Presentation Transcript

Vaginal Rings and Microbicides

Mark Mitchnick, MD.

October 30, 2007


Microbicide delivery system goals
Microbicide Delivery System Goals

  • Safe

  • Effective

  • Coitally Independent

    • Daily

    • Monthly

  • Affordable

    • Ease of manufacture

    • Broadly stable

    • Long shelf life

  • Acceptable

  • Versatile

    • Forgiving PK

    • Multiple actives


Microbicide delivery choice will be key to widespread adoption of microbicides
Microbicide Delivery: Choice will be Key to Widespread Adoption of Microbicides

  • Diversity of delivery systems

    • Semisolids/Solids

      • Gels

      • Emulsions

      • Films

      • Tablets

    • Devices

      • Vaginal rings

      • Sponges

      • Physical barriers

    • Other?


Antiretroviral arv microbicides
Antiretroviral (ARV) Adoption of MicrobicidesMicrobicides

  • Most developers are focusing on ARV’s

  • HIV specific

  • Highly active

  • Affordable

  • Can be formulated to be Coitally independent

  • Safe, lots of experience with most classes

  • Stable in relevant climatic zones


Microbicides in product development
Microbicides Adoption of Microbicides in Product Development

Lactin-V

Invisible Condom

Free virus

BufferGel

Carraguard

PRO2000

SPL7013 (VivaGel)

Monoclonal antibodies

DS003 (BMS)

DS001 (Merck)

DS006 (Maraviroc)

Attachment

Locus small molecules

Fusion

S-DABO

Dapivirine (TMC120)

UC781

Tenofovir (PMPA)

PC815 (MIV150 + Carraguard)

Pyrimidinediones (Samjin)

Replication

(RT)

Integration

Protein synthesis and assembly

Budding

Maturation


Ipm drug product grid medium term
IPM Drug Product Grid: Adoption of MicrobicidesMedium Term

  • Delivery Formats

    • Semisolids

      • Gels

      • Emulsions

      • Gel caps

    • Vaginal Rings

      • Matrix

      • Reservoir

    • Films

    • Dissolving Tablets

  • API

    • NNRTI

      • Dapivirine

    • NRTI

      • PMPA

    • R5 Blocker

      • Merck 167

      • Maraviroc (pending)

    • GP 120 binding

      • BMS 793


Dapivirine
Dapivirine Adoption of Microbicides

  • NNRTI developed by Tibotec/J&J, licensed to IPM (2004)

  • Developed originally as therapeutic, 11 clinical studies conducted via oral administration

  • Highly potent ARV

  • Low cytotoxicity, non-mutagenic, non-teratogenic

  • Easily manufactured, very cheap

  • Stable drug substance

  • IP clarity

  • Multiple dosage forms


Sustained release vaginal rings
Sustained Release: Vaginal Rings Adoption of Microbicides

  • Attractive technology:

    • 30+ days of drug delivery

    • Potentially reduces compliance burden

    • Easy to use

    • “Low” cost

  • Unknowns:

    • Acceptability in relevant populations

    • Scale up manufacture

    • Regulatory path in multiple countries

    • Feasibility of multi-drug combinations

    • Environmental impact


Addressing the unknowns
Addressing the Unknowns Adoption of Microbicides

  • Acceptability in relevant populations

    • Acceptability studies ongoing

  • Scale up manufacture

    • Survey of methods with scale-up of each investigated

    • Redundant capacity being installed

  • Regulatory path in multiple countries

    • Priority

    • Engaging regulators

  • Feasibility of multi-drug combinations

    • Multiple groups engaged to tackle

    • Several novel approaches

  • Environmental impact

    • Being quantified, primary concern is control over HIV

    • Additional matrix materials being investigated


Types of vaginal rings reservoir matrix
Types of Vaginal rings: Reservoir & Matrix Adoption of Microbicides

Dapivirine

Raman maps

Cross-sectional

profiles

Drug

Core-type

Matrix-type

Courtesy or Karl Malcolm, QUB


In vitro daily release of dapivirine from a silicone elastomer matrix vaginal ring
In-Vitro Daily Release of Adoption of MicrobicidesDapivirine From a Silicone Elastomer Matrix Vaginal Ring

g Dapivirine

Days

-Sink conditions: Release medium is 50% IPA. Daily vaginal gel dose= 500 g (red line)


Human experience with vaginal rings to date
Human Experience with Vaginal Rings To Date Adoption of Microbicides

  • Several marketed products

    • Hormone releasing

    • FemRing

      • Vagianlmenapuse symptoms

      • Silicone reservoir

    • NuvaRing

      • Birth control

      • EVA reservoir

  • Microbicide containing rings

    • In development

    • Several Phase I studies

      • PK looking very promising

      • No safety issues to date


Dapivirine levels in clinical samples
Dapivirine Levels in Clinical Samples Adoption of Microbicides

EC50= 0.33 ng/mL

Dapivirine ng/mL

<50 pg/mL


Next steps
Next Steps Adoption of Microbicides

  • Complete manufacturing development

  • Install manufacturing capacity

  • Larger safety studies in 2008

  • Phase III study with Dapivirine ring in 2010

    • Part of larger multi-arm study

  • Strong efforts in additional development

    • Multiple actives in single ring

    • Additional Matrix materials
