Hella Xenius 5DV009720-00 Xenon Ballast Control Unit

Xenons4U is the leading high quality and affordable car parts provider in UK. We offer Hella Xenius 5DV009720-00 Xenon Ballast Control Unit. If your xenon lights have stopped working or shut downs without any reason then Xenon HID Ballast has failed and you will need to replace with new unit. It is direct replacement for your old part and no modifications will be required. For more information visit our website.

Albertpeter
Download Presentation

Hella Xenius 5DV009720-00 Xenon Ballast Control Unit

An Image/Link below is provided (as is) to download presentation Download Policy: Content on the Website is provided to you AS IS for your information and personal use and may not be sold / licensed / shared on other websites without getting consent from its author. Content is provided to you AS IS for your information and personal use only. Download presentation by click this link. While downloading, if for some reason you are not able to download a presentation, the publisher may have deleted the file from their server. During download, if you can't get a presentation, the file might be deleted by the publisher.

E N D

Presentation Transcript

  1. Hella Xenius 5DV009720-00 Xenon Ballast Control Unit

  2. GENUINE HELLA 5DV009720-00 XENIUS XENON HID BALLAST CONTROL UNIT. • Factory fitted on Opel or Vauxhall cars with Xenon headlamps and AFS (Cornering Function). • If your xenon lights have stopped working or shut downs without any reason then Xenon HID Ballast has failed and you will need to replace with new unit. • This part is indented to fit only Vauxhall or Opel brand cars such as Insignia or Astra J MK6. • Hella 5DV 009 720-00 xenon ballast is used with D1S HID bulbs. • Information from original sticker: D1S DOT 2000h DC 1100V AC 85V P 35W Al 99.5 xenius ballast 12V. • Xenon Ballast is direct replacement for your old part and no modifications will be required. • Below you will find Hella part numbers and compatibility list. • THE MOST COMMON WARNING MESSAGES • Service AFL Lamp • Headlamp levelling malfunction • Check Left Low Beam Lamp • Check Right Low Beam Lamp • Check left dipped beam lamp • Check right dipped beam lamp

  3. THE MOST COMMON DIAGNOSTIC TROUBLE CODES DTC • B2590 02: Left Cornering Lamp Circuit Short to Ground • B2590 04: Left Cornering Lamp Circuit Open • B2595 02: Right Cornering Lamp Circuit Short to Ground • B2595 04: Right Cornering Lamp Circuit Open • B2575 01: Left Headlamp Control Circuit Short to Battery • B2575 02: Left Headlamp Control Circuit Short to Ground • B2575 04: Left Headlamp Control Circuit Open • B2699 01: Right Headlamp Control Circuit Short to Battery • B2699 02: Right Headlamp Control Circuit Short to Ground • B2699 04: Right Headlamp Control Circuit Open • U1511-00 LIN Bus 1 Lost communication with device 1 • HELLA PART NUMBERS • 5DV 009 720-00 • 5DV009720000 • 5DV009720-00

  4. OEM PART NUMBERS • GM13278005, GM13278005, 13278005, • Opel Vauxhall: 12323357295702 • COMPATIBILITY LIST: • Vauxhall Opel Astra J MK6 6 2009, 2010, 2011, 2012 • Vauxhal Opel Insignia Pre-Facelift MK1 A 2008 2009 2010 2011 2012 2013 • Saloon Sedan Hatchback Estate Sports Tourer • 2.0DTCi diesel

  5. CONTACT US www.xenons4u.co.uk info@xenons4u.co.uk
