Presentation Transcript


5 the processor datapath and control l.jpg

5. The Processor: Datapath and Control

순천향대학교 정보기술공학부 이 상 정 1


The processor datapath control l.jpg

The Processor: Datapath & Control

  • We're ready to look at an implementation of the MIPS

  • Simplified to contain only:

    • memory-reference instructions: lw, sw

    • arithmetic-logical instructions: add, sub, and, or, slt

    • control flow instructions: beq, j

  • Generic Implementation:

    • use the program counter (PC) to supply instruction address

    • get the instruction from memory

    • read registers

    • use the instruction to decide exactly what to do

  • All instructions use the ALU after reading the registersWhy? memory-reference? arithmetic? control flow?

순천향대학교 정보기술공학부 이 상 정 2


More implementation details l.jpg

More Implementation Details

  • Abstract / Simplified View:Two types of functional units:

    • elements that operate on data values (combinational)

    • elements that contain state (sequential)

순천향대학교 정보기술공학부 이 상 정 3


State elements l.jpg

State Elements

  • Unclocked vs. Clocked

  • Clocks used in synchronous logic

    • when should an element that contains state be updated?

cycle time

순천향대학교 정보기술공학부 이 상 정 4


An unclocked state element l.jpg

An unclocked state element

  • The set-reset latch

    • output depends on present inputs and also on past inputs

순천향대학교 정보기술공학부 이 상 정 5


Latches and flip flops l.jpg

Latches and Flip-flops

  • Output is equal to the stored value inside the element(don't need to ask for permission to look at the value)

  • Change of state (value) is based on the clock

  • Latches: whenever the inputs change, and the clock is asserted

  • Flip-flop: state changes only on a clock edge(edge-triggered methodology)

"logically true",

— could mean electrically low

A clocking methodology defines when signals can be read and written

— wouldn't want to read a signal at the same time it was being written

순천향대학교 정보기술공학부 이 상 정 6


D latch l.jpg

D-latch

  • Two inputs:

    • the data value to be stored (D)

    • the clock signal (C) indicating when to read & store D

  • Two outputs:

    • the value of the internal state (Q) and it's complement

순천향대학교 정보기술공학부 이 상 정 7


D flip flop l.jpg

D flip-flop

  • Output changes only on the clock edge

순천향대학교 정보기술공학부 이 상 정 8


Our implementation l.jpg

Our Implementation

  • An edge triggered methodology

  • Typical execution:

    • read contents of some state elements,

    • send values through some combinational logic

    • write results to one or more state elements

순천향대학교 정보기술공학부 이 상 정 9


Register file l.jpg

Register File

  • Built using D flip-flops

Do you understand? What is the “Mux” above?

순천향대학교 정보기술공학부 이 상 정 10


Abstraction l.jpg

Abstraction

  • Make sure you understand the abstractions!

  • Sometimes it is easy to think you do, when you don’t

순천향대학교 정보기술공학부 이 상 정 11


Register file12 l.jpg

Register File

  • Note: we still use the real clock to determine when to write

순천향대학교 정보기술공학부 이 상 정 12


Elements for instruction fetch l.jpg

Elements for Instruction Fetch

  • Basic Instruction Fetch Unit

순천향대학교 정보기술공학부 이 상 정 13


Elements for r format instructions load store instuctions l.jpg

Elements for R-format Instructions /Load/Store Instuctions

  • Two elements for R-format

    • R[rd] <- R[rs] op R[rt]

  • Additional elements for Load/Store

    • R[rt] <- Mem[R[rs] + SignExt[imm16]]

순천향대학교 정보기술공학부 이 상 정 14


Datapath for a branch l.jpg

Datapath for a Branch

  • If (R[rs] == R[rt]) PC <- PC + 4 + ( SignExt(imm16) x 4 )

    Else PC <- PC + 4

순천향대학교 정보기술공학부 이 상 정 15


Datapath for lw sw and r type l.jpg

Datapath for Lw/Sw and R-type

순천향대학교 정보기술공학부 이 상 정 16


Putting it altogether l.jpg

Putting it Altogether

순천향대학교 정보기술공학부 이 상 정 17


Control l.jpg

Control

  • Selecting the operations to perform (ALU, read/write, etc.)

  • Controlling the flow of data (multiplexor inputs)

  • Information comes from the 32 bits of the instruction

  • Example: add $8, $17, $18 000000 10001 10010 01000 00000 100000 op rs rt rd shamt funct

  • ALU's operation based on instruction type and function code

순천향대학교 정보기술공학부 이 상 정 18


Three instruction classes l.jpg

op(6) rs(5) rt(5)rd(5) shamt(5)func(6)

op(6) rs(5) rt(5) 16 bit address

op(6) 26 bit address

Three Instruction Classes

  • op. 6 bits and funct. 6 bits can be used to generate control signals

  • I-type an J-type instructions only have op. 6 bits

  • R-type instructions have both op. 6 bits and funct. 6 bits

R

I

J

순천향대학교 정보기술공학부 이 상 정 19


Alu control l.jpg

ALU Control

  • e.g., what should the ALU do with this instruction

  • Example: lw $1, 100($2) 35 2 1 100 op rs rt 16 bit offset

  • ALU control input0000 AND0001OR0010add0110subtract0111set-on-less-than1100NOR

순천향대학교 정보기술공학부 이 상 정 20


Control with local decoding l.jpg

RegDst

Big Single Control Logic

(becomes slow)

Branch

op

MemRead

6

MemtoReg

RegWrite

func

MemWrite

6

ALUSrc

ALUctr

4

func

ALUctr

Small

Control 2

(fast)

op

6

Small

Control 1

(fast)

4

ALUop

6

2

RegDst

Branch

MemRead

MemtoReg

RegWrite

MemWrite

ALUSrc

Control with Local Decoding

ALU Control

Main Control

순천향대학교 정보기술공학부 이 상 정 21


Alu control aluctr l.jpg

ALU Control (ALUctr)

순천향대학교 정보기술공학부 이 상 정 22


Truth table for alu control l.jpg

Truth Table for ALU Control

  • Can turn into gates:

순천향대학교 정보기술공학부 이 상 정 23


Control for r type instruction l.jpg

Control for R-type Instruction

  • Data path and active control signals are highlighted

순천향대학교 정보기술공학부 이 상 정 24


Control for load instruction l.jpg

Control for “load” instruction

순천향대학교 정보기술공학부 이 상 정 25


Control for branch equal l.jpg

Control for “branch equal”

순천향대학교 정보기술공학부 이 상 정 26


Slide27 l.jpg

순천향대학교 정보기술공학부 이 상 정 27


Truth table for main control l.jpg

Truth Table for Main Control

순천향대학교 정보기술공학부 이 상 정 28


Control29 l.jpg

Control

  • Simple combinational logic (truth tables)

순천향대학교 정보기술공학부 이 상 정 29


Implementing jump l.jpg

Implementing Jump

j Exit

op

Exit (26 bit address)

$pc

xxxx

xxxx

Exit (26 bit address)

00

jump addr.

순천향대학교 정보기술공학부 이 상 정 30


Our simple control structure l.jpg

Our Simple Control Structure

  • All of the logic is combinational

  • We wait for everything to settle down, and the right thing to be done

    • ALU might not produce “right answer” right away

    • we use write signals along with clock to determine when to write

  • Cycle time determined by length of the longest path

We are ignoring some details like setup and hold times

순천향대학교 정보기술공학부 이 상 정 31


Performance of single cycle datapath l.jpg

Performance of Single Cycle Datapath

  • Calculate cycle time assuming negligible delays except:

    • memory (200ps), ALU and adders (100ps), register file access (50ps)

  • Minimum Cycle Time > 600ps!

순천향대학교 정보기술공학부 이 상 정 32


Where we are headed l.jpg

Where we are headed

  • Single Cycle Problems:

    • what if we had a more complicated instruction like floating point?

    • wasteful of area

  • One Solution:

    • use a “smaller” cycle time

    • have different instructions take different numbers of cycles

    • a “multicycle” datapath:

순천향대학교 정보기술공학부 이 상 정 33


Slide34 l.jpg

What’s wrong with our CPI=1 processor?

Arithmetic & Logical

PC

Inst Memory

Reg File

ALU

setup

mux

mux

Load

PC

Inst Memory

Reg File

ALU

Data Mem

setup

mux

mux

Critical Path

Store

PC

Inst Memory

Reg File

ALU

Data Mem

mux

Branch

PC

Inst Memory

Reg File

cmp

mux

  • Long Cycle Time

  • All instructions take as much time as the slowest

  • Real memory is not so nice as our idealized memory

    • cannot always get the job done in one (short) cycle

순천향대학교 정보기술공학부 이 상 정 34


Slide35 l.jpg

storage element

storage element

Combinational

Logic (A)

Combinational

Logic

storage element

Combinational

Logic (B)

storage element

storage element

Reducing Cycle Time

  • Cut combinational dependency graph and insert register / latch

  • Do same work in two fast cycles, rather than one slow one

=>

순천향대학교 정보기술공학부 이 상 정 35


Slide36 l.jpg

Partitioning the CPI=1 Datapath

Add registers between smallest steps

MemWr

MemRd

RegWr

RegDst

nPC_sel

ALUSrc

ExtOp

ALUctr

Reg.

File

Operand

Fetch

Exec

Instruction

Fetch

Mem

Access

PC

Next PC

순천향대학교 정보기술공학부 이 상 정 36


Slide37 l.jpg

Example Multicycle Datapath

MemToReg

RegWr

RegDst

MemWr

MemRd

nPC_sel

ALUctr

ALUSrc

ExtOp

Reg.

File

Ext

ALU

A

Reg

File

S

PC

IR

Next PC

B

Mem

Access

M

Instruction

Fetch

Result Store

Operand

Fetch

순천향대학교 정보기술공학부 이 상 정 37


Slide38 l.jpg

inst Physical Register Transfers

IR <– MEM[pc]

ADDA<– R[rs]; B <– R[rt]

S <– A + B

R[rd] <– S; PC <– PC + 4

A

S

B

M

R-rtype (add, sub, . . .)

inst Logical Register Transfers

ADDR[rd] <– R[rs] + R[rt]; PC <– PC + 4

  • Logical Register Transfer

  • Physical Register Transfers

Reg.

File

Reg

File

Exec

PC

IR

Next PC

Inst. Mem

Mem

Access

순천향대학교 정보기술공학부 이 상 정 38


Slide39 l.jpg

inst Physical Register Transfers

IR <– MEM[pc]

LWA<– R[rs]; B <– R[rt]

S <– A + SignEx(Im16)

M <– MEM[S]

R[rt] <– M; PC <– PC + 4

A

S

B

M

Reg.

File

Reg

File

Exec

PC

IR

Next PC

Inst. Mem

Mem

Access

Load

  • Physical Register Transfers

  • Logical Register Transfer

inst Logical Register Transfers

LWR[rt] <– MEM(R[rs] + sx(Im16);

PC <– PC + 4

순천향대학교 정보기술공학부 이 상 정 39


Slide40 l.jpg

A

S

B

M

Store

  • Logical Register Transfer

  • Physical Register Transfers

inst Physical Register Transfers

IR <– MEM[pc]

SWA<– R[rs]; B <– R[rt]

S <– A + SignEx(Im16);

MEM[S] <– BPC <– PC + 4

inst Logical Register Transfers

SWMEM(R[rs] + sx(Im16) <– R[rt];

PC <– PC + 4

Reg.

File

Reg

File

Exec

PC

IR

Next PC

Inst. Mem

Mem

Access

순천향대학교 정보기술공학부 이 상 정 40


Slide41 l.jpg

S

M

Branch

  • Physical Register Transfers

  • Logical Register Transfer

inst Physical Register Transfers

IR <– MEM[pc]

BEQA<– R[rs]; B <– R[rt]

S <– A - B

Eq:PC<-PC+4+sx(Im16)||00, ~Eq:PC <– PC + 4

inst Logical Register Transfers

BEQif R[rs] == R[rt]

then PC <= PC + 4 + sx(Im16) || 00

else PC <= PC + 4

Equal

Reg.

File

Reg

File

A

Exec

IR

PC

Inst. Mem

Next PC

B

Mem

Access

순천향대학교 정보기술공학부 이 상 정 41


Summary l.jpg

Summary:

순천향대학교 정보기술공학부 이 상 정 42


Slide43 l.jpg

PCWr

PCWrCond

PCSrc

32

Zero

ALUSelA

IorD

MemWr

IRWr

RegDst

RegWr

1

0

Mux

Mux

32

PC

1

0

0

Zero

32

Rs

Mux

Ra

0

32

32

RAdr

5

32

S

1

Rt

busA

A

Mux

Rb

ALU

Control

32

Mux

ALU

1

0

Ideal

Memory

32

Instruction Reg

Reg File

<< 2

5

1

4

0

Rw

32

WrAdr

32

5

busB

B

1

32

Rd

Din

Dout

busW

Extend

2

16

32

3

M

Imm

32

ALUOp

ExtOp

MemtoReg

ALUSelB

Multiple Cycle Datapath

  • Miminizes Hardware: 1 memory, 1 adder

순천향대학교 정보기술공학부 이 상 정 43


Multi cycle datapath control signals l.jpg

Multi-Cycle Datapath & Control Signals

  • Figure 5.28 in page 323

순천향대학교 정보기술공학부 이 상 정 44


High level control flow l.jpg

start

Instruction fetch / decode and register fetch

Memory access

instructions

R-type instructions

Branch instructions

Jump instruction

High-Level Control Flow

  • Common 2-clock sequence to fetch/decode any instruction

  • Separate sequences of 1 to 3 clocks to execute specific types of instruction

  • Two techniques for control

    • finite state machine

    • microprogramming

순천향대학교 정보기술공학부 이 상 정 45


Review of finite state machine fsm l.jpg

Next-state

function

Current state

clock

Inputs

Output

function

Outputs

Review of Finite State Machine(FSM)

  • Finite state machine

    • a set of states and

    • next state function (determined by current state and input)

    • output function (determined by current state and input)

  • We will use a Moore machine

    • output based only on current state

    • cf. Mealy machine: output based on both current state and input

순천향대학교 정보기술공학부 이 상 정 46


Control finite state machine fsm diagram l.jpg

Control Finite State Machine(FSM) Diagram

순천향대학교 정보기술공학부 이 상 정 47


Control finite state machine structure l.jpg

Combinational

Control Logic

(random logic or PLA)

outputs

Datapath control outputs

inputs

Next state

inputs from instruction

register opcode field

State register

Control Finite State Machine Structure

  • Outputs to datapath control determined by current state

  • Next state determined by current state and input from instruction register

순천향대학교 정보기술공학부 이 상 정 48


Pla implementation l.jpg

AND

plane

OP code

current state

OR

plane

PLA Implementation

순천향대학교 정보기술공학부 이 상 정 49


Microprogramming l.jpg

Microprogramming

  • Microprogramming is an alternate structure for implementing the control finite state machine

    • represent outputs and next state selection as microinstructions in a memory (the control store) addressed by the current state (often called the microprogram counter)

    • the control store can be implemented in ROM or RAM (writable control store)

    • provides level of abstraction between software and datapath hardware: firmware

순천향대학교 정보기술공학부 이 상 정 50


Slide51 l.jpg

User program

plus Data

Main

Memory

ADD

SUB

AND

DATA

one of these is

mapped into one

of these

execution

unit

AND microsequence

e.g., Fetch

Calc Operand Addr

Fetch Operand(s)

Calculate

Save Answer(s)

CPU

control

memory

“Macroprogram” Interpretation

순천향대학교 정보기술공학부 이 상 정 51


Slide52 l.jpg

System

Exception

Handler

user program

Exception:

return from

exception

Exceptions

  • Normal Control Flow

    • sequential, jumps, branches, calls, returns

  • Exception = unprogrammed control transfer

    • system takes action to handle the exception

      • must record the address of the offending instruction

    • returns control to user

    • must save & restore user state

순천향대학교 정보기술공학부 이 상 정 52


Slide53 l.jpg

Exceptions vs. Interrupts

  • MIPS convention:

    • exception means any unexpected change in control flow, without distinguishing internal or external

    • use the term interrupt only when the event is externally caused.

      Type of event From where? MIPS terminologyI/O device request ExternalInterruptInvoke OS from user program InternalExceptionArithmetic overflow InternalExceptionUsing an undefined instruction InternalExceptionHardware malfunctions EitherException orInterrupt

순천향대학교 정보기술공학부 이 상 정 53


Exception handling in mips l.jpg

Exception Handling in MIPS

  • Save PC in the dedicated register EPC

    • like $ra but can’t assume that $ra is unused

  • Records the reason for the exception in the Cause register

    • used by operating system to figure out what went wrong

  • Load special value into PC, the exception handler’s address

    • transfer execution to exception handler

  • The instruction RFE restores the PC from EPC

    • like jr $ra for subroutines but a special register just for exceptions

순천향대학교 정보기술공학부 이 상 정 54


Updated datapath to implement exceptions l.jpg

Updated Datapath to Implement Exceptions

순천향대학교 정보기술공학부 이 상 정 55


Updated finite state machine l.jpg

Updated Finite State Machine

순천향대학교 정보기술공학부 이 상 정 56


Pentium 4 l.jpg

Chapter 7

Chapter 6

Pentium 4

  • Pipelining is important (last IA-32 without it was 80386 in 1985)

  • Pipelining is used for the simple instructions favored by compilers“Simply put, a high performance implementation needs to ensure that the simple instructions execute quickly, and that the burden of the complexities of the instruction set penalize the complex, less frequently used, instructions”

순천향대학교 정보기술공학부 이 상 정 57


Pentium 458 l.jpg

Pentium 4

  • Somewhere in all that “control we must handle complex instructions

  • Processor executes simple microinstructions, 70 bits wide (hardwired)

  • 120 control lines for integer datapath (400 for floating point)

  • If an instruction requires more than 4 microinstructions to implement, control from microcode ROM (8000 microinstructions)

  • Its complicated!

순천향대학교 정보기술공학부 이 상 정 58


  • Login
