3. The bottom line, what is this all about?Collection of Aeronautical data

4. This is where the rubber meets the road.Data Provides, pay attention!Defines process for submitting data to AGIS

5. Deliverables DefinedData, Reports, Plans, Status…

6. Table 2-1Scope of Work (Contract Document)The Work Plan

7. Tie the knot between the runway and ground based navigation facilities (NAVAIDS).The two must be connected.

8. Read… Aeronautical Survey….Vertically or non vertically guided approachAeronautical Survey is here!Defines the surfaces and areas to be surveyedLook UP!

9. Engineering (Construction) SurveysElements to be surveyed for construction projectsPavement, utilities including SUE, boundaries

10. Review of GIS Specifications and Standards

11. Moving your data into AGIS using the DMTAutoDesk Civil 3D, AutoDesk, MicroStation, or ESRI to AGIS

12. Data Capture RulesNames Listed AlphabeticallyUse the PDF Search Function

13. Attribute Enumerations (What???), Code Who????Coordinate Systems, design groups, temporal, colors, land use

14. Appendicesor Appendix Attack?Now Look DOWN!

15. Know what NAVAIDS are on your airport and the survey accuracy requirements (pages 107-367)

16. Runway End… Feature Class Name: RunwayEnd

17. Easy to Locate RunwayEnd?

18. Runway Threshold Lights are likely not at the same place as RunwayEnd

19. Caution; The paint (markings) on the runway may be in the wrong place

20. NAVAID Equipment (Glideslope)

21. Glideslope antenna and equipment shelter

22. Localizer (LOC)

23. Localizer Runway 27; Antenna on Runway 9 end
