Presentation Transcript
Slide1 l.jpg

Wireless and Mobile Computing and Networking at the University of FloridaTechnology, Infrastructure & Research

University of Florida

http://net-services.ufl.edu/wireless

http://www.harris.cise.ufl.edu


Talk overview l.jpg
Talk Overview University of Florida

  • Technology

    • Mobile Devices

    • Wireless Networks

    • The 802.11b Wireless LAN

  • Infrastructure

    • The Wireless campus project

  • Synergistic Research Activities

    • Helal (CISE): Wireless & Mobile Tech for the Elders

    • Others ..


Mobile information appliances l.jpg
(Mobile Information Appliances) University of Florida

Subscriber Identification

Module (SIM)


Platform limitations l.jpg
Platform Limitations University of Florida

  • Limited battery power

  • Limited memory capacity

  • Limited processing power (in some devices)

  • Limited I/O modalities (no keyboard)

  • Limited display size, resolution & refresh rate

  • Wide variety of devices lacking platform standardization (started to change with advent of Java 2 Micro-Edition)


Wireless networks l.jpg

Global University of Florida

Satellite

dik

©

Suburban

Urban

In-Building

Pico-Cell

Micro-Cell

Macro-Cell

In-Room

(BlueTooth)

Wireless Networks


Wireless networks6 l.jpg

UMTS University of Florida

Wireless Networks


Wireless data networks l.jpg
Wireless Data Networks University of Florida

  • Unlicensed Frequency

    • The 802.11 Wireless LAN

    • Bluetooth

    • Infrared

  • Licensed Frequency

    • 2G-2.5G: D-AMPS, CDMA, GSM, iDEN, CDPD

    • 3G: CDMA2000, W-CDMA

  • Mobile Networking

    • CDPD: Wireless packet data

    • iDEN: Wireless packet data & Mobile IP

    • GPRS & EDGE: Wireless packet data & other mobile networking protocols (competition to Mobile IP)


802 11 l.jpg
802.11 University of Florida

  • Unlicensed Frequency

    • indoor/outdoor coverage with cell sizes ranging from 300 feet (indoor) to 1000 feet (outdoor)

    • Bandwidth:

      • 802.11b: 11Mb/s

      • 802.11a: 100Mb/s

      • 802.11g: 54Mb/s;

      • Effective bandwidth in presence of multiple users is less (for instance: 6Mb/s in 803.11b)


Network limitations l.jpg
Network Limitations University of Florida

  • Low bandwidth

    • Limited spectrum, interference

  • High latency (in 2G and 3G)

  • High Bit Error Rate (BER)

    • bad carrier signal, handoffs

  • Frequent disconnection

  • Heterogeneity of network coverage

  • In many cases, lack of network infrastructure  Ad-hoc Networks

  • Preserving Return on Investment in presence of a rapidly evolving technology


Challenges l.jpg
Challenges University of Florida

Mobile environment differs greatly from the traditional fixed-network environment. The difference is limitations that can be divided into two categories.

  • Platform diversity and limitations – which platform to use for a certain application?

  • Network limitations -- which network to support? What if the devices use different network interfaces?


Which platform l.jpg
Which Platform? University of Florida

Mobile User


Target platforms l.jpg
Target Platforms University of Florida


Operating systems l.jpg
Operating Systems University of Florida


Implementation language l.jpg
Implementation Language University of Florida


Wireless infrastructure at uf l.jpg
Wireless Infrastructure at UF University of Florida

Recognizing the importance and impact of using wireless and mobile technology in education and research, the University Network Services and Several University Colleges and Schools have committed to provide for the indoor and outdoor deployment of the 802.11b wireless LAN technology.


Short history of wireless at uf l.jpg
Short History of Wireless at UF University of Florida

  • Lombardi’s initiative -- First Wireless Classroom Trial: in CSE Building, Spring 1999

    • 20 IBM thinkpads, 20 PC cards, two Bay Network access points (2Mbps), Static IP configurations – no authentication

  • The University IE Proposal to the National Science Foundation (even though was not funded, it brought together awareness and commitment of various University entities)

  • Outdoor campus deployment begun (Jan 2001)

  • CISE deployment (May 2001)

  • Law School deployment (July 2001)

  • College of Engineering all-classroom deployment (May 2001 – Nov 2001)


Blueprints of the big picture l.jpg
Blueprints of the Big Picture University of Florida

We envision that many educational activities can be taken to a higher level of effectiveness if this opportune technology is exploited properly. In particular, we identify several undergraduate curricula that, for a long time, have been deprived from having the appropriate computing environments that they needed. Botany, geology, animal science, agriculture, anthropology, remote sensing, architecture, veterinary medicine, civil engineering, exercise physiology, and forestry are among the many curricula that would benefit significantly from the wireless outdoor laboratory, a concept that can be achieved with today’s technology. By bringing the (wireless) network and the (portable) computers much closer to the actual subjects of study (plants, humans, trees, crops, animals, roads, building, etc.), it will be possible to design and develop substantially effective curricula for undergraduate and graduate education.


Goals of the wireless campus project l.jpg
Goals of the Wireless Campus Project University of Florida

  • Create a Pervasive Computing environment within the University of Florida campus, by exploiting wireless, mobile networking technology and portable computing appliances.

  • Modify and extend existing curricula in several major areas to take advantage of the wireless connectivity that will blanket UF campus.

  • Explore research issues in Pervasive Computing (e.g. projects undertaken in the Harris Lab by Dr. Helal)

  • Potentially, integrate some University services into the wireless network.


Objectives of the wireless campus project l.jpg
Objectives of the Wireless Campus Project University of Florida

  • Indoor and outdoor wireless connectivity

  • Ideally: Single IP, secure roaming solution – pending industry adoption of IPv6

  • Support for a variety of devices (notebooks, iPAQs, Palms, wearable computers, …)

  • Different views of network resources for different student groups

  • Anticipated use of thin client technology

  • Innovative solutions for software license management (not all mobile users active at once – licenses will need to be spread over multiple network domains (unusual)

  • Challenging requirements: security & scalability


International center on pervasive technology for successful aging l.jpg

Sample Research Activities on Mobile and Wireless University of Florida

International Center on Pervasive Technology for Successful Aging

Dr. Bill Mann, Director

Dr. Sumi Helal, Director of Technology Development

Rehabilitation Engineering Research Center on

Technology for Successful Aging

University of Florida

Funded by

National Institute on Disability and

Rehabilitation Research


Pervasive technology for elders l.jpg
Pervasive Technology for Elders University of Florida

  • Health care system ($$ & Nurses) will not sustain the increasing number of elders

  • Goal: how to help elders stay at home and live independently

  • Broad center activities:

    • Create smart spaces

    • Create magic Wands for interaction with smart spaces

    • Create and perform extensive testing of applications that use the smart home/phone infrastructure


Sample applications l.jpg
Sample Applications University of Florida


Sample applications25 l.jpg
Sample Applications University of Florida


Icta planned renovation room 447 cse bldg l.jpg

Main Entrance to ICTA University of Florida

Video Tele-conferencing

ICTAPlannedRenovationRoom 447, CSE Bldg.

Meeting

Table

Front

door

Workstations

Elder Home

Mockup

Harris Mobile Computing

Laboratory

Servers

Window

Workshop Area

Storage

Pins


Early prototyping l.jpg

Pharmacy University of Florida

Client

Request

Query

Query

Reply

Response

Response

HTTP Interface

Proxy

Server

Scanner

Medicine Bottle

Unlock request

Data written to port

Generated Pulse

TINI Board

Circuit

UnLatch

Early Prototyping

Video


802 11 wireless networking l.jpg
802.11 Wireless University of FloridaNetworking


History l.jpg
History University of Florida

  • In 1985, as an attempt to stimulate the production and use of wireless network products, the FCC modified Part 15 of the radio spectrum regulation, which governs unlicensed devices. The modification authorized wireless network products to operate in the Industrial, Scientific, and Medical (ISM) bands using spread spectrum modulation.


Fcc ism restrictions l.jpg
FCC University of Florida ISM Restrictions

  • Frequency restrictions

    • 902-928 MHz

    • 2.4-2.4835 GHz

    • 5.725-5.850 GHz

  • 1 Watt power restriction

    • 100mW for WLANs

  • Spread Spectrum transmission


History31 l.jpg
History University of Florida

  • The first wireless LAN technologies operated in the 900MHz band and were low speed (1-2Mbps), proprietary offerings.

  • 1992, wireless LAN makers began developing products operating in the unlicensed 2.4 GHz frequency band.

  • IEEE approved 802.11 standard in 1997


802 11 transmission methods l.jpg
802.11 transmission methods University of Florida

  • FHSS

  • DSSS

  • IR


Frequency hopping spread spectrum fhss l.jpg
Frequency Hopping Spread Spectrum (FHSS) University of Florida

  • minimum 75 non-overlapping channels with a maximum 1 MHz bandwidth

  • Three possible hop patterns (22 hops in a given pattern)

  • Minimum rate of 2.5 hops/s

  • Maximum dwell time of 400ms


Direct sequence spread spectrum dsss l.jpg
Direct Sequence Spread Spectrum (DSSS) University of Florida

  • Combines a data signal with a higher data rate bit sequence (chipping code). Minimum of 10.

  • 14 twenty-two MHz channels


Characteristics of fhss l.jpg
Characteristics of FHSS University of Florida

  • Lower cost

  • Lowest power consumption

  • More tolerant to signal interference

  • Lower potential data rates

  • Less range than direct sequence

  • Less interoperability


Characteristics of dhss l.jpg
Characteristics of DHSS University of Florida

  • Highest cost

  • Highest power consumption

  • Less tolerant to interference

  • Highest potential data rates

  • Better range than frequency hopping

  • Better interoperability


802 11 layers l.jpg
802.11 Layers University of Florida


802 11 data link layer mechanisms l.jpg
802.11 Data Link Layer University of FloridaMechanisms

  • CSMA/CA

  • RTS/CTS

  • CRC checksum

  • Acknowledgments

  • Fragmentation


802 11 features l.jpg
802.11 Features University of Florida

  • Beacon frames

  • Authentication

  • Roaming

  • Security

  • Power saving


Security features l.jpg
Security Features University of Florida

  • Service Set Identifier (SSID) (also called Network Identifier or Network Name)

  • MAC address filtering

  • Wired Equivalent Privacy (WEP) encryption


Wep encryption l.jpg
WEP Encryption University of Florida

  • Algorithm based on RSA RC4 algorithm

  • 40bit and 128bit keys

  • Security partially relies on maintaining the secrecy of the WEP key.

  • Shown to be weak


Wireless access modes l.jpg
Wireless Access Modes University of Florida

  • Ad hoc

  • Infrastructure


802 11 future l.jpg
802.11 Future University of Florida

  • 802.11g

    • 2.4Ghz frequency band, >20Mbps data rate

  • 802.11a

    • 5.7Ghz supporting data rates up to 54Mbs.


Uf wireless deployment l.jpg

UF Wireless Deployment University of Florida


Uf wireless deployment45 l.jpg
UF Wireless Deployment University of Florida

  • Cisco Aironet 350 series access points

  • Authenticated via Gatorlink userid

  • Not using WEP encryption

  • No registered MAC address

  • Area VLANs and a common configuration to allow roaming


Compatibility l.jpg
Compatibility University of Florida

  • Wireless Ethernet Compatibility Alliance (WECA)

    Wireless Fidelity - WiFi


Channel coordination l.jpg
Channel Coordination University of Florida

  • 802.11b DSSS hardware only offers 11 channels.

  • At most, only three non-overlapping channels can be used (1,6, and 11).

  • Where common channels overlap there will be co-channel interference which will negatively impact performance.


Dsss channels l.jpg
DSSS Channels University of Florida


Channel coordination49 l.jpg
Channel Coordination University of Florida


Vertical channel coordination l.jpg
Vertical Channel Coordination University of Florida


Basic topology l.jpg

UF Core University of Florida

Basic Topology

Authentication Gateway

Core POP

Access Point


Vpn authentication l.jpg

UF Core University of Florida

VPN Authentication

Authentication Gateway

CORE POP

VPN Concentrator

Access Point

VPN connection


Vlan trunking l.jpg
VLAN Trunking University of Florida

  • VLAN trunking (802.1q) allows the transport of multiple 'logical' (Virtual) ethernets over one single physical ethernet.

  • This allows the delivery of authentication VLANs in parallel with building VLAN(s).

  • This use of VLANs allows roaming through wireless areas that share the same VLAN.


Vlan trunking design l.jpg
VLAN Trunking Design University of Florida

CORE POP

Authentication VLAN passes through CORE POP at layer 2 only and is not routed. Routing for the VLAN is performed by the Authentication Gateway.

Routed connection for Authentication Network

Authentication VLAN

Authentication Gateway

802.11q Trunk

Authentication VLAN

Access Point

Building VLAN(s)

Building Network(s)

Authentication VLAN

Access Point

BPOP Switch


Area vlan implementation l.jpg

UF Core University of Florida

Area VLAN Implementation

CORE POP

Authentication Gateway

Authentication VLAN

802.11q Trunk

Authentication VLAN

Authentication VLAN

Building Network(s)

Building Network(s)

Access Point

Access Point


Problems issues l.jpg
Problems/Issues University of Florida

  • Departmental wireless networks

  • Rogue wireless networks

  • Interference from other devices

  • Security

  • Malicious interference

  • Interoperability

  • Competing technology

  • Emerging technology


Isolated deployment l.jpg
Isolated Deployment University of Florida

If you are deploying wireless service and it can not be incorporated into the campus plan the following steps are critical:

  • Contact Network Services to coordinate frequency usage.

  • Change the SSID to a non-default setting (and do NOT use ‘ufw’).

  • Disable the SSID broadcasting capability.


Current wireless campus coverage spring 2002 l.jpg
Current Wireless Campus Coverage University of Florida(Spring 2002)


ad
