Presentation Transcript
Automated irrigation systems benefits and maintenance issues l.jpg

Automated Irrigation Systems:Benefits and Maintenance Issues

Dick Villamil, Ph.D.

CEO, Aquarius Landscape Sprinklers






Maybe it s time to install or optimize your use of l.jpg
Maybe it’s time to install…(or optimize your use of)

Automatic landscape sprinklers!


Key aims for grounds managers l.jpg

Keep repetitive labor to a minimum

Eliminate your reliance on Mother Nature

Reduce annual need for re-seeding

Key aims for grounds managers

  • Make the president’s house look good

  • Eye appeal for visitors, students, administration

  • Keep high-traffic areas from turning into mud

  • Minimize loss of landscape plantings


Why automatic sprinklers can help l.jpg
Why automatic sprinklers can help

  • Consistent source of water

  • Protect grounds investment

  • Less labor by grounds staff

  • Protects plants from effects of variable weather

  • Customizable to your plant and turf needs

  • Increases effectiveness of fertilizer

  • One word: AUTOMATIC


Even if you have an automatic system already l.jpg
Even if you have an automatic system already…

  • Are you covering all your areas?

  • Are you optimizing timing and delivery?

  • Do you have consistent equipment?

  • Have you had a check-up recently?

  • Are you still having problem wet or dry areas?

  • Have you ever actually watched it working?


What your fields could look like l.jpg
What your fields could look like!


What your grounds could look like l.jpg
What your grounds could look like!


Key irrigation concepts l.jpg
Key Irrigation Concepts:

  • Plant materials – sod, seed, trees or perennials

  • Soil Type – sand, clay

  • Drainage

  • Electrical needs and issues

  • Water supply – pressure vs. flow in gpm

  • Water quality – lake, pond, well or municipal

  • “Hardscape” issues

  • Sustainable maintenance


Tools of the trade l.jpg
Tools of the Trade

  • Controllers – are loaded with features

  • Lightning and surge protection

  • Multiple independent programs

  • Multiple start times

  • Ease of use


Tools of the trade14 l.jpg
Tools of the Trade

  • Valves offer many features at a low price

  • Pressure reducing

  • Flow control

  • Manual activation

  • Low amperage

  • Durable plastic body

  • Internal bleed

  • Dirty water compatible


Tools of the trade15 l.jpg
Tools of the Trade

  • Rotors have many interchangeable nozzles

  • One sprinkler for either full or part circle

  • Integrated check valve

  • Ease of service

  • High pop-up height – 5”

  • Long warranty


Installation strategies l.jpg
Installation Strategies

  • Vibratory plow can install 2” pipe with no trench!

  • Flexible continuous poly pipe resists heaving

  • Install multi strand wire with pipe

  • Use non-corrosive clamps

  • PVC reduces restriction to flow


Installation strategies17 l.jpg
Installation strategies

  • Install sleeving before pavement

  • Locate wire and pipe splices – use a digital camera

  • Install sprinklers and valves AFTER landscaping and BEFORE lawn planting



Maintenance issues l.jpg
Maintenance Issues

  • Refer to As-Built drawings BEFOREExcavating

    Planting trees

    Aerating lawns

    Installing tent stakes

    Staking roads for snow plowing


Maintenance issues20 l.jpg
Maintenance issues

  • Operate and test frequently

    Exercise valve diaphragms

    Check for broken sprinklers

    Check wiring integrity

    Change program to suit the weather

    Avoid the “Set it and Forget It” mentality


Maintenance issues21 l.jpg
Maintenance issues

  • Wires should be labeled

  • Install spare wires – just in case!

  • Install grounding rods to avoid electrical problems

  • Choose the proper wire gauge for length of run


Maintenance issues22 l.jpg
Maintenance issues

  • Clean around valve boxes before they are

    “lost”

  • Main line shutoff valves and wire splice boxes need to be located

  • Trim grass on a monthly

    schedule


Maintenance issues23 l.jpg
Maintenance issues

  • Plan your water shutoff valves for convenient access

  • Winterization ports should be easily accessible

  • Emergency access may be important!


Design for efficiency l.jpg

Hydrozone strategy

Gardens vs. Lawn

Sunny vs. Shady areas

Rotors vs. Mist Spray

Slopes vs. level lawn

Drip for shrubs and perennials

Drip for disease susceptible perennials

Water conservation and Liability Issues

- Avoid spraying across public walks

- Use check valves to

avoid low head

drainage

- Adjust controller for

seasonal changes

Design for Efficiency


Hydrozones drip for gardens rotors for lawns l.jpg
Hydrozones – Drip for gardens, Rotors for lawns


Hydrozones spray for gardens rotors for lawns l.jpg
Hydrozones – Spray for gardens, rotors for lawns.


Water conservation avoid watering walks and liability issues and roads l.jpg
Water Conservation – avoid watering walks and Liability Issues and roads


Hydrozone drip for gardens l.jpg
Hydrozone – Drip for Gardens

  • Drip irrigation puts water at the roots where it is needed

  • Drip avoids wetting foliage inducing mildew

  • Drip conserves water

  • Drip prevents wetting fences and buildings


Specific maintenance issues l.jpg

Stuck valves – dirty water

Broken sprinkler riser

Rotors that don’t rotate

Wires cut by . . . . . . .

Properly winterized

Don’t just add sprinklers

add a new zone

Prune shrubs to avoid blocking sprinklers

Raise sprinklers as turf thickens

Monitor water quality

Specific Maintenance Issues


Maintenance winterization l.jpg
Maintenance - Winterization

  • Winterize by using compressed air

  • Choose the proper compressor

  • CFM vs. pressure

  • Install drains in low points


Irrigation motto 1 l.jpg
Irrigation Motto #1

Set it and Forget it.

You’ll never discover the problem until

there IS one!

.


Irrigation motto 2 l.jpg
Irrigation Motto #2

  • The best fertilizer is the footstep of the farmer.

  • Run a test cycle often to check your irrigation system’s performance.


Irrigation systems l.jpg
Irrigation systems

  • Properly designed

  • Carefully installed

  • Regularly maintained

  • Selectively upgraded

    will result in the following . . . . . . . . . . .
