Analysis of PPB Level Volatile Chemicals using Static Preconcentration Introduction to Sampling and Analysis of Volatile Chemicals Comparison with other VOC Methods Air Analysis - Canister Methods Liquids and Solids - Large Volume Static Headspace (LVSH) Technique Other Applications Summary

Related searches for Catalogs : Entech : Products : PRODUCTS

loader
I am the owner, or an agent authorized to act on behalf of the owner, of the copyrighted work described.
capcha
Download Presentation

PowerPoint Slideshow about 'Catalogs : Entech : Products : PRODUCTS' - Faraday


An Image/Link below is provided (as is) to download presentation

Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author.While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server.


- - - - - - - - - - - - - - - - - - - - - - - - - - E N D - - - - - - - - - - - - - - - - - - - - - - - - - -
Presentation Transcript

Presentation overview l.jpg

Introduction to Sampling and Analysis of Volatile Chemicals Preconcentration

Comparison with other VOC Methods

Air Analysis - Canister Methods

Liquids and Solids - Large Volume Static Headspace (LVSH) Technique

Other Applications

Summary

Presentation Overview


Gc ms detection limits vs headspace sample volume l.jpg
GC/MS Detection Limits vs Headspace Sample Volume Preconcentration

1000

100

10

1

0.1

0.01

10-3

10-4

10-5

Loop

Preconcentration

PPM

LOD

Vol vs Conc.

0.001 0.01 0.1 1.0 10 100 1000

MINIMUM VOLUME REQUIRED (CC)


Slide4 l.jpg

Classical VOC Sampling and Analysis Preconcentration

  • Air

    • Tedlar Bags

    • Adsorbent Tubes

    • Stainless Steel Canisters (EPA TO14, TO15)

  • Liquids & Solids

    • Purge and Trap

    • Static Headspace - Loop Injection


Slide5 l.jpg

Classical VOC Sampling and Analysis Preconcentration

  • Air

    • Tedlar Bags

    • Adsorbent Tubes

    • Stainless Steel Canisters (EPA TO14, TO15)

  • Liquids & Solids

    • Purge and Trap

    • Static Headspace - Loop Injection

    • Large Volume Static Headspace


Slide6 l.jpg

Air Sampling Media Preconcentration


Slide7 l.jpg

Volume Determination Preconcentration

  • Loop or Syringe Injection

    • Must equilibrate Sample to Atmospheric

    • Canister must usually be at positive pressures.

    • For Sample Volumes under 5 cc

P

  • Mass Flow Time Integration

    • Canister Can be at Positive or Negative Pressure

    • Must verify leak free conditions before starting

    • MFC Downstream of trap reduces carryover

    • On-line Pressure Sensor monitors trap blockage

    • For Sample Volumes 10cc and larger

MFC


Low concentration measurements epa methods to14 to15 l.jpg
Low Concentration Measurements Preconcentration(EPA Methods TO14 / TO15)



Advantages of canisters over tubes l.jpg

Canisters Tubes Samples

Chance For Volume Measurement Errors No Yes

Traps Checked for Blank and Analyte Recovery Yes No

Allow Repeat Analyses Yes No

Chance for Post Cleaning Contamination Minor Yes

Permits Sample Screening Yes No

Allows Mild Trapping/Desorption Conditions Yes No to Maximize Yields

Requires Power for Sampling No Yes

Requires Conc. To be known Before Sampling No Yes

Advantages Of Canisters Over Tubes





Slide15 l.jpg

1320 32-Position Field Sampler and 1L MiniCans Samples

Bridging The Gap Between Tubes and Canisters


Slide16 l.jpg

Six Sites Monitored with Just 2 Analyzers Samples

CS6

CS1

Centralized Lab

Analyzers

CS2

CS5

1

2

CS3

CS4



Slide18 l.jpg

Are 1 Liter Canisters Large Enough? Samples

Instrument: 7100 Preconcentrator

Application Detector Sample Vol. LOD

PAMS FID 400cc 0.1 PPB(c)

PAMS 5973 MS 400cc 0.05 PPB(v)

Air Toxics 5973 MS 400cc 0.05 PPB(v)

Air Toxics (SIMS) 5973 MS 400cc 0.005 PPB(v)

Limited to Single Analysis - OK for Continuous Monitoring


Slide19 l.jpg

Clean 21 (or 42) Canisters Simultaneously Samples

  • 3 Batches a day equals 63 Canisters

  • Supports 7 sites with single 21 position manifold

  • Supports 14 sites with two 21 position manifolds




Slide22 l.jpg

7032-LVSH / 7100 /5973 Samples

Large Volume Static Headspace Analyzer

M3

SL I/O

SL I/O

M2

6

M1

GC

MS

7100

7032-LVSH


Slide23 l.jpg

7100 Heated Flow Path Samples

  • Silonite tubing used throughout.

  • Complete heating of sample flow path. Easily accessed for trap and tubing replacement.

  • External Heaters outside each cryotrap

7100 Preconcentrator


Silonite tm fused silica lined tubing l.jpg
Silonite SamplesTM Fused Silica Lined Tubing


Slide25 l.jpg

7100 Water and CO2 Management Techniques Samples

MFC

PUMP

Loading Internal Standard

N2, O2

Helium Carrier

Helium

To

GC

Focuser

Glass Beads

Tenax

Sample

Internal

Standard

Calibration

Standard

Sample

Cryogen in


Slide26 l.jpg

7100 Water and CO2 Management Techniques Samples

MFC

PUMP

Loading Calibration Standard

Helium Carrier

N2,O2

Helium

To

GC

Focuser

Glass Beads

Tenax

Sample

Internal

Standard

Calibration

Standard

Cryogen in


Slide27 l.jpg

7100 Water and CO2 Management Techniques Samples

MFC

PUMP

Loading Sample

Helium Carrier

N2, O2,

Ar, CH4

Helium

To

GC

CO2

H2O

Focuser

VOCs

Glass Beads

Tenax

Sample

Internal

Standard

Calibration

Standard

Cryogen in


Slide28 l.jpg

7100 Water and CO2 Management Techniques Samples

MFC

PUMP

Flushing Traps

Helium Carrier

N2, O2,

Ar, CH4

Helium

To

GC

CO2

H2O

Focuser

VOCs

Glass Beads

Tenax

Sample

Internal

Standard

Calibration

Standard

Cryogen in


Slide29 l.jpg

7100 Water and CO2 Management Techniques Samples

MFC

PUMP

Removing Water and CO2

CO2

Helium Carrier

Helium

To

GC

H2O

VOCs

Focuser

Glass Beads

Tenax

Sample

Internal

Standard

Calibration

Standard

Cryogen in


Slide30 l.jpg

7100 Water and CO2 Management Techniques Samples

MFC

PUMP

Focusing Sample before Injection

Helium Carrier

Helium

VOCs

To GC

VOCs

Focuser

Glass Beads

Tenax

Sample

Internal

Standard

Calibration

Standard

Cryogen in


Slide31 l.jpg

7100 Water and CO2 Management Techniques Samples

MFC

PUMP

H2O

Post-Injection Bakeout

Helium Carrier

Helium

To

GC

Focuser

Glass Beads

Tenax

Sample

Internal

Standard

Calibration

Standard

Cryogen in


Slide32 l.jpg

Fast Injection and Proper Water Management Minimizes Tailing of Polar VOCs

Column: HP1, 60m, 0.32mm ID, 1um film.

Flow rate: 1.5 ccm

Carrier: He


Slide33 l.jpg

1 Week TO14 Stability Test of Polar VOCs

1 Liter MiniCan

Concentration: 10 PPB

Volume: 400cc

Instrument: 7100/5973 GCMS

Column: HP1, 60m, 0.32ID, 1um

Column Start Temp: 35 deg. C


Slide34 l.jpg

TO15 Precision Study using of Polar VOCs

7100 Preconcentrator and 5973 GCMS

Data Compliments of:

Columbia Analytical

Jacksonville, Florida


Slide35 l.jpg

TO15 Precision Study using of Polar VOCs

7100 Preconcentrator and 5973 GCMS

Data Compliments of:

Columbia Analytical

Jacksonville, Florida


Slide36 l.jpg

TO15 Precision Study using of Polar VOCs

7100 Preconcentrator and 5973 GCMS

Data Compliments of:

Columbia Analytical

Jacksonville, Florida


Slide37 l.jpg

C2-C10 GC/FID Analysis - Light Ends of Polar VOCs

GC: 5890

Column: 60m, 0.32mmID, 1um, DB1

Preconc: MP&T, 400cc, 30ppbc Std

GC Start Temp: -50 for 4 minutes


Slide38 l.jpg

Vinyl Chloride 100x Calibration Curve using of Polar VOCsVariable Volume / Single Standard Calibration


Advantages of 7100 multi stage preconcentration l.jpg

Multiple Preconcentration Options Depending on Target Compounds and Matrix (CO2, ETOH)

Better Recovery of Thermally Labile Flavor and Odor Compounds:

Strong Carbon Based Adsorbents are Avoided

Inert, Silonite Tubing used Throughout

Reduced Temperature Trapping Minimizes Sample Stress

Advantages of 7100 Multi-Stage Preconcentration


Large volume static headspace autosampler l.jpg

Introduces 10-200cc of headspace to the 7100 Preconcentrator Compounds and Matrix (CO2, ETOH)

Accommodates solids and liquids

Detection limits 100x lower than conventional loop injection headspace

“See what you can smell”

Large Volume Static Headspace Autosampler


Slide41 l.jpg

LVSH Sample Platforms and Enclosures Compounds and Matrix (CO2, ETOH)

  • Samples are placed in disposable vials, reducing potential for contamination of sample platforms.

  • Sample Platforms use quick connects, simplifying removal for oven bakeout.


Slide42 l.jpg

Cheddar Cheese by LVSH/GCMS Compounds and Matrix (CO2, ETOH)

Cheddar Cheese, Brand A

100cc, LVSH

60m, HP1, 0.32mm ID, 1um

7032LVSH/7100/5973

Cheddar Cheese, Brand B

100cc, LVSH

60m, HP1, 0.32mm ID, 1um

7032LVSH/7100/5973

Toluene


Slide43 l.jpg

Beer by LVSH/GCMS Compounds and Matrix (CO2, ETOH)

Beer, EtOH Removed

200cc, LVSH

60m, HP1, 0.32mm ID, 1um

7032LVSH/7100/5973

EtOH


Slide44 l.jpg

Advantages of Large Volume Static Headspace (LVSH) over Purge and Trap

  • Cleaner. No aerosols or foaming to contaminate sample transfer lines

  • Better Recovery of Thermally Labile Flavor and Odor Compounds:

    • Strong carbon based adsorbents are avoided

    • Inert, Silonite tubing used throughout

    • Reduced temperature trapping minimizes sample stress, improving recovery and reducing artifact formation

  • Better matrix elimination using 3-stage trapping

  • More accurate determination of steady state distribution of chemicals in the sample headspace

  • Allows direct comparison of liquid, solid, and gas phase collected samples


Slide45 l.jpg

Advantages of Large Volume Static Headspace (LVSH) over SPME Purge and Trap

  • Less discrimination against light end compounds

  • LVSH is a closed system. Little chance of contamination with room air

  • Lower detection limits, especially for more volatile compounds

  • SPME cannot compare liquid, solid, and gas phase collected samples





Slide49 l.jpg

100cc LVSH - Coke/Pepsi Challenge Purge and Trap

Coke

Pepsi


Slide50 l.jpg

Using LVSH to Determine Product Quality Markers in Fruits and Vegetables

  • Analysis of 100cc of Headspace allows detection of VOCs indicating condition of food products.

  • Monitoring changes in VOC ratios as food spoils allows quantitative evaluation of extent of spoilage.

  • Once specific “Markers” are determined, remote headspace techniques can be used to predict food condition and time until spoilage in storage containers and warehouses.


Slide51 l.jpg

100cc LVSH Analysis of Tomato and Vegetables

2

1. CO2

2. Methanol

3. Ethanol

4. Acetone

5. 2-Methyl Furan

6. DHHN

1

6

5

1

4

Loop Injection

Detection Limit

3

IS

3

IS

4

5

2

6


Slide52 l.jpg

LVSH Analysis of Tomatoes - Scaled to show PPB Cmpds and Vegetables

Multiple

PPB Level

Markers


Slide53 l.jpg

Tomato Chemical Markers Indicating Quality and Vegetables

  • Heavy aldehydes increased as food spoils

  • The largest increase was from a semi-volatile tentatively identified as DHHN

  • In this study, the ratio of DHHN to 2-Methyl Furan was determined to be an excellent indicator of product quality


Slide54 l.jpg

Multiple Applications for Static VOC Analysis and Vegetables

- Personal Exposure Monitoring/Industrial Hygiene

- Breath Analysis

- Sulfur Gas Analysis

- Product Outgassing

- Product Quality Testing

- Arson Investigation

- Emergency Response


Personal sampling with the minican l.jpg
Personal Sampling with the MiniCan and Vegetables

  • Whole Air Sample Collection Provides a More Universal Approach

  • Sampling Times from 1 Minute to 8 Hours

  • Does not Require Volume Determination in the Field


Comparing monitoring techniques l.jpg
Comparing Monitoring Techniques and Vegetables

Vol Measured During Samp

Yes Yes No NN

NN - Not Necessary


Slide57 l.jpg

1. When target compound list is not well known (initial investigations)

2. When specified target compound list requires 2 or more different tubes

3. When no OSHA/NIOSH method exists for the target compounds (Literally thousands of compounds fall into this category)

4. When GCMS is desired to provide better identification certainty and to resolve co-eluting compounds.

When to use MiniCans for Personal Sampling


Slide58 l.jpg

Soil Gas Sampling investigations)

  • Collects soil gas at 1m depths

  • Ideal for screening applications



Slide60 l.jpg

Solvent Enhancement Enclosure investigations)

for Surface Contaminants


Slide61 l.jpg

VOCs in Soil by LVSH investigations)

  • Easier sample prep and clean-up than Purge and Trap

  • Large Sample Loading (25 grams)

  • Samples can be heated to 150 deg. C


Silonite tm coating improves recovery of reactive compounds l.jpg

Fused Silica coating prevents chemical interaction with underlying stainless steel surface

Improves VOC Stability

Ideal for sulfur and nitrogen containing compounds

SiloniteTM Coating Improves Recovery of Reactive Compounds


Slide63 l.jpg

Chemicals in Human Breath underlying stainless steel surface

  • Chemicals equilibrate with alveolar air proportional to their concentration in the blood

  • Monitoring VOCs in breath provides information on:

    • Exposure to Chemicals

    • Disease Conditions


Slide64 l.jpg

Low Volume Breath Sampler underlying stainless steel surface


Slide65 l.jpg

Surrogate Spiking and Automated Analysis underlying stainless steel surface

7032 Autosampler

Surrogate Spiking


Slide66 l.jpg

5973/7100/7032 200cc Injection underlying stainless steel surface10 PPB Sulfur Std., ECTD

5

1. CO2

2. H2S

3. COS

4. MeSH

5. DMS

6. CS2

6

4

3

1

2


Slide67 l.jpg

2-Day Stability Study of Sulfur Compounds in underlying stainless steel surface

Fused Silica Lined vs Electropolished Canisters

7000 / HP5973 Data


Slide68 l.jpg

5-Point underlying stainless steel surfaceSulfur Gas Calibrations

H2S

DMS

CS2

MeSH


Slide71 l.jpg

40 Day Formaldehyde Stability in Silonite Coated MiniCan underlying stainless steel surface

Analysis of Cylinder - 9 December 1999

2.52 ppm

2.65 ppm

2.54 ppm

Analysis of Mini Canister #1086 - 10 December 1999

2.56 ppm

2.44 ppm

Analysis of Mini Canister #1087 - 10 December 1999

2.57 ppm

2.56 ppm

Let time pass....

Analysis of Mini Canister #1086 - 20 January 2000

2.46 ppm

2.53 ppm

Analysis of Mini Canister #1087 - 20 January 2000

2.37 ppm

2.47 ppm

Data Courtesy of

Dr. Daniel Riemer,

NCAR


Additional applications benefiting from trace level analysis of airborne chemicals l.jpg

Forensics underlying stainless steel surface

Identification of Illegal Drug Laboratories

Breath Analysis: The “Reverse Fingerprint”

Arson Investigation

Rapid Sampling and Analysis On-Site

Emergency Response

Fast yet Complete Compound Identification and Quantitation

Fire Inspection / Chemical Inventory Determination

Developing fire fighting strategies based on chemicals present

Detection and remediation of potentially hazardous conditions

Additional Applications Benefiting from Trace Level Analysis of Airborne Chemicals


Slide73 l.jpg

Accelerant Sampling with MiniCans underlying stainless steel surface

Quickly sample vapor phase chemicals by sweeping inlet nozzle over locations most likely to revel accelerants.

Use the Solvent Enhancement Enclosure (SEE) to concentrate vapors where concentrations are expected to be low due to intense heat or gusty winds.


Slide74 l.jpg

Emergency Response underlying stainless steel surface

Monitoring of Chemical Releases

RGS

RGS

Chemical Release

RGS

RGS

Facility

4 Hr PS

4 Hr PS

4 Hr PS

Community

RGS - Restricted Grab Sample (5-15 minutes)


Slide75 l.jpg

Quarterly/Annual Vacuum Verification underlying stainless steel surface


Slide76 l.jpg

Daily/Weekly Testing of Atmosphere in underlying stainless steel surfaceChemical Storage Rooms


Slide77 l.jpg

Consumer Product Testing for underlying stainless steel surfaceVOC Emission Rates

N2 or Zero Air


Conclusion l.jpg

Analysis of Trace VOCs can be performed in a variety of matrices using a static sample introduction technique.

For natural products, maintaining the sample in an unaltered state allows the analysis of “normally occurring” volatile compounds.

Inert flow paths and reduced temperature trapping increases the range of analytes that can be recovered, including oxygen, nitrogen, and sulfur containing compounds.

Sampling devices are available for collecting and storing gas-phase volatile chemicals opening up a host of new applications and possibilities.

Conclusion


ad
