies

  • New Strategies

  • Experimental Results

  • Conclusions and Future Work

ICCSE’06, Cairo, Egypt


Sum games l.jpg

Sum Games

  • Let G1 ,...,Gn represent n games

  • Playing in the sum game

    G = G1 +...+Gn

    consists of picking a component game Gi and making a move in it

ICCSE’06, Cairo, Egypt


Sum games cont l.jpg

=

+

+

Sum Games (cont.)

  • Example I: NIM

    • Several heaps of coins

    • In his turn, a player selects a heap, and removes any positive number of coins from it, maybe all

  • Goal

    • Take the last coins

  • Example with 3 piles: (3,4,5)

ICCSE’06, Cairo, Egypt


Sum games cont5 l.jpg

Sum Games (cont.)

  • Many games tend to decompose into a number of independent regions or subgames.

  • Examples:

    • Domineering

    • GO

    • Amazons

ICCSE’06, Cairo, Egypt


Sum games cont6 l.jpg

Sum Games (cont.)

  • Example II: Domineering

    • Start with the board empty

    • In his turn a player places a domino on the board:

      • Blue places them vertically

      • Red places them horizontally

  • Goal

    • Place the last domino

  • Example game

=

ICCSE’06, Cairo, Egypt


Sum games cont7 l.jpg

Sum Games (cont.)

  • Example III: Go

    • The standard Go board is 19X19; games are also played on 13X13 and 9X9.

    • The Go board begins empty. One player uses the black stones and the other uses the white stones.

    • Black always goes first. Players take turns placing one stone on the board.

    • Once a stone is placed on the board, it is never moved unless it is captured

    • Game ends when both players agree that there are no more moves to be played.

  • Goal

    • surround more territory than the opponent

ICCSE’06, Cairo, Egypt


Sum games cont8 l.jpg

Sum Games (cont.)

  • Example III: Go (cont.)

    • Towards endgame, board becomes partitioned into a number of independent subgames

ICCSE’06, Cairo, Egypt


Sum games cont9 l.jpg

Sum Games (cont.)

  • Full game: high branching factor, long game

  • Local game: low branching factor, short game

Challenge: how to combine local analyses

To achieve near optimal results

ICCSE’06, Cairo, Egypt


Sum games cont10 l.jpg

Sum Games (cont.)

  • Tool for Local Game Search:

    • minimax search

      • Unable to consider successive moves by same player

      • Cannot be used to find best global sequence

    • Combinatorial game theory(CGT)

      is used to perform the search due to its ability to represent a game as a sum of independent subgames

ICCSE’06, Cairo, Egypt


Sum games11 l.jpg

Sum Games

  • CGT

  • Deals with partitioned game

  • Local analysis

  • Search time exponential insize ofsubproblems

Minimax

  • Considers the sum game as one unit

  • Full board evaluation

  • Search time exponential in size of thefull problem

ICCSE’06, Cairo, Egypt


Outline12 l.jpg

Outline

  • Sum Games

  • Combinatorial Game Theory

  • Previous Strategies

  • New Strategies

  • Experimental Results

  • Conclusions and Future Work

ICCSE’06, Cairo, Egypt


Combinatorial game theory l.jpg

Combinatorial Game Theory

  • Developed by Conway, Berlekamp and Richard K. Guy in the 1960s

  • A combinatorial game is any two player perfect information game satisfying the following conditions:

    • Alternating moves

    • Player who cannot move loses

    • no draws

    • No random element

ICCSE’06, Cairo, Egypt


Combinatorial game theory cont l.jpg

Combinatorial Game Theory (cont.)

  • Combinatorial game theory (cgt) provides abstract definition of combinatorial games

  • A game position is defined by sets of follow-up positions for both players (Left, Right)

    G={GL|GR}={L1,L2,L3|R1,R2}

ICCSE’06, Cairo, Egypt


Combinatorial game theory cont15 l.jpg

Combinatorial Game Theory (cont.)

  • Examples:

    • The simplest game is the ‘zero game’ in which no player has a move:

      0 = { | } with GL, GR empty

    • The game 1 = {0 | } = { { | } | } represents one free move for Left

    • Similarly, The game -1 = { | 0 } = { | { | } } represents one free move for Right

    • G = { {14 | 10} | {7|3} }

ICCSE’06, Cairo, Egypt


Combinatorial game theory cont16 l.jpg

Combinatorial Game Theory (cont.)

  • Hot Game

    • A game in which each player is eager to play

    • A hot game is not a number

    • Example of a hot game:

ICCSE’06, Cairo, Egypt


Combinatorial game theory cont17 l.jpg

Combinatorial Game Theory (cont.)

  • Properties of Hot Games:

    • Temperature:

      • Measures urgency of move

    • Type:

      • Sente

        • A sente move by a player implies a severe threat follow-up forcing the opponent to answer locally. This leaves the original player free to play where he chooses, thereby controlling the flow of the game.

      • Double Sente

        • is a move which is sente for either player

      • Gote

        • a move which loses the initiative, since it need not be answered by the opponent, thus giving him Sente

ICCSE’06, Cairo, Egypt


Combinatorial game theory cont18 l.jpg

Combinatorial Game Theory (cont.)

  • Properties of hot games (cont.)

    • Thermograph

ICCSE’06, Cairo, Egypt


Combinatorial game theory cont19 l.jpg

Combinatorial Game Theory (cont.)

  • Thermographs of simple hot games of the form G={{A|B}{C|D}}

temperature

ICCSE’06, Cairo, Egypt


Combinatorial game theory cont20 l.jpg

Combinatorial Game Theory (cont.)

  • Approximate Strategies to Play Sum Games based on CGT

    • Compute simple properties of each subgame

      • Thermograph

      • Temperature

      • Type

    • Make global decision based on one or more of these properties

ICCSE’06, Cairo, Egypt


Outline21 l.jpg

Outline

  • Sum Games

  • Combinatorial Game Theory

  • Previous Approximate Strategies

  • New Strategies

  • Experimental Results

  • Conclusions and Future Work

ICCSE’06, Cairo, Egypt


Previous approximate strategies for playing sum games l.jpg

Previous Approximate Strategies for Playing Sum Games

  • ThermoStrat

    • Graphical determination of the best subgame based on the compound thermograph of the sum

  • MaxMove

    • Compute the width of the thermograph at t=0 for each subgame

    • Play in subgame with maximum value

  • HotStrat:

    • Compute temperature of each subgame

    • Play in hottest subgame

  • MaxThreat

    • Choose the best subgame by comparing them two by two using minimax

ICCSE’06, Cairo, Egypt


Previous approximate strategies for playing sum games23 l.jpg

Previous Approximate Strategies for Playing Sum Games

  • Performance of Approximate Strategies Compared to Optimal

    • Thermostrat is always good. For subgames with different types gives same result as optimal in 90% of the cases and slightly less in others.

    • The performance of each of Hotstrat and Maxmove is highly dependent on the types of subgames participating in the sum.

    • MaxMove strategy gives the same result as ThermoStrat for the pattern with only reverse sente games. Performs badly for the rest.

    • HotStrat shows very low performance in dealing with patterns that contain reverse sente subgames alone or when combined with only sente games but very good otherwise.

ICCSE’06, Cairo, Egypt


Previous approximate strategies for playing sum games performance l.jpg

Previous Approximate Strategies for Playing Sum Games - Performance

  • Maxthreat’s performance depends on the order in which

    subgames are considered when the sum contains one or more sente gamesas shown

ICCSE’06, Cairo, Egypt


Outline25 l.jpg

Outline

  • Sum Games

  • Combinatorial Game Theory

  • Previous Approximate Strategies

  • New Strategies

  • Experimental Results

  • Conclusions and Future Work

ICCSE’06, Cairo, Egypt


Slide26 l.jpg

ICCSE’06, Cairo, Egypt


Slide27 l.jpg

ICCSE’06, Cairo, Egypt


Outline28 l.jpg

Outline

  • Sum Games

  • Combinatorial Game Theory

  • Previous Approximate Strategies

  • New Strategies

  • Experimental Results

  • Conclusions and Future Work

ICCSE’06, Cairo, Egypt


Experimental results l.jpg

Experimental Results

  • Performance

ICCSE’06, Cairo, Egypt


Experimental results cont l.jpg

Experimental Results (cont.)

Time Considerations

ICCSE’06, Cairo, Egypt


Outline31 l.jpg

Outline

  • Sum Games

  • Combinatorial Game Theory

  • Previous Approximate Strategies

  • New Strategies

  • Experimental Results

  • Conclusions and Future Work

ICCSE’06, Cairo, Egypt


Conclusions l.jpg

Conclusions

ICCSE’06, Cairo, Egypt


Future work l.jpg

Future Work

ICCSE’06, Cairo, Egypt


Thank you l.jpg

Thank You

ICCSE’06, Cairo, Egypt
